GB/T 4678.18-2024: Die casting dies - Components - Part 18: Support pillars
Status: Valid

GB/T 4678.18: Historical versions

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 4678.18-2024	209	Add to Cart	3 days	Die casting dies - Components - Part 18: Support pillars	Valid
GB/T 4678.18-2003	139	Add to Cart	2 days	Die-casting die components -- Part 18: Support pillar	Valid

Similar standards

GB/T 45677   GB/T 6110   JB/T 3943   GB/T 4678.20   GB/T 4678.17   GB/T 4678.16

Basic data

Standard ID: GB/T 4678.18-2024 (GB/T4678.18-2024)
Description (Translated English): Die casting dies - Components - Part 18: Support pillars
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: J46
Classification of International Standard: 25.120.30
Word Count Estimation: 10,172
Date of Issue: 2024-09-29
Date of Implementation: 2025-04-01
Older Standard (superseded by this standard): GB/T 4678.18-2003
Issuing agency(ies): State Administration for Market Regulation, China National Standardization Administration

GB/T 4678.18-2024: Die casting dies - Components - Part 18: Support pillars

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Die casting dies - Components - Part 18.Support pillars Die casting parts Part 18.Support columns ICS 25.120.30 CCS J 46 National Standard of the People's Republic of China Replaces GB/T 4678.18-2003 Released on 2024-09-29 2025-04-01 Implementation State Administration for Market Regulation The National Standardization Administration issued

Foreword

This document is in accordance with the provisions of GB/T 1.1-2020 "Guidelines for standardization work Part 1.Structure and drafting rules for standardization documents" Drafting is required. This document is part 18 of GB/T 4678 "Die casting parts". GB/T 4678 has been published as follows. Part 1.Template;- Part 2.Circular inserts;- Part 3.Rectangular inserts;- Part 4.Square guide posts; Part 5.Circular guide cylinders; Part 6.Guide bushings with head; Part 7.Straight guide bushings; Part 8.Push Plate;- Part 9.Push plate guide column; Part 10.Push plate guide bushing; Part 11.Push rods;- Part 12.Reset rod;- Part 13.Push plate washers; Part 14.Stopping pins; - Part 15.Spacers;- Part 16.Flat push rods; Part 17.Push tube; Part 18.Support columns; Part 19.Positioning elements. - This document replaces GB/T 4678.18-2003 "Die casting die parts Part 18.Support column". Compared with GB/T 4678.18-2003, In addition to structural adjustments and editorial changes, the main technical changes are as follows. Added C-type support column (see 4.3); a) The dimension series in Table 1 and Table 2 have been adjusted, and the range of values for dimensions such as D and L has been expanded (see Table 1 and Table 2,.2003 edition). Table 1, Table 2). b) Please note that some of the contents of this document may involve patents. The issuing organization of this document does not assume the responsibility for identifying patents. This document is proposed and coordinated by the National Technical Committee for Mould Standardization (SAC/TC 33). This document was drafted by. Ningbo Junling Mould Technology Co., Ltd., Ningbo Heli Technology Co., Ltd., Guangzhou Cavity Mould Manufacturing Co., Ltd., Ningbo Xinda Mould Manufacturing Co., Ltd., Ningbo Beilun Liaoyuan Mould Casting Co., Ltd., Ningbo Jinlin Precision Machinery Co., Ltd., Ningbo Xusheng Group Co., Ltd., Ningbo Xunhui Electric Co., Ltd., Dalian Yaming Auto Parts Co., Ltd., Chongqing Yujiang New High Mould Co., Ltd., Tianjin Norinco Precision Electronics Co., Ltd., Ningbo Yongjie Mould Co., Ltd., Guilin Electric Science Research Institute Co., Ltd. manage. The main drafters of this document are. Hu Ning'an, Liu Yongyue, He Chiling, He Kaiming, Li Guanghao, Wang Xueliang, Ma Huanxiang, Lu Ruhui, Fang Jianru, Chen Jianwei, Hong Zhengping, Du Jianjie, Li Yongfei, Yao Xianjun, Shi Dingwei, Hu Lianmao, Lin Chunyu, Li Chuquan, Zhou Dibo, Wang Xifu, Lu Chao, Fang Haocheng. The previous versions of this document and the documents it replaces are as follows. First published in.2003 as GB/T 4678.18-2003; This is the first revision. -

Introduction

The series of standards for die casting parts are the basic technical documents for the design, manufacture, inspection and acceptance of die casting parts. The purpose of the formulation of the "Die Casting Parts" is to unify the basic structure and specifications of die casting parts, standardize their technical requirements, and improve the quality of domestic die casting parts. Product quality and standard parts utilization rate, reduce production costs. Due to the large number of parts types, according to the number of typical parts of the die casting mold GB/T 4678 is divided into the following 19 parts. Part 1.Template;- Part 2.Circular inserts;- Part 3.Rectangular inserts;- Part 4.Square guide posts; Part 5.Circular guide cylinders; Part 6.Guide bushings with head; Part 7.Straight guide bushings; Part 8.Push Plate;- Part 9.Push plate guide column; Part 10.Push plate guide bushing; Part 11.Push rods;- Part 12.Reset rod;- Part 13.Push plate washers; Part 14.Stopping pins; - Part 15.Spacers;- Part 16.Flat push rods; Part 17.Push tube; Part 18.Support columns; Part 19.Positioning elements. - Each part specifies the structure, technical requirements, material requirements, marking, etc. of one of the parts. According to the requirements, refer to the corresponding parts to design and manufacture die-casting mold parts. GB/T 4678 was first issued in 1984 and was revised and supplemented for the first time in.2003 according to the needs of the development of the die-casting mold industry. In recent years, with the development of my country's industry and economy, the design and manufacturing technology of large, precise, complex and other high-end die-casting molds has become more and more mature. At the same time, with the application of new materials and new processes and the requirements of international standards brought about by mold exports, the basic size system of die-casting mold parts has been There have been changes in the series, accuracy requirements, marking, packaging, etc. The National Technical Committee on Mould Standardization completed Part 1 to Part 16 and Part 17 of GB/T 4678 from.2017 to 2023. This revision is part 18 of GB/T 4678, which is revised to make it It reflects the latest mature technology content of the die casting mold industry in a timely and comprehensive manner, and is coordinated with other revised die casting mold parts standards to provide a comprehensive and comprehensive support for the die casting industry. It is of great significance to the technological progress and industrial upgrading of the industry. Die casting parts Part 18.Support columns

1 Scope

This document specifies the types and dimensions, materials, technical requirements and markings of support columns for die casting moulds. This document applies to the design and manufacture of support columns for die casting molds.

2 Normative references

The contents of the following documents constitute the essential clauses of this document through normative references in this document. For referenced documents without a date, only the version corresponding to that date applies to this document; for referenced documents without a date, the latest version (including all amendments) applies. in this document. GB/T 1800.1-2020 Product Geometrical Technical Specification (GPS) Linear Dimension Tolerance ISO Code System Part 1.Tolerance The basis of difference, deviation and fit GB/T 4679 Technical requirements for die casting parts

3 Terms and definitions

There are no terms or definitions that require definition in this document.

4 Type and size

4.1 The type of support column A shall be in accordance with Figure 1 and the dimensions shall conform to the values given in Table 1. Surface roughness in microns Dimensions in millimeters The roughness Ra of the unfilled surface should be 3.2 μm. Figure 1 A-type support column ......
