GB/T 9109.2-2014: Dynamic measurement of petroleum and liquid petroleum products -- Part 2: Technical requirements of meter installation
Status: Valid

GB/T 9109.2: Historical versions

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 9109.2-2014	299	Add to Cart	3 days	Dynamic measurement of petroleum and liquid petroleum products -- Part 2: Technical requirements of meter installation	Valid
GB/T 9109.2-1988	199	Add to Cart	2 days	Dynamic measurement of crude oil--The technical requirement of displacement meter installation	Obsolete

Similar standards

GB/T 18604 GB/T 21447 GB/T 9109.5 GB/T 43926 GB/T 18603 GB/T 9109.1

Basic data

Standard ID: GB/T 9109.2-2014 (GB/T9109.2-2014)
Description (Translated English): Dynamic measurement of petroleum and liquid petroleum products -- Part 2: Technical requirements of meter installation
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: E98
Classification of International Standard: 75.180.30
Word Count Estimation: 13,197
Date of Issue: 2/19/2014
Date of Implementation: 6/1/2014
Older Standard (superseded by this standard): GB/T 9109.2-1988
Quoted Standard: GB/T 4756; GB/T 9109.1; GB/T 17746; SY/T 5317; SY/T 6682
Regulation (derived from): 2014 National Standards Bulletin No. 2
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China
Summary: This Standard specifies the technical requirements for the design and installation of petroleum and liquid petroleum products dynamic measurement flowmeter system. This Standard applies to merchandise petroleum and liquid petroleum products flowmeter syst

GB/T 9109.2-2014: Dynamic measurement of petroleum and liquid petroleum products -- Part 2: Technical requirements of meter installation

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Dynamic measurement of petroleum and liquid petroleum products.Part 2. Technical requirements of meter installation ICS 75.180.30 E98 National Standards of People's Republic of China Replacing GB/T 9109.2-1988 Petroleum and liquid petroleum products - Dynamic measurement Part 2. Technical requirements for meter installation Part 2. Technicalrequirementsofmeterinstalation Issued on. 2014-02-19 2014-06-01 implementation Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China Standardization Administration of China released

Foreword

GB/T 9109 is divided into four parts. --- GB/T 9109.1 Dynamic measurement of crude oil general principles; --- GB/T 9109.2 Oil and dynamic measurement of liquid petroleum products - Part 2. flowmeter installation technical requirements; --- GB/T 9109.3 dynamic measurement of oil and liquid petroleum products - Part 3. Volume tube mounting technical requirements; --- GB/T 9109.5 Petroleum and liquid petroleum products - Calculation of oil dynamic measurement. This section GB/T 9109 Part 2. This section drafted in accordance with GB/T 1.1-2009 given rules. This Part replaces GB/T 9109.2-1988 "Dynamic measurement of crude oil displacement meter installation technical requirements." This portion GB/T 9109.2-1988 compared to the main changes in the technical content is as follows. --- The standard name was changed to "dynamic measurement of oil and liquid petroleum products - Part 2. Install flowmeter technical requirements"; --- Modify the scope, increase in oil and liquid petroleum products; --- Modify the standard structure, an increase in Chapter 3; --- Increasing the technical requirements for the design and installation of turbine flow meters, Coriolis mass flow meters and ultrasonic flow meters and other measurement systems. This part of the National Oil and Gas Standardization Technical Committee (SAC/TC355) and focal points. This section is drafted. a large national oil and gas flow metering stations. The main drafters of this section. Luo Yang again, Gao Jun, Chen Liang, Ruanzeng Rong, Bao-right, Zhao Chenghai. This section replaces the following previously issued as follows. --- GB/T 9109.2-1988. Petroleum and liquid petroleum products - Dynamic measurement Part 2. Technical requirements for meter installation

1 Scope

This section GB/T 9109 provisions of the Petroleum and liquid petroleum products - Dynamic measurement meter systems design and installation techniques Claim. This section applies to goods of petroleum and liquid petroleum products meter systems design and installation, non-commercial oil and liquid petroleum products Product meter systems design and installation can use the reference.

2 Normative references

The following documents for the application of this document is essential. For dated references, only the dated version suitable for use herein Member. For undated references, the latest edition (including any amendments) applies to this document. GB/T 4756 petroleum liquids hand sampling method GB/T 9109.1 Dynamic measurement of crude oil general principles GB/T 17746 Petroleum liquids and gases dynamic measuring electric and (or) electronic pulse fidelity and reliability of data transmission cables SY/T 5317 petroleum liquids pipeline automatic sampling SY/T 6682 liquid hydrocarbon flow measurement with Coriolis flowmeters

3 General requirements

3.1 Construction principle flowmeter for custody transfer measurement metering station shall comply with GB/T 9109.1. 3.2 meter level of accuracy for custody transfer measurement shall not be less than 0.2. 3.3 meter systems design, installation should meet the following requirements. a) easy access, observation and operation, providing a dedicated platform and ladder, if necessary; b) avoid the heat, place strong vibration; c) avoid electrostatic interference, electromagnetic interference and noise, when can not be avoided, it should take appropriate static interference, electromagnetic interference and noise Measures sound interference; D) When a non-waterproof meter located outdoors, the instrument should be installed in a protective case; e) non-Ex instrument when used in explosion risk areas, should be installed in the positive pressure meter cabinet or take other measures to explosion, and comply with the relevant Explosion-proof specifications. Design pressure of 3.4 meter and auxiliary equipment shall not be less than the maximum working pressure metering system design temperature should not be lower than the measured oil Maximum temperature. 3.5 flowmeter system design, installation, insulation should be taken on the instrument and process oil pipeline based on the measured physical and environmental characteristics, Anti-corrosion and anti-vibration measures.

4 System Design

4.1 meter 4.1.1 Select the meter and ancillary equipment, the meter manufacturer should consult and consider the following. ......
