GB/T 43432.2-2023: Metallic materials - Barcol hardness test - Part 2: Verification and calibration of hardness testers
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 43432.2-2023	289	Add to Cart	3 days	Metallic materials - Barcol hardness test - Part 2: Verification and calibration of hardness testers	Valid

Similar standards

GB/T 17394.3 GB/T 17394.2 GB/T 16825.1 GB/T 16826 GB/T 43432.3 GB/T 16491

Basic data

Standard ID: GB/T 43432.2-2023 (GB/T43432.2-2023)
Description (Translated English): Metallic materials - Barcol hardness test - Part 2: Verification and calibration of hardness testers
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: N71
Classification of International Standard: 19.060
Word Count Estimation: 14,195
Date of Issue: 2023-11-27
Date of Implementation: 2024-06-01
Issuing agency(ies): State Administration for Market Regulation, China National Standardization Administration

GB/T 43432.2-2023: Metallic materials - Barcol hardness test - Part 2: Verification and calibration of hardness testers

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
ICS 19:060 CCSN71 National Standards of People's Republic of China Barcol hardness test of metal materials Part 2: Inspection and Calibration of Hardness Testers Metalicmaterials-Barcolhardnesstest- Published on 2023-11-27 2024-06-01 Implementation State Administration for Market Regulation Released by the National Standardization Administration Committee

Preface III Introduction IV 1 Scope 1 2 Normative references 1 3 Terms and Definitions 1 4 Principle of Barcol hardness test 1 5 Hardness Tester Classification 1 6 General requirements 2 7 Direct inspection 2 7:1 General 2 7:2 Inspection of indenter 3 7:2:1 Main technical parameters of indenter 3 7:2:2 Detection of pressure needle cone angle 3 7:2:3 Detection of the flat diameter of the top of the indenter 3 7:2:4 Detection of surface roughness of indenter 3 7:2:5 Testing of indenter hardness 3 7:3 Calibration of measuring indicating devices 3 8 Indirect inspection 4 8:1 General 4 8:2 Indirect inspection method 4 8:3 Evaluation of indication repeatability 4 8:4 Evaluation of indication error 4 8:5 Measurement uncertainty 4 9 Inspection cycle 5 10 Inspection report and/or calibration certificate 5 Appendix A (Informative) Measurement Uncertainty of Barcol Hardness Tester Calibration Results 6

Foreword

This document complies with the provisions of GB/T 1:1-2020 "Standardization Work Guidelines Part 1: Structure and Drafting Rules of Standardization Documents" Drafting: This document is Part 2 of GB/T 43432 "Barcol Hardness Test of Metallic Materials": GB/T 43432 has released the following part: ---Part 2: Inspection and calibration of hardness tester; ---Part 3: Calibration of standard hardness blocks: Please note that some content in this document may be subject to patents: The publisher of this document assumes no responsibility for identifying patents: This document is proposed by China Machinery Industry Federation: This document is under the jurisdiction of the National Testing Machine Standardization Technical Committee (SAC/TC122): This document was drafted by: Shenyang Tianxing Testing Instrument Co:, Ltd:, China Machinery Testing Equipment Co:, Ltd:, Wuxi Inspection and Testing Certification Research Institute, Jilin University, Lishui Valve Testing and Control Technology Co:, Ltd:, China Aviation Industry Corporation Beijing Great Wall Measurement Testing Technology Research Institute, Guangzhou University, Changsha Dicastal Technology Co:, Ltd:, and China Machinery Testing Equipment (Jiangsu) Co:, Ltd: The main drafters of this document: Zhang Luming, Ren Xia, Bao Jun, Zhao Hongwei, Yan Gang, Shi Wei, Xu Zhonggen, Liu Jun, and Ma Wei:

Introduction

GB/T 43432 "Barcol Hardness Test of Metal Materials" aims to standardize the test methods and inspection of test instruments for Barcol hardness: It is planned to be composed of three composed of parts: ---Part 1: Test methods: The purpose is to establish the procedures and methods to be followed for Barcol hardness testing: ---Part 2: Inspection and calibration of hardness tester: The purpose is to stipulate the technical requirements and inspection and calibration methods that the Barcol hardness tester must meet: Law: It stipulates the direct inspection method for testing the basic functions of the hardness tester and the indirect inspection method for testing the comprehensive performance of the hardness tester: ---Part 3: Calibration of standard hardness blocks: The purpose is to determine the technical requirements and calibration methods that the Barcol standard hardness block needs to meet: Barcol hardness test of metal materials Part 2: Inspection and Calibration of Hardness Testers

1 Scope

This document describes the method of testing the Barcol hardness tester (hereinafter referred to as the "hardness tester") using the direct inspection method and the indirect inspection method, and stipulates the Barcol hardness tester: Hardness tester classification, general requirements, direct inspection method, indirect inspection method, inspection cycle and inspection report requirements: This document is applicable to the inspection and calibration of the Barcol hardness tester: The indirect inspection method can also be used independently for regular routine use of the hardness tester: test:

2 Normative reference documents

The contents of the following documents constitute essential provisions of this document through normative references in the text: Among them, the dated quotations For undated referenced documents, only the version corresponding to that date applies to this document; for undated referenced documents, the latest version (including all amendments) applies to this document: GB/T 4340:1 Vickers hardness test of metallic materials Part 1: Test methods GB/T 36416:1 Testing machine vocabulary Part 1: Material testing machines GB/T 43432:3 Barcol hardness test of metallic materials Part 3: Calibration of standard hardness blocks

3 Terms and definitions

The terms and definitions defined in GB/T 36416:1 apply to this document:

4 Principle of Barcol hardness test

A steel indenter with a specified shape is pressed into the surface of the sample under the action of spring force: The depth of the indenter pressed into the sample is used to indicate the barometer of the material: degree of hardness: The hardness of the material is related to the depth of indentation: The shallower the indentation depth, the higher the hardness, and vice versa: Define every 0:0076mm The penetration depth is one Barcol hardness unit: Calculate Barcol hardness according to formula (1): HBa=100- 0:0076 (1) In the formula: HBa---Barcol hardness value; d ---The depth of the indenter pressed into the sample, in millimeters (mm):

5 Hardness Tester Classification

The cone angle of the pressing needle and the nominal value of the force spring coefficient divide the hardness tester into three types: Type A, Type B and Type C: The parameters corresponding to each type are See Table 1 for values: ......
