JJF 1450-2014 English PDF

Q: How long will the true-PDF of English version of JJF 1450-2014 be delivered?

Upon your order, we will start to translate JJF 1450-2014_English as soon as possible, and keep you informed of the progress. The lead time is typically 3 ~ 5 working days. The lengthier the document the longer the lead time.

Q: Can I share the purchased PDF of JJF 1450-2014_English with my colleagues?

Yes. The purchased PDF of JJF 1450-2014_English will be deemed to be sold to your employer/organization who actually pays for it, including your colleagues and your employer's intranet.

Q: Does the price include tax/VAT?

Yes. Our tax invoice, downloaded/delivered in 9 seconds, includes all tax/VAT and complies with 100+ countries' tax regulations (tax exempted in 100+ countries). Avoidance of Double Taxation Agreements (DTAs) between Singapore and 100+ Countries: https://www.iras.gov.sg/taxes/international-tax

Q: Do you accept my currency other than USD?

Yes. If you need your currency to be printed on the invoice, please write an email to Sales@ChineseStandard.net. In 2 working-hours, we will create a special link for you to pay in any currencies. Otherwise, follow the normal steps: Add to Cart -- Checkout -- Select your currency to pay.

US$559.00 · In stock
Delivery: <= 5 days. True-PDF full-copy in English will be manually translated and delivered via email.
JJF 1450-2014: Program of Pattern Evaluation of Portable Induction Anemometer
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
JJF 1450-2014	559	Add to Cart	5 days	Program of Pattern Evaluation of Portable Induction Anemometer	Valid

Similar standards

GB/T 36126 JJF 1368 GB/T 1885 JJF 1451 JJF 1452 JJF 1445

Basic data

Standard ID: JJF 1450-2014 (JJF1450-2014)
Description (Translated English): Program of Pattern Evaluation of Portable Induction Anemometer
Sector / Industry: Metrology & Measurement Industry Standard
Classification of Chinese Standard: A53
Classification of International Standard: 17.100
Word Count Estimation: 24,216
Date of Issue: 2/14/2014
Date of Implementation: 5/14/2014
Quoted Standard: JJG 515-1987; JJG 431-1986
Regulation (derived from): ?AQSIQ Announcement 2014 No. 17
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine
Summary: This standard applies to portable magnetic induction wind anemometer (hereinafter referred to as magnetic induction wind meter) of type evaluation.

JJF 1450-2014: Program of Pattern Evaluation of Portable Induction Anemometer

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Program of Pattern Evaluation of Portable Induction Anemometer People's Republic of China National Metrology Technical Specifications Portable magnetic induction wind anemometer type evaluation outline Issued on. 2014-02-14 2014-05-14 implementation The State Administration of Quality Supervision, Inspection and Quarantine released Portable magnetic induction wind anemometer Type Evaluation Outline Focal point. the National Technical Committee of pressure measurement Main drafting unit. China Meteorological Administration meteorological observation center China Baicheng Ordnance Test Center Participated in the drafting unit. Xinjiang Meteorology Technical Equipment Support Center This specification commissioned the National Technical Committee of pressure measurement shall be interpreted The main drafters of this specification. Li Jianying (CMA Meteorological Observation Center) Qijiu Cheng (China Baicheng Ordnance Test Center) HE Xiao Lei (China Meteorological Administration meteorological observation center) Yang Jian (China Baicheng Ordnance Test Center) For He Jun (China Meteorological Administration meteorological observation center) Li Qing (China Baicheng Ordnance Test Center) Drafters participate. Wu Ning (Xinjiang meteorological technology and equipment protection center)

Introduction (Ⅲ) 1 Scope (1) 2. References (1) 3 Overview (1) 4 legal management requirements (1) 4.1 units of measurement (1) 4.2 The maximum permissible error (1) 4.3 legal metrology marking and identification of measuring instruments (1) 4.4 Test Prototype (2) 5 measurement requirements (2) 5.1 Wind represents error (2) 5.2 meter wind measuring range (2) 5.3 Start vane wind speed (2) 5.4 Winds indicates error (2) 5.5 anemometer measurement error (2) 5.6 anemometer measurement range (2) 5.7 wind speed swing pointer (2) 5.8 Start up wind speed wind cup (2) 6 General Requirements (2) 6.1 Appearance (2) 6.2 Mechanical properties (3) Storage temperature 6.3 (3) 7 type evaluation item list (3) 8 pilot projects test methods and conditions (4) 8.1 Wind represents error (4) 8.2 meter wind measuring range (4) 8.3 weathervane start Winds (5) 8.4 Winds indicates error (5) 8.5 anemometer measurement error (6) 8.6 anemometer measurement range (6) 8.7 wind speed swing pointer (7) 8.8 Start up wind speed wind cup (7) 8.9 Appearance (7) 8.10 Mechanical properties (8) 8.11 high and low temperature storage (8) 9 type evaluation results to determine (9) Appendix A portable magnetic induction wind anemometer type evaluation original record format (10) B portable magnetic induction wind anemometer measurement error calculation appendix (15) Appendix C portable magnetic induction wind anemometer measurement equipment manufacturing license examination prerequisites (16)

Introduction

JJF 1016 "Measuring Instruments type evaluation outline guidelines for the preparation", JJF 1015 "Measuring Instruments type evaluation and type Ratify general specification ", JJF 1246" measurement equipment manufacturing license evaluation general specification ", JJF 1001" universal cytometry Language and Definitions "and JJF 1059" Evaluation and Expression of Uncertainty in Measurement "together constitute the fundamental norm-setting series specification. The specification for the specific test methods and technical indicators refinement, additions and modifications. This specification is the first release. Portable magnetic induction wind anemometer type evaluation outline

1 Scope

This type of evaluation framework applies to portable magnetic induction wind anemometer (hereinafter referred to as magnetic induction wind meter) of pattern evaluation. 2. References JJG515-1987 portable magnetic induction wind anemometer (Trial) JJG431-1986 DEM6 type light wind anemometer cups Those documents by reference the terms of this syllabus constitute provisions of this outline. For dated references, All subsequent amendments (not including errata content) or revisions do not apply in this outline, however, encourage the All parties that this outline agreement to use the latest versions of these documents. For undated reference documents Member, the latest versions apply to this outline.

3 Overview

Magnetic induction wind meter is a measure of the instantaneous wind direction and speed instruments, mainly for field observation, by the anemometer and wind direction table composition. The key member includes a wind vane and wind cups. Vane by wind vane shaft is rotated around to drive the wind direction pointer on the compass direction. Wind cup Wind cup shaft is rotated around by wind, driven by the wind cup shaft lower end of the magnet is rotated to form a rotating magnetic field around the magnet The induction coil generates eddy currents in a changing magnetic field. Induction coil under the action of the electromagnetic force, the magnet rotates along the square To deflect. Induction coil deflected to a certain angle after reaching the torque balance and gossamer. Winds pointer The induction line Deflection angle in the circle indicates the wind speed wind speed dial.

4 legal management requirements

4.1 units of measurement Magnetic induction wind table should respectively "m/s" and "(°)" as wind speed and direction units. 4.2 The maximum permissible error Wind direction magnetic induction meter maximum permissible error of ± 22.5 °, wind speed maximum permissible error of ± (0.5m/s 0.05v). Note. v standard wind speed, m/s. 4.3 legal metrology marking and measuring instruments logo 4.3.1 legal metrology flags include the following. --- Measurement equipment manufacturing license logo and number (test prototype should stay out of the corresponding position); --- Induction wind flags and table type approval number (test prototype should stay out of the corresponding position; this entry is not mandatory provisions set); --- Product certification (with magnetic induction wind provided separately from the main unit). 4.3.2 measuring instruments identified include the following. --- Name induction wind table specification (model); ......
