GB/T 5273-2016: Dimensional standardisation of terminals for high-voltage apparatus
Status: Valid

GB/T 5273: Historical versions

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 5273-2016	279	Add to Cart	3 days	Dimensional standardisation of terminals for high-voltage apparatus	Valid
GB/T 5273-1985	399	Add to Cart	3 days	Terminals for transformers, high-voltage apparatus and bushings	Obsolete

Similar standards

GB/T 11022 GB/T 3906 GB/T 30092 GB/T 1984 GB/T 1985

Basic data

Standard ID: GB/T 5273-2016 (GB/T5273-2016)
Description (Translated English): Dimensional standardisation of terminals for high-voltage apparatus
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: K43
Classification of International Standard: 29.120.30
Word Count Estimation: 14,173
Date of Issue: 2016-04-25
Date of Implementation: 2016-11-01
Older Standard (superseded by this standard): GB/T 5273-1985
Regulation (derived from): National Standard Announcement No
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China

GB/T 5273-2016: Dimensional standardisation of terminals for high-voltage apparatus

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Dimensional standardisation of terminals for high-voltage apparatus ICS 29.120.30 K43 National Standards of People's Republic of China Replace GB/T 5273-1985 High voltage electrical terminal size standardization (IEC /T R62271-301..2009, High-voltageswitchgearandcontrolgear- Part 301. Dimensionalstandardisationofhigh-voltageterminals, MOD) 2016-04-25 released 2016-11-01 implementation General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China China National Standardization Management Committee released Directory Preface I 1 Overview 1 1.1 Scope 1 1.2 Normative references 2 2 terms and definitions 2 3 type and size 2 3.1 screw terminal 2 3.2 cylindrical terminal 3 3.3 Board terminal 3 3.4 screw-shaped terminal 8 Technical requirements 8 4.1 Material 8 4.2 Electrical performance 9 4.3 Mechanical properties 9 4.4 Surface treatment 9 4.5 Temperature rise 9 4.6 Factory 9 Reference 10

Foreword

This standard is drafted in accordance with the rules given in GB/T 1.1-2009. This standard replaces GB/T 5273-1985 "Terminals for transformers, high voltage electrical appliances and sleeves". The main technical differences between this standard and GB/T 5273-1985. - Terminals are removed from the terms and definitions, with high voltage terminals and terminal connectors added (see Chapter 2); - modify the dimensions of the terminal (see 1985 version 3.2) by modifying the dimensions in the type and size, such as a2 (see 3.3); - Removed single-hole type terminals in type and size (see 1985 version 3.2), with screw-shaped terminals and 16-hole plate terminals (See 3.3); - The recommended value of the connection terminal size and its connection method for the rated current selection is given in Appendix A and Appendix B "Terminals (See Appendix A, Appendix B, 1985). This standard uses the re-drafting method to modify the use of IEC /T R62271-301..2009 "High Voltage Switchgear and Control Equipment Part 301 Points. high-voltage terminal size standardization. " The main technical differences between this standard and IEC /T R62271-301..2009. - to increase the normative reference documents GB/T 14315-2008, GB 50149-2010; --- According to China's actual, in the type and size of the screw-shaped terminals, screw-shaped terminals and sixteen-hole plate-shaped terminals; - according to our actual situation, in the plate-shaped terminal to increase the hole center to the edge of the vertical recommended size a1, hole center to the root of the longitudinal Size a2; --- According to China's reality, in some of the board-shaped terminal to increase the size of φ18 × 60; --- According to China's needs, an increase of "Chapter 4 technical requirements." This standard has made the following editorial changes. --- Standard name is changed from "High voltage switchgear and control equipment Part 301. High voltage terminal size standardization" to "High voltage electrical appliances Terminal size standardization ". This standard is proposed by China Electrical Equipment Industry Association. This standard by the National High Voltage Switchgear Standardization Technical Committee (SAC/TC65) centralized. This standard is responsible for drafting units. Pinggao Group Co., Ltd. This standard participates in the drafting unit. Xi'an High Voltage Electric Appliance Research Institute Co., Ltd., Xi'an Xidian Switch Electric Co., Ltd., Huayi Electric Co., Ltd., Beijing Branch Rui Power Distribution Automation Co., Ltd., the new Northeast Electric Group High Voltage Switch Co., Ltd., Cooper (Ningbo) Co., Ltd., Fujian Zhongneng Electric Co., Ltd., Zhejiang Switchgear Co., Ltd., Henan Senyuan Electric Co., Ltd., Beijing Beikai Electric Co., Ltd., Qingdao Terui De Electric Co., Ltd., Shandong Taikai High Voltage Switchgear Co., Ltd., Jiangsu Huaguan Electric Group Limited company, Yihe Electric Group Co., Ltd. The main drafters of this standard. Yan Guanxing, Zhao Hongfei, Tian Enwen, Yao Fengjuan, Zhang Shi, Wu Hongyan, Yan Zhaizheng, Xu Hongchun, Wang Xiangke, Li Xiju, Li Jianhua, Liu Xinbo, Zhu Cunchun, Hou Yishun, Ye Zubiao, Zhang Shu, Liu Chengxue, Wang Tongzhi, Zhou Qingqing, Liu Yang, Yin Hongyan, Xin Jing, Li Zhonghua, Zheng Yunbo, Kong Xiangchong. This standard replaced the previous version of the standard release. --- GB/T 5273-1985. High voltage electrical terminal size standardization

1 Overview

1.1 Scope This standard specifies the type and size and technical requirements of high voltage electrical terminals. This standard applies to indoor and outdoor voltage of 3000V and above the system of high-voltage electrical high-voltage terminals. But do not rule it out Applies to other devices. This standard does not provide a fit between the terminal size and the rated current. This standard applies primarily to the following equipment. --- Power transformers (including their low side terminals); --- casing (including through the wall casing, high voltage switchgear and transformer casing, etc.); High voltage circuit breaker --- high voltage isolating switch; --- high pressure load switch; --- high voltage grounding switch; --- bypass switch; High pressure automatic recloser; --- high-pressure automatic segmentation device; High voltage fuses --- high voltage load switch - fuse combination of electrical appliances; --- high voltage contactor - fuse combination of electrical appliances; --- metal-enclosed switchgear; High voltage/low voltage preloaded substation; Gas insulated metal - enclosed switchgear (GIS); --- composite combination of electrical (H-GIS); --- Open combination (C-AIS); --- metal enclosed bus; --- cable distribution box; --- current transformer (not including its secondary terminal); --- current limiting reactor and so on. This standard also applies to the following equipment. Grounding switch, power capacitor, arrester and high voltage contactor; --- other transformers other than power transformers (eg electric furnace transformers, rectifier transformers, test transformers, etc.), voltage transformers, and Joint reactor --- protection of voltage transformers and power capacitors of high-voltage fuses; High voltage power cable. Note. The DC switchgear, ground and only for the use of potential connection terminals are also applicable to this standard. High-voltage power cable conductor with pressure-type copper, aluminum terminals included in the GB/T 14315-2008, the electrical installation of engineering bus The terminals are included in GB 50149-2010. Where the special requirements beyond the scope of this standard, by the user consultation with the manufacturer. ......
