GB/T 4340.4-2022 English PDF

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 4340.4-2022	RFQ	ASK	3 days	Metallic materials - Vickers hardness test - Part 4: Tables of hardness values	Valid
GB/T 4340.4-2009	RFQ	ASK	9 days	Metallic materials -- Vickers hardness test -- Part 4: Tables of hardness values	Obsolete

Similar standards

GB/T 4340.1   GB/T 4337   GB/T 4340.1   GB/T 4340.3   GB/T 4340.2   GB/T 4340.3

Basic data

Standard ID: GB/T 4340.4-2022 (GB/T4340.4-2022)
Description (Translated English): Metallic materials - Vickers hardness test - Part 4: Tables of hardness values
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: H22
Word Count Estimation: 143,168
Issuing agency(ies): State Administration for Market Regulation, China National Standardization Administration

GB/T 4340.4-2022: Metallic materials - Vickers hardness test - Part 4: Tables of hardness values

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Metallic materials -- Vickers hardness test -- Part 4.Tables of hardness values ICS 77.040.10 CCSH22 National Standards of People's Republic of China Replacing GB/T 4340.4-2009 Vickers hardness test of metal materials Part 4.Table of hardness values (ISO 6507-4.2018, IDT) Published on 2022-03-09 2022-10-01 Implementation State Administration for Market Regulation Released by the National Standardization Administration directory Preface I Introduction II 1 Scope 1 2 Normative references 1 3 Terms and Definitions 1 4 Vickers hardness table 1

foreword

This document is in accordance with the provisions of GB/T 1.1-2020 "Guidelines for Standardization Work Part 1.Structure and Drafting Rules of Standardization Documents" drafted. This document is part 4 of GB/T 4340 "Vickers Hardness Test for Metallic Materials". GB/T 4340 has published the following parts. --- Part 1.Test methods; --- Part 2.Inspection and calibration of hardness testers; --- Part 3.Calibration of standard hardness blocks; --- Part 4.Table of hardness values. This document replaces GB/T 4340.4-2009 "Vickers Hardness Test for Metal Materials Part 4.Table of Hardness Values", and Compared with GB/T 4340.4-2009, in addition to structural adjustment and editorial changes, the main technical changes are as follows. --- Added the statement of the calculation method of Vickers hardness value (see Chapter 4); --- Delete the Vickers hardness value with an average indentation diameter greater than 1.400mm (see Table 3 of the.2009 edition). This document is equivalent to ISO 6507-4.2018 "Vickers Hardness Test for Metal Materials Part 4.Table of Hardness Values". Please note that some content of this document may be patented. The issuing agency of this document assumes no responsibility for identifying patents. This document is proposed by China Iron and Steel Association. This document is under the jurisdiction of the National Steel Standardization Technical Committee (SAC/TC183). This document is drafted by. General Iron and Steel Research Institute, Fujian Boiler and Pressure Vessel Inspection Institute, Metallurgical Industry Information Standards Institute, Shougang Group Co., Ltd., Quanzhou Fengze Donghai Instrument Hardness Block Factory, Beijing Times Zhifeng Technology Co., Ltd., and Gangyan Nake Testing Technology Co., Ltd. Ltd. The main drafters of this document. Gao Yifei, Chen Song, Dong Li, Wu Zhaohui, Chen Junxin, Qiu Yu, He Keqin, Hou Huining. This document was first published in.2009 and this is the first revision.

Introduction

GB/T 4340 "Vickers Hardness Test for Metal Materials" aims to standardize the Vickers hardness test method of metal materials, the inspection and calibration of hardness testers Standard, standard hardness block calibration and hardness value and so on. GB/T 4340 consists of four parts. --- Part 1.Test methods; --- Part 2.Inspection and calibration of hardness testers; --- Part 3.Calibration of standard hardness blocks; --- Part 4.Table of hardness values. This document provides indentation diagonals below 1.961N, between 1.961N~29.42N and between 49.03N~980.7N The comparison table of length and corresponding Vickers hardness value is convenient for standard users to consult and use. Vickers hardness test of metal materials Part 4.Table of hardness values

1 Scope

The table of hardness values given in this document applies to Vickers hardness testing in accordance with ISO 6507-1.

2 Normative references

The contents of the following documents constitute essential provisions of this document through normative references in the text. Among them, dated citations documents, only the version corresponding to that date applies to this document; for undated references, the latest edition (including all amendments) applies to this document. ISO 6507-1 Vickers hardness test for metallic materials - Part 1.Test methods (Metalicmaterials-Vickershard- nesstest-Part 1.Testmethod) Note. GB/T 4340.1-2009 Vickers hardness test of metallic materials Part 1.Test method (ISO 6507-1.2005, MOD)

3 Terms and Definitions

There are no terms and definitions that need to be defined in this document.

4 Vickers hardness table

Table 1, Table 2 and Table 3 give the Vickers hardness value table calculated according to the ISO 6507-1 Vickers hardness formula. The range < HV0.2 is shown in Table 1; the range HV0.2~HV3 is shown in Table 2; the range HV5~HV100 is shown in Table 3. ......
