JJF 1096-2002 English PDF

Q: How long will the true-PDF of English version of JJF 1096-2002 be delivered?

Upon your order, we will start to translate JJF 1096-2002_English as soon as possible, and keep you informed of the progress. The lead time is typically 2 ~ 4 working days. The lengthier the document the longer the lead time.

Q: Can I share the purchased PDF of JJF 1096-2002_English with my colleagues?

Yes. The purchased PDF of JJF 1096-2002_English will be deemed to be sold to your employer/organization who actually pays for it, including your colleagues and your employer's intranet.

Q: Does the price include tax/VAT?

Yes. Our tax invoice, downloaded/delivered in 9 seconds, includes all tax/VAT and complies with 100+ countries' tax regulations (tax exempted in 100+ countries). Avoidance of Double Taxation Agreements (DTAs) between Singapore and 100+ Countries: https://www.iras.gov.sg/taxes/international-tax

Q: Do you accept my currency other than USD?

Yes. If you need your currency to be printed on the invoice, please write an email to Sales@ChineseStandard.net. In 2 working-hours, we will create a special link for you to pay in any currencies. Otherwise, follow the normal steps: Add to Cart -- Checkout -- Select your currency to pay.

US$499.00 · In stock
Delivery: <= 4 days. True-PDF full-copy in English will be manually translated and delivered via email.
JJF 1096-2002: Calibration Specification for Calibrator of Extensometers
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
JJF 1096-2002	499	Add to Cart	4 days	Calibration Specification for Calibrator of Extensometers	Valid

Similar standards

JJG 1114 JJF 1280 JJF 1126 JJF 1097 JJG 1088 JJF 1099

Basic data

Standard ID: JJF 1096-2002 (JJF1096-2002)
Description (Translated English): Calibration Specification for Calibrator of Extensometers
Sector / Industry: Metrology & Measurement Industry Standard
Classification of Chinese Standard: A52
Word Count Estimation: 19,147
Date of Issue: 2002-11-04
Date of Implementation: 2003-02-04
Issuing agency(ies): State Administration of Quality Supervision, Inspection and Quarantine
Summary: This standard applies to the extensometer dedicated calibration device (hereinafter referred to as the calibrator) the metrological characteristics calibration.

JJF 1096-2002: Calibration Specification for Calibrator of Extensometers

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Calibration Specification for Calibrator of Extensome National Metrology Technical Specification of the People's Republic Extensometer Calibrator Calibration Specifications Released on November 11,.2002 2003-02-04 implementation The General Administration of Quality Supervision, Inspection and Quarantine issued This specification was approved by the General Administration of Quality Supervision, Inspection and Quarantine on November 4,.2002, and Implemented on February 4,.2003. Focal Point. National Geometric Quantity Engineering Measurement Technology Committee Main drafting unit. Shaanxi Institute of Metrology and Testing Participated in the drafting unit. Xi'an Century Measurement and Control Technology Research Institute Institute of Analysis and Testing, Central Iron and Steel Research Institute This specification entrusts the focal point to be responsible for interpretation The main drafters of this specification. Zhang Lei (Shaanxi Institute of Metrology and Testing) Shi Jize (Xi'an Century Measurement and Control Technology Research Institute) Wang Chunhua (Institute of Analytical Testing, Central Iron and Steel Research Institute)

1 Scope (1) 2 Citations (1) 3 Overview (1) 4 Measurement characteristics (2) 4.1 The quality of the micro-head and the relative position of each part (2) 4.2 Coaxiality of the upper and lower mandrels (2) 4.3 Resolution (2) 4.4 indication error (2) 4.5 indication stability (3) 4.6 bracket rigidity (3) 5 Calibration conditions (3) 5.1 Environmental conditions (3) 5.2 Calibration items and calibration equipment (3) 6 Calibration method (3) 6.1 The quality of the micro-head and the relative position of each part (4) 6.2 Coaxiality of the upper and lower mandrels (4) 6.3 Resolution (4) 6.4 indication error (4) 6.5 indication stability (7) 6.6 bracket rigidity (7) 7 Calibration result expression (7) 8 re-study interval (7) Appendix A Measurement uncertainty of the indication error of the extensometer calibrator (8) Appendix B Special Table for Calibrating the Extensometer Calibrator (13) Appendix C Contents of the Calibration Certificate (14) Extensometer Calibrator Calibration Specifications

1 Scope

This specification applies to the calibration of the metering characteristics of the extensometer-specific calibration device (hereinafter referred to as the calibrator).

2 Citations

JJF 1001-1998 General measurement terms and definitions JJF 1059-1999 Measurement Uncertainty Evaluation and Representation ISO 9513.1999 Calibration of extensometers for uniaxial testing of metallic materials JB/T 10033-1999 micrometer Use of this specification should be done with the current valid version of the above cited documents.

3 Overview

The calibrator is an instrument used to give a standard displacement to a calibrated extensometer. It consists of a rigid bracket and two coaxial A mandrel or fixture for the card extensometer, a micrometer device capable of accurately measuring the amount of axial displacement along the mandrel to make. The calibrator is divided into Class A and Class B according to the form of micrometer. The structure diagram is shown in Figure 1 and Figure 2. Figure 1 Class A calibrator Figure 2 Class B calibrator Class A calibrators are generally displaced by the micrometer head of the helical substructure, using a micrometer mounted on the calibrator bracket The table (comparator, micrometer or interferometer light pipe, etc.) is measured with a gauge block. Class B calibrators generally use the same micrometer Time to achieve displacement and measurement. ......
