GB/T 5584.4-2020: Rectangular copper or aluminium and its alloy wires for electrical purposes - Part 4: Strip copper conductor
Status: Valid

GB/T 5584.4: Historical versions

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 5584.4-2020	129	Add to Cart	3 days	Rectangular copper or aluminium and its alloy wires for electrical purposes - Part 4: Strip copper conductor	Valid
GB/T 5584.4-2009	399	Add to Cart	3 days	Rectangular copper or aluminium and its alloy wires for electrical purposes -- Part 4: Strip copper conductor	Obsolete
GB/T 5584.4-1985	239	Add to Cart	2 days	Rectangular copper or aluminium and its alloy conductors for electrical purposes--Part 4: Copper strip	Obsolete

Similar standards

GB/T 4910 GB/T 5585.2 GB/T 5585.1 GB/T 5584.2 GB/T 5584.1 GB/T 5584.3

Basic data

Standard ID: GB/T 5584.4-2020 (GB/T5584.4-2020)
Description (Translated English): Rectangular copper or aluminium and its alloy wires for electrical purposes - Part 4: Strip copper conductor
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: K11
Classification of International Standard: 29.060.10
Word Count Estimation: 7,770
Date of Issue: 2020-12-14
Date of Implementation: 2021-07-01
Older Standard (superseded by this standard): GB/T 5584.4-2009
Quoted Standard: GB/T 3048.2; GB/T 4340.1; GB/T 4909.2; GB/T 4909.3; GB/T 4909.6; GB/T 5584.1-2020; GB/T 5121.1; GB/T 5121.2; GB/T 5121.3; GB/T 5121.4; GB/T 5121.5; GB/T 5121.6; GB/T 5121.7; GB/T 5121.8; GB/T 5121.9; GB/T 5121.10; GB/T 5121.11; GB/T 5121.12; GB/T 5121.13
Regulation (derived from): National Standard Announcement No. 28 of 2020
Issuing agency(ies): State Administration for Market Regulation, China National Standardization Administration
Summary: This standard specifies the technical requirements, test and inspection rules, and delivery requirements for electrical copper strips. This standard applies to copper strips for electricians.

GB/T 5584.4-2020: Rectangular copper or aluminium and its alloy wires for electrical purposes - Part 4: Strip copper conductor

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
(Copper, aluminum and its alloy rectangular wires for electrical purposes-Part 4: Copper tape) ICS 29:060:10 K11 National Standards of People's Republic of China Replace GB/T 5584:4-2009 Copper, aluminum and its alloy flat wires for electrical purposes Part 4: Copper Strip 2020-12-14 release 2021-07-01 implementation State Administration for Market Regulation Issued by the National Standardization Management Committee

Preface Ⅲ 1 Scope 1 2 Normative references 1 3 Technical requirements 1 4 Test and inspection rules 3 5 Delivery requirements 4

Foreword

GB/T 5584 "Copper, Aluminum and Its Alloy Flat Wire for Electrical Engineering" is divided into four parts: ---Part 1: General provisions; ---Part 2: Copper and its alloy flat wire; ---Part 3: Aluminum flat wire; ---Part 4: Copper tape: This part is Part 4 of GB/T 5584: This section was drafted in accordance with the rules given in GB/T 1:1-2009: This part replaces GB/T 5584:4-2009 "Copper, aluminum and its alloy flat wires for electrical purposes-Part 4: Copper strip", and GB/T 5584:4- The main technical changes compared to:2009 are as follows: ---Added the technical requirements of phosphorus deoxidized copper TP1DR (see Chapter 3); ---Added the Vickers hardness requirement of copper strip (see 3:6); ---Modified the size range of copper strip (see 3:2, 5:2 of the:2009 edition); ---Deleted the specification of copper strip (see Chapter 5 of the:2009 edition): This part was proposed by China Electrical Equipment Industry Association: This part is under the jurisdiction of the National Bare Wire Standardization Technical Committee (SAC/TC422): Drafting organizations of this section: Shanghai Cable Research Institute Co:, Ltd:, Shanghai National Cable Testing Center Co:, Ltd:, Chongqing Pigeon Brand Wire and Cable Co:, Ltd: Company, Zhongtian Alloy Technology Co:, Ltd:, Hangzhou Cable Co:, Ltd:, Shanghai Pudong Wire and Cable (Group) Co:, Ltd:, Wuxi Tongli Power Industrial Co:, Ltd:, Wuxi Xizhou Magnet Wire Co:, Ltd:, Zhejiang Libo Industrial Co:, Ltd:, Shandong Jinyuan Copper Co:, Ltd:, Global Energy Internet Research Institute Co:, Ltd: Drafters of this section: Cai Xichuan, Ding Zhenpei, Zhang Yongjia, Pang Xiaoming, Zhang Da, Hu Jianming, Chen Wei, Zhang Hengguang, Cao Yongyi, Xu Gaolei, Zhao Ruhai, Zhu Zhixiang and Chen Xin: The previous versions of the standards replaced by this part are as follows: ---GB/T 5584:4-1985, GB/T 5584:4-2009: Copper, aluminum and its alloy flat wires for electrical purposes Part 4: Copper Strip

1 Scope

This part of GB/T 5584 specifies the technical requirements, test and inspection rules, and delivery requirements for electrical copper strips: This section applies to copper strips for electricians:

2 Normative references

The following documents are indispensable for the application of this document: For dated reference documents, only the dated version applies to this article Pieces: For undated references, the latest version (including all amendments) applies to this document: GB/T 3048:2 Test methods for electrical properties of wires and cables Part 2: Resistivity test of metallic materials GB/T 4340:1 Vickers hardness test of metallic materials Part 1: Test method GB/T 4909:2 Bare Wire Test Method Part 2: Dimension Measurement GB/T 4909:3 Test Method for Bare Wire Part 3: Tensile Test GB/T 4909:6 Test method for bare wires-Part 6: Bend test unidirectional bending GB/T 5121 (all parts) Methods for chemical analysis of copper and copper alloys GB/T 5584:1-2020 Copper, aluminum and its alloy rectangular wires for electrical purposes Part 1: General provisions

3 Technical requirements

3:1 Chemical composition The chemical composition of the copper strip should meet the requirements of Table 1: Table 1 Chemical composition of copper strip Product Category Mass score/% Cu Ag, not less than P TDR, TDY1, TDY2 99:90- TP1DR 99:90 0:004~0:012 Note: When the chemical composition has special requirements, the supplier and the buyer shall negotiate and determine: 3:2 Dimensions and deviations 3:2:1 The size range of copper strip is: ---Narrow side size: 0:30mm≤a≤3:55mm; ---Wide side size: 9:00mm≤b≤100:00mm: 3:2:2 The size and deviation of the narrow side a and wide side b of the copper strip shall meet the requirements of Table 2: ......
