GB/T 44455-2024 English PDF

US$439.00 · In stock
Delivery: <= 4 days. True-PDF full-copy in English will be manually translated and delivered via email.
GB/T 44455-2024: Test methods for optical properties of variable focus liquid lens
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 44455-2024	439	Add to Cart	4 days	Test methods for optical properties of variable focus liquid lens	Valid

Similar standards

GB/T 903   GB/T 7962.2   GB/T 10586   GB/T 45908   GB/T 42714

Basic data

Standard ID: GB/T 44455-2024 (GB/T44455-2024)
Description (Translated English): Test methods for optical properties of variable focus liquid lens
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: N05
Classification of International Standard: 81.040.01
Word Count Estimation: 22,253
Date of Issue: 2024-09-29
Date of Implementation: 2025-04-01
Issuing agency(ies): State Administration for Market Regulation, China National Standardization Administration

GB/T 44455-2024: Test methods for optical properties of variable focus liquid lens

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
ICS 81.040.01 CCSN05 National Standard of the People's Republic of China Optical performance test method of liquid zoom lens Released on 2024-09-29 2025-04-01 Implementation State Administration for Market Regulation The National Standardization Administration issued

Table of Contents

Preface III Introduction IV 1 Scope 1 2 Normative references 1 3 Terms and Definitions 1 4 Test Requirements 2 5 Test Method 2 5.1 Zoom range 2 5.2 Maximum hysteresis 4 5.3 Optical power response time 4 5.4 Transmittance curve 6 5.5 Axial chromatic aberration 7 5.6 Lens center deviation 8 6 Test Report 10 Appendix A (Informative) Liquid zoom lens types and application scenarios 11 Appendix B (Informative) Test Report Template 13 Reference 14

Foreword

This document is in accordance with the provisions of GB/T 1.1-2020 "Guidelines for standardization work Part 1.Structure and drafting rules for standardization documents" Drafting. Please note that some of the contents of this document may involve patents. The issuing organization of this document does not assume the responsibility for identifying patents. This document was proposed by the China Machinery Industry Federation. This document is under the jurisdiction of the National Technical Committee on Optics and Photonics Standardization (SAC/TC103). This document was drafted by. Zhijiang Laboratory, Shanghai Cool Technology Co., Ltd., Ningbo Yongxin Optics Co., Ltd., Zhoushan Quality and Technical Technical Supervision and Inspection Institute, Shanghai University of Technology, Nanjing University of Science and Technology, Zhejiang Institute of Metrology, Beijing University of Aeronautics and Astronautics, Zhejiang Agricultural University Lin University, Guangdong Beichuang Optoelectronics Technology Co., Ltd., Shenzhen Hengtian Weiyan Technology Co., Ltd., Jiangsu Shike New Materials Co., Ltd. Co., Ltd., Fudan University, China Ordnance Industry Standardization Institute, Dongguan Yutong Optical Technology Co., Ltd., Shanghai Essilor Optical Co., Ltd. Limited company. The main drafters of this document are. Zhang Jianfeng, Dai Bo, Zheng Mingtian, Li Guoqiang, Yang Kun, Chen Lei, Qiu Yuanfang, Chen Wenjian, Zhang Dawei, Zhou Yitong, Hu Pengbing, Pan Sunqiang, Liu Chao, Wang Qionghua, Hao Huadong, Xiao Shundong, Xiong Jinhua, Wang Minghua, Du Mengying, Mi Shilong, Song Zhen.

Introduction

Liquid zoom lens is a focus-adjustable lens containing optical liquid, usually driven by electrical signals. When it is loaded into a liquid lens, the shape of the optical liquid changes accordingly, thereby changing the focal length of the lens. Liquid lenses have the advantages of large focal range, small size, fast response speed, low energy consumption, and high precision. They have been applied to machine vision. The zoom range, hysteresis, response time, etc. are important characteristics of liquid zoom lenses. Parameter indicators directly affect the imaging effect. This document provides the test methods for these parameters, which can be used to standardize the performance of such products and provide a reference for product development, testing and application. Technical basis, thereby promoting industrial development. Optical performance test method of liquid zoom lens

1 Scope

This document describes the test methods for the optical performance of liquid variable focus lenses. This document is applicable to the optical performance test of liquid variable focus lenses.

2 Normative references

This document has no normative references.

3 Terms and definitions

The following terms and definitions apply to this document. 3.1 Focal power The reciprocal of the focal length of a lens. 3.2 zoom rangefocusrange In the curve of the driving signal and optical power of the liquid zoom lens, the minimum optical power and the maximum optical power corresponding to the monotonically changing part. 3.3 Maximum hysteresis The liquid zoom lens is configured to be capable of performing a variable focus operation when the drive signal increases from the minimum drive value to the maximum drive value and decreases from the maximum drive value to the minimum drive value. The maximum mismatch between the driving signal and the optical power curve during the process. 3.4 When the liquid zoom lens is within the zoom range, the driving signal responds in a step manner, causing the focal length to jump. The time required. Note. The stable value means that the difference between adjacent optical powers is no more than 1%. 3.5 Transmittance curve The curve of the transmittance of the liquid zoom lens changing with wavelength. 3.6 Under specified optical focal length, the difference in optical focal length corresponding to different incident wavelengths of the liquid variable focus lens within the working wavelength range. 3.7 The angle at which the normal to the lens reference surface deviates from the optical axis. Note. For liquid zoom lenses, the reference plane is the plane of the lens package shell. ......
