GBZ16656.1009-2010 English PDF

US$414.00 · In stock
Delivery: <= 4 days. True-PDF full-copy in English will be manually translated and delivered via email.
GBZ16656.1009-2010: Industrial automation systems and integration -- Product data representation and exchange -- Part 1009: Application module: Shape appearance and layers
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/Z 16656.1009-2010	414	Add to Cart	4 days	Industrial automation systems and integration -- Product data representation and exchange -- Part 1009: Application module: Shape appearance and layers	Valid

Similar standards

GB/T 38633   GB/T 38666   GB/T 38672   GB/Z 16656.1004   GB/Z 16656.1005   GB/Z 16656.1003

Basic data

Standard ID: GB/Z 16656.1009-2010 (GB/Z16656.1009-2010)
Description (Translated English): Industrial automation systems and integration -- Product data representation and exchange -- Part 1009: Application module: Shape appearance and layers
Sector / Industry: National Standard
Classification of Chinese Standard: L67
Classification of International Standard: 25.040.40
Word Count Estimation: 21,297
Date of Issue: 2011-01-14
Date of Implementation: 2011-05-01
Quoted Standard: GB/T 16262.1; GB/T 16656.46-1998; GB/T 16656.202-2000; GB/Z 16656.1001-2004; GB/Z 16656.1005-2010; GB/Z 16656.1006-2010; GB/Z 16656.1007-2010; GB/Z 16656.1008-2010; ISO 10303-1-1994; ISO 10303-11-1994; ISO 10303-41-2000
Adopted Standard: ISO/TS 10303-1009-2001, IDT
Regulation (derived from): ?National Standard Approval Announcement 2011 No.2
Issuing agency(ies): Ministry of Health of the People's Republic of China
Summary: This standard provides for the appearance of the model, geometrical and topological elements and layers visible property specified application module. This section applies to: assignment appearance layer, appearance of visible assignment attributes, assignment surface color, assignment belongs to the visible property of a surface curve, This section shall not apply to: express appearance model, geometric view definition elements or annotations, appearance model specification.
