GB/T 5600-2018 English PDF

US$268.00 · In stock
Delivery: <= 1 days. True-PDF full-copy in English will be manually translated and delivered via email.
GB/T 5600-2018: General technical specification for railway freight car
Status: Valid

GB/T 5600: Historical versions

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 5600-2018	268	Add to Cart	1 days	General technical specification for railway freight car	Valid
GB/T 5600-2006	719	Add to Cart	3 days	General technical specification for railway freight car	Obsolete
GB/T 5600-1997	RFQ	ASK	3 days	General technical specification for freight cars	Obsolete
GB/T 5600-1985	199	Add to Cart	2 days	General technical specification for freight cars	Obsolete

Similar standards

TB/T 3548   GB/T 12817   GB/T 7928   GB/T 5601   GB/T 10478

Basic data

Standard ID: GB/T 5600-2018 (GB/T5600-2018)
Description (Translated English): General technical specification for railway freight car
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: S52
Classification of International Standard: 45.060.20
Word Count Estimation: 22,259
Date of Issue: 2018-06-07
Date of Implementation: 2019-01-01
Issuing agency(ies): State Administration for Market Regulation, China National Standardization Administration

GB/T 5600-2018: General technical specification for railway freight car

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
General technical specification for railway freight car ICS 45.060.20 S52 National Standards of People's Republic of China Replace GB/T 5600-2006 General technical conditions for railway wagons Published on.2018-06-07 2019-01-01 implementation State market supervision and administration China National Standardization Administration issued

Content

Foreword III Introduction IV 1 Scope 1 2 Normative references 1 3 General requirements 2 4 Material Requirements 2 5 Manufacturing requirements 3 5.1 Process Requirements 3 5.2 Car body 3 5.3 bogie 3 5.4 Brake device 3 5.5 coupler buffer device 3 5.6 Vehicle completion 3 6 Painting and signing 4 7 Vehicle type requirements 4 Appendix A (Normative Appendix) Safety Technical Requirements for Railway Freight Cars 5 Appendix B (normative appendix) Technical requirements for open, shed and flat car 8 Appendix C (Normative Appendix) General Technical Requirements for Tank Cars 10 Appendix D (Normative Appendix) Technical Requirements for Mechanical Refrigerators 14 Appendix E (Normative Appendix) Technical Requirements for Other Vehicle Types 16

Foreword

This standard was drafted in accordance with the rules given in GB/T 1.1-2009. This standard replaces GB/T 5600-2006 "General Technical Conditions for Railway Freight Cars". Compared with GB/T 5600-2006, except for editorial repair The main technical changes changed are as follows. --- Revised the scope of application of the standard (see Chapter 1, Chapter 1 of the.2006 edition); --- Increased the requirements for trucks that need to enter the defrosting warehouse (see 3.2, 3.2 of.2006 edition); --- Increased the work pressure requirements of train supervisors (see 3.3); --- Modify the scope of application through vehicle reducers and mechanized hump vehicles (see 3.13, 3.12 of the.2006 edition); --- Increased the vehicle should have an electrostatic discharge function (see 3.14); --- Increased interface size requirements (see 3.15); --- Clarified the specific requirements of aluminum alloy and stainless steel (see 4.4, 4.3 edition of.2006); --- Increased requirements for rubber elastic components (see 4.6); --- Increased the basic requirements for welding and riveting of truck manufacturing (see 5.1.1, 5.1.2); --- Revised the standard for the implementation of general technical requirements for bogies (see 5.3, 5.2.2,.2006 edition); --- Increased brake component requirements (see 5.4.3, 5.4.4); --- Revised the requirements for vehicle markings (see Chapter 6, Chapter 6 of the.2006 edition); --- Added the normative appendix "Technical Requirements for Vehicle Safety" (see Appendix A); --- Revised the structural requirements for gondola cars, box cars, and flat cars (see B.1,.2006 edition of A.2); --- Revised the steel structure requirements of the car body [see B.2.1b),.2006 edition of A.3.1]; --- Removed the manufacturing requirements for the end and side doors of the flat car (see A.3.6, A.3.7 and A.3.8 of the.2006 edition); ---Modified the manufacturing requirements for container flat cars (see B.2.12, B.3.2 of.2006 edition); --- Removed the requirements for home storage (avian) vehicles (see B.5 of.2006 edition); --- Removed the requirements for the pillow device of the tanker (see C.3.4 for the.2006 edition). This standard is proposed and managed by the National Railway Administration. This standard is mainly drafted by. Institute of Standard Metrology of China Railway Science Research Institute, CRRC Changjiang Vehicle Co., Ltd., Zhongqi Qiqiha Vehicle Co., Ltd., CRRC Meishan Vehicle Co., Ltd., CRRC Beijing Erqi Vehicle Co., Ltd., CRRC Xi'an Vehicle Co., Ltd., Zhongchetai Original Locomotive Vehicle Co., Ltd., CRRC Qingdao Sifang Vehicle Research Institute Co., Ltd. The main drafters of this standard. Gao Junli, Lei Qingping, He Maosheng, Lin Jieliang, Zhang Simei, Wang Zhiming, Liu Wensheng, Tian Yishuan, Liu Yuyuan, Song Rui. The previous versions of the standards replaced by this standard are. ---GB/T 5600-1985, GB/T 5600-1997, GB/T 5600-2006.

Introduction

In the railway technical standard system, in addition to GB/T 5600 "General Technical Conditions for Railway Freight Cars", TB/T 1667-1985 "Design parameters of car body", TB/T 1668-1985 "Design parameters of coal hopper car body", TB/T 1788- 1986 "Changer Car Body Design Parameters", TB/T 1950-1987 "Railway Tank Car Body Design Parameters", TB/T 2039-1989 "Railway General "Plane car body design parameters", TB/T 2835-1997 "Basic requirements for railway heavy-duty trucks" and TB1560-2002 "trucks General regulations for all technologies. According to the railway standard series integration plan, GB/T 5600 merges and revise the above standard contents. This standard does not refer to the structure and the use of trucks with special requirements (such as. long cargo vehicles, liquefied gas railway tankers), some of the provisions of this standard For trucks with special requirements, the structure and the use of trucks with special requirements can be referred to. General technical conditions for railway wagons

1 Scope

This standard specifies the general requirements, material requirements, manufacturing requirements, painting and marking of standard gauge railway trucks. This standard applies to standard gauge new railroads with a maximum operating speed of less than or equal to 120km/h and an axle weight of less than or equal to 30t. car. For newly-built railway wagons with a maximum running speed of more than 120km/h and a major shaft of 30t or special requirements for structure and operation, please refer to carried out.

2 Normative references

The following documents are indispensable for the application of this document. For dated references, only dated versions apply to this article. Pieces. For undated references, the latest edition (including all amendments) applies to this document. GB 146.1 standard gauge railway locomotive vehicle limit GB/T 699 high quality carbon structural steel GB/T 700 carbon structural steel GB/T 702 hot rolled steel bar size, shape, weight and tolerance GB/T 1591 low alloy high strength structural steel GB 4806.10 National food safety standards for food contact coatings and coatings GB/T 5599 Railway Vehicle Dynamics Performance Evaluation and Test Identification Specification GB/T 25024 railway truck two-axle bogie general technical conditions GB/T 25343 (all parts) Welding of railway applications rail vehicles and their components GB/T 28791 railway vehicle sign GBZ 230 Occupational exposure to toxicant hazard classification NB/T 47013 (all parts) Non-destructive testing of pressure equipment NB/T 47014 Pressure welding equipment welding process evaluation Brake hose connector for TB/T 60 rolling stock TB/T 456 Rail vehicle with hook and hook frame TB/T 493 railway vehicle coupler cushioning device assembly technical conditions TB/T 1335 Railway Vehicle Strength Design and Test Identification Specification TB/T 1558 (all parts) Non-destructive testing of welds on rolling stock TB/T 1808 railway mechanical refrigerated truck electrical device and refrigeration heating device TB/T 1900 railway vehicle storage cylinder TB/T 1961 railway vehicle bumper TB/T 1979 weather-resistant steel for railway vehicles TB/T 2206 Type 103/104 air distribution valve rubber parts for vehicles TB/T 2231.2 Railway vehicle braking systems - Part 2. Trucks General technical requirements for rubber elastic components for TB/T 2843 rolling stock TB/T 2911 Technical conditions for the riveting of railway vehicles TB/T 2942 General technical requirements for steel castings for rolling stock ......
