GB/T 6563-2014: Hexagon head thread rolling screws
Status: Valid

GB/T 6563: Historical versions

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 6563-2014	169	Add to Cart	3 days	Hexagon head thread rolling screws	Valid
GB/T 6563-1986	199	Add to Cart	2 days	Hexagon head thread forming screws	Obsolete

Similar standards

GB/T 6187.2   GB/T 6187.1   GB/T 6185.2   GB/T 6561   GB/T 6562   GB/T 6560

Basic data

Standard ID: GB/T 6563-2014 (GB/T6563-2014)
Description (Translated English): Hexagon head thread rolling screws
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: J13
Classification of International Standard: 21.060.10
Word Count Estimation: 7,750
Date of Issue: 6/24/2014
Date of Implementation: 3/1/2015
Older Standard (superseded by this standard): GB/T 6563-1986
Quoted Standard: GB/T 90.1; GB/T 90.2; GB/T 1237; GB/T 3098.7; GB/T 3103.1; GB/T 5267.1; GB/T 5267.2; GB/T 5276; GB/T 5779.1; GB/T 5783; GB/T 6559; GB/T 16938
Regulation (derived from): National Standards Bulletin No. 14 of 2014
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China
Summary: This standard provides the specifications for the M2 ~ M12 thread hex head rolling screws. This standard applies to hexagonal head rolling screws.

GB/T 6563-2014: Hexagon head thread rolling screws

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Hexagon head thread rolling screws ICS 21.060.10 J13 National Standards of People's Republic of China Replacing GB/T 6563-1986 Hexagon head screw extrusion Issued on. 2014-06-24 2015-03-01 implementation Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China Standardization Administration of China released

Foreword

The standard is "rolling screws" one national standard series. The series of standards include. --- GB/T 6560 Cross recessed pan head screw extrusion; --- GB/T 6561 Cross recessed countersunk head screw extrusion; --- GB/T 6562 Cross recessed countersunk head screw extrusion; --- GB/T 6563 Hexagon head screw extrusion; --- GB/T 6564.1 Hexagon flower-shaped cylinder head rolling screws; --- GB/T 6564.2 within the hexagonal-shaped flower pan head screw extrusion; --- GB/T 6564.3 Hexagon flower-shaped countersunk head screw extrusion; --- GB/T 6564.4 within the hexagonal-shaped flower countersunk head rolling screws. This standard was drafted in accordance with GB/T 1.1-2009 given rules. This standard replaces GB/T 6563-1986 "hex head self-tapping screws." This standard and GB/T 6563-1986 compared to the main changes are as follows. --- Modify the standard name; --- Specify the type size of the screw head and GB/T 5783 the same (see Chapter 3); --- To increase the size of a predetermined shape and non-threaded shank (see Chapter 3); --- Increase in thread sizes M2, M2.5, M3 and M4 (see Table 1); --- Adjustment screw length and preferred length range (see Table 1); --- Implementing GB/T 3098.7-2000 Cancel "performance rating" provisions (see Table 2); --- Increase the reference GB/T 16938 (see Table 2); --- Increase in non-electrolytic zinc flake coating surface treatment (see Table 2). The standard proposed by China Machinery Industry Federation. This standard by the National Standardization Technical Committee fasteners (SAC/TC85) centralized. This standard is drafted by. Productivity Promotion Center in the machine. This standard replaces the standards previously issued as follows. --- GB/T 6563-1986. Hexagon head screw extrusion

1 Scope

This standard provides the specifications for the M2 ~ M12 thread hex head rolling screws. This standard applies to hexagonal head rolling screws.

2 Normative references

The following documents for the application of this document is essential. For dated references, only the dated version suitable for use herein Member. For undated references, the latest edition (including any amendments) applies to this document. GB/T 90.1 Fasteners acceptance inspection GB/T 90.2 Fasteners marking and packaging GB/T 1237 marking method fasteners GB/T 3098.7 Mechanical properties of fasteners rolling screws GB/T 3103.1 Tolerances for fasteners - Bolts, screws, studs and nuts GB/T 5267.1 fasteners plating layer GB/T 5267.2 fasteners non-electrolytic zinc flake coating GB/T 5276 Fasteners Bolts, screws, studs and nuts - Symbols and designations size GB/T 5779.1 Fasteners - Surface discontinuities - Bolts, screws and studs for general requirements GB/T 5783 full thread hex head bolts GB/T 6559 self-tapping screw locking screw coarse thread series GB/T 16938 Fasteners Bolts, screws, studs and nuts conditions

3 Dimensions

Size code and labeling are in line with GB/T 5276. Screw type dimensions shown in Figure 1 and Table 1. Screw head type size and GB/T 5783 the same basic dimensions. When the entire system is not out of the screw thread, which can be made without threaded shank diameter equal to or smaller than the diameter of the circumscribed circle of the cylindrical or three prism (See GB/T 6559). ......
