GB/T 45541-2025 English PDF

US$519.00 · In stock
Delivery: <= 5 days. True-PDF full-copy in English will be manually translated and delivered via email.
GB/T 45541-2025: Testing method for proton exchange membrane electrolyzer performance
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 45541-2025	519	Add to Cart	5 days	Testing method for proton exchange membrane electrolyzer performance	Valid

Similar standards

GB/T 44262   GB/T 44244   GB/T 45027   GB/T 45539   GB/T 43674

Basic data

Standard ID: GB/T 45541-2025 (GB/T45541-2025)
Description (Translated English): Testing method for proton exchange membrane electrolyzer performance
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: F19
Classification of International Standard: 27.010
Word Count Estimation: 26,289
Date of Issue: 2025-03-28
Date of Implementation: 2025-07-01
Issuing agency(ies): State Administration for Market Regulation, China National Standardization Administration

GB/T 45541-2025: Testing method for proton exchange membrane electrolyzer performance

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
GB/T 45541-2025 English version. Testing method for proton exchange membrane electrolyzer performance ICS 27.010 CCSF19 National Standard of the People's Republic of China PEM electrolyzer performance test method Released on 2025-03-28 2025-07-01 Implementation State Administration for Market Regulation The National Standardization Administration issued

Table of Contents

Preface III 1 Scope 1 2 Normative references 1 3 Terms and Definitions 1 4 Basic Check 1 5 Basic Test 2 5.1 Strength Test 2 5.2 Air tightness test 2 5.3 Leakage rate test 3 5.4 Internal channeling test 3 5.5 Power-on test 4 5.6 Temperature test 4 6 Performance Test 4 6.1 Test conditions 4 6.2 Test equipment 5 6.3 Hydrogen production flow 5 6.4 Oxygen in Hydrogen/Hydrogen in Oxygen 6 6.5 Gas purity 6 6.6 Hydrogen production pressure 7 6.7 Current and Voltage 7 6.8 Rated input power of electrolyzer 8 6.9 DC power consumption 8 6.10 Power adjustment range 8 6.11 Load change rate 9 6.12 Cold start time and hot start time 9 6.13 Decay rate 10 6.14 Pressure/pressure difference 11 6.15 Single Electrolytic Cell 11 7 Test Report 11 Appendix A (Informative) Blow-by velocity calculation formula 12 Appendix B (Informative) Current-voltage test data record table 13 Appendix C (Informative) Single Electrolytic Cell for Testing 14 C.1 Single electrolytic cell structure and flow field 14 C.2 Single electrolytic cell current-voltage test 15 Appendix D (Informative) Test Report Template 16

Foreword

This document is in accordance with the provisions of GB/T 1.1-2020 "Guidelines for standardization work Part 1.Structure and drafting rules for standardization documents" Drafting. Please note that some of the contents of this document may involve patents. The issuing organization of this document does not assume the responsibility for identifying patents. This document was proposed and coordinated by the National Hydrogen Energy Standardization Technical Committee (SAC/TC309). This document was drafted by. Dalian Institute of Chemical Physics, Chinese Academy of Sciences, China National Institute of Standardization, Sinopec Petrochemical Research Institute Institute Co., Ltd., CSSC (Handan) Perri Hydrogen Energy Technology Co., Ltd., China Huadian Science and Technology Group Co., Ltd., State Power Investment Corporation Science and Technology Research Institute Co., Ltd., State Power Investment Group Hydrogen Energy Technology Development Co., Ltd., State Grid Zhejiang Electric Power Co., Ltd. Electric Power Research Institute, Tianjin Continental Hydrogen Equipment Co., Ltd., Tongji University, Kewell Technology Co., Ltd., Shandong Seikesaisi Hydrogen Energy Co., Ltd., Shanghai Hydrogen Age Technology Co., Ltd., Guoneng Hydrogen Technology (Beijing) Co., Ltd., Tsinghua Sichuan Energy Internet Research Institute, Beijing Low Carbon Clean Energy Research Institute, Tan Kah Kee Innovation Laboratory, Zhejiang University. The main drafters of this document are. Yu Hongmei, Yang Yanmei, Xu Wei, Zhang Cunman, Xiu Kai, Chi Jun, Hu Xiaofu, Li Wenying, Mei Wu, Liu Wei, Kan Hongwei, Wannianfang, Wang Xin, Yu Ping, Liu Min, Han Kunkun, He Guangli, Ren Hangxing, Sun Liuli, Liu Congmin, Zhou Luli, Tao Huabing, Li Jiaxin, Li Yang, Jin Liming, Ma Meng, and Zhang Jiahang. PEM electrolyzer performance test method Warning. During the test, the safety of the test medium, test system, test environment and the safety protection of the test operators should be evaluated. This document does not cover all possible safety issues. Users are responsible for taking appropriate safety and health protection measures and ensuring compliance with national The conditions stipulated by relevant laws and regulations of the country.

1 Scope

This document describes the basic inspection, basic test and performance test methods of proton exchange membrane electrolyzer (hereinafter referred to as "PEM electrolyzer"). Specifies the requirements for test reports. This document is applicable to PEM electrolyzers with a rated hydrogen production pressure less than or equal to 10MPa and a single cell rated hydrogen production capacity of 1m3/h~500m3/h. PEM electrolyzers with a rated hydrogen production pressure greater than 10MPa, or a rated hydrogen production capacity less than 1m3/h or greater than 500m3/h PEM electrolyzer shall be implemented as a reference. Note. Unless otherwise specified, pressure refers to gauge pressure. The standard state in this document is temperature 0°C and pressure 101.325 kPa (absolute pressure). The volume of oxygen refers to the volume under standard conditions.

2 Normative references

The contents of the following documents constitute the essential clauses of this document through normative references in this document. For referenced documents without a date, only the version corresponding to that date applies to this document; for referenced documents without a date, the latest version (including all amendments) applies to This document. GB/T 8979 Pure nitrogen, high purity nitrogen and ultra-pure nitrogen GB/T 24499 Terminology of hydrogen, hydrogen energy and hydrogen energy systems GB/T 37562 Technical requirements for pressure-type water electrolysis hydrogen production system GB/T 45539 Technical requirements for PEM electrolyzers

3 Terms and definitions

The terms and definitions defined in GB/T 24499 and GB/T 45539 apply to this document.

4 Basic inspection

4.1 Check the PEM electrolyser product manual. 4.2 Use visual method to check whether the appearance and structure of PEM electrolyzer are intact and whether there are any defects such as damage and scratches. 4.3 Use visual method to check whether the PEM electrolyzer label is affixed to the designed position and whether the content of the label is complete and clear. 4.4 The polarity of the PEM electrolyzer should be checked. The wiring terminals and electrical connections should be inspected to confirm whether they meet the requirements. During normal operation test, use a voltmeter to check the polarity of the PEM electrolyzer terminals. 4.5 If there is an inspection line on the PEM electrolyzer, it should be inspected to avoid short circuit, open circuit, etc. 4.6 The gas, water pipeline interfaces and electrical interfaces of the PEM electrolyzer shall comply with the requirements of the instructions and meet the requirements of installation, operation, inspection and maintenance. need. ......
