GB/T 44436-2024 English PDF

US$439.00 · In stock
Delivery: <= 4 days. True-PDF full-copy in English will be manually translated and delivered via email.
GB/T 44436-2024: Laboratory testing and calibration methods for soft X-ray to extreme ultraviolet band space imaging instrument
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 44436-2024	439	Add to Cart	4 days	Laboratory testing and calibration methods for soft X-ray to extreme ultraviolet band space imaging instrument	Valid

Similar standards

GB/T 22062   GB/T 4315.1   GB/T 4315.2   GB/T 26342   GB/T 26332.1

Basic data

Standard ID: GB/T 44436-2024 (GB/T44436-2024)
Description (Translated English): Laboratory testing and calibration methods for soft X-ray to extreme ultraviolet band space imaging instrument
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: N30
Classification of International Standard: 17.180.01
Word Count Estimation: 22,297
Date of Issue: 2024-09-29
Date of Implementation: 2024-09-29
Issuing agency(ies): State Administration for Market Regulation, China National Standardization Administration

GB/T 44436-2024: Laboratory testing and calibration methods for soft X-ray to extreme ultraviolet band space imaging instrument

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
ICS 17.180.01 CCSN30 National Standard of the People's Republic of China Soft X-ray-Extreme Ultraviolet Space Imaging Instrument Laboratory testing and calibration methods Released on 2024-09-29 Implementation on September 29, 2024 State Administration for Market Regulation The National Standardization Administration issued

Table of Contents

Preface III 1 Scope 1 2 Normative references 1 3 Terms and Definitions 1 4 Test Environment 2 4.1 General Requirements 2 4.2 Test environment requirements in atmosphere 2 4.3 Test environment requirements under vacuum 2 5 Test equipment 2 5.1 Test light source 2 5.2 Far-field target simulation device 3 5.3 Star point target 4 5.4 Vacuum system 4 5.5 Standard transfer detector 4 5.6 Motion Platform 4 6 Test items and test methods 4 6.1 Test Items 4 6.2 Field of view and pixel angular resolution detection 5 6.3 System angular resolution test 6 6.4 Spectral response distribution, effective area 7 7 Calibration items and methods 9 7.1 Bidding Items 9 7.2 Geometric Scaling 9 7.3 Dark Noise Calibration 10 7.4 Radiation Calibration 11 References 16

Foreword

This document is in accordance with the provisions of GB/T 1.1-2020 "Guidelines for standardization work Part 1.Structure and drafting rules for standardization documents" Drafting. Please note that some of the contents of this document may involve patents. The issuing organization of this document does not assume the responsibility for identifying patents. This document was proposed and coordinated by the National Technical Committee for Space Science and Its Applications Standardization (SAC/TC312). This document was drafted by. Changchun Institute of Optics, Fine Mechanics and Physics, Chinese Academy of Sciences, National Satellite Meteorological Center, Chinese Academy of Sciences Institute of Energy Physics, National Space Science Center, Chinese Academy of Sciences, National Astronomical Observatories, Chinese Academy of Sciences. The main drafters of this document are. He Lingping, Chen Bo, Lu Yan, Wang Haifeng, Ding Guangxing, Zhang Hongji, Zhang Xiaoxin, Zong Weiguo, Dun Jinping, Wang Yusa, Wei Fei, Bai Xianyong, Liu Shuhu. Soft X-ray-Extreme Ultraviolet Space Imaging Instrument Laboratory testing and calibration methods

1 Scope

This document describes the laboratory testing and characterization of a soft X-ray-EU space imaging instrument operating in the 0.1 nm to 121 nm band. The standard specifies the test items and test methods, and stipulates the requirements for the test environment and test equipment. This document applies to laboratory testing and calibration of space imaging instruments in the soft X-ray-EUV spectral range.

2 Normative references

The contents of the following documents constitute essential clauses of this document through normative references in this document. For referenced documents without a date, only the version corresponding to that date applies to this document; for referenced documents without a date, the latest version (including all amendments) applies to This document. GB/T 8979 Pure nitrogen, high purity nitrogen and ultra-pure nitrogen GB/T 13962 Terminology of optical instruments GB/T 14950 Photogrammetry and remote sensing terminology GB/T 37835 General requirements for the solar irradiance determination process ISO 14644-1.2015 Cleanrooms and related controlled environments Part 1.Classification of air cleanliness by particle concentration centration

3 Terms and definitions

GB/T 8979, GB/T 13962, GB/T 14950, GB/T 37835, ISO 14644-1.2015 and the following terms and definitions The meanings apply to this document. 3.1 Soft X-rays Electromagnetic radiation in the wavelength range of 0.1nm~10nm. 3.2 Extreme ultraviolet lightextremeultraviolet 3.3 The angular width corresponding to a single pixel of the image plane detector of an imaging instrument. 3.4 The angle of the smallest space target that can be resolved by an imaging instrument. 3.5 effective area The product of the entrance pupil area of an imaging instrument and the radiation response efficiency in the working band. ......
