GB/T 42207.5-2022 English PDFUS$474.00 ยท In stock
Delivery: <= 5 days. True-PDF full-copy in English will be manually translated and delivered via email. GB/T 42207.5-2022: Connectors for electronic equipment - Product requirements - Rectangular connectors - Part 5: Detail specification for rewirable power connectors with snap locking for rated voltage of250 V d. c. and rated current of 30 A Status: Valid
Basic dataStandard ID: GB/T 42207.5-2022 (GB/T42207.5-2022)Description (Translated English): Connectors for electronic equipment - Product requirements - Rectangular connectors - Part 5: Detail specification for rewirable power connectors with snap locking for rated voltage of250 V d. c. and rated current of 30 A Sector / Industry: National Standard (Recommended) Classification of Chinese Standard: L23 Classification of International Standard: 31.220 Word Count Estimation: 26,234 Date of Issue: 2022-12-30 Date of Implementation: 2023-07-01 Issuing agency(ies): State Administration for Market Regulation, China National Standardization Administration GB/T 42207.5-2022: Connectors for electronic equipment - Product requirements - Rectangular connectors - Part 5: Detail specification for rewirable power connectors with snap locking for rated voltage of250 V d. c. and rated current of 30 A---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order. ICS 31.220 CCSL23 National Standards of People's Republic of China Product requirements for connectors for electronic equipment Rectangular connectors part 5. rated voltage dc 250V rated current 30A buckle lock repeatable Wiring Power Connector Detail Specification Released on 2022-12-30 and implemented on 2023-07-01 State Administration for Market Regulation Released by the National Standardization Management Committee table of contentsPreface III Introduction IV 1 Scope 1 2 Normative references 1 3 Terms and Definitions 2 4 Feature 2 4.1 Ratings and Characteristics 2 4.2 Performance level 2 4.3 Compatibility Level 2 4.4 Climate category 2 4.5 Clearances and creepage distances 2 4.6 Ampacity 3 4.7 Flag 3 5 Size information 3 5.1 General 3 5.2 Axonometric drawings and general features 3 5.3 Fixed end connector 3 5.4 Free end connector 5 5.5 Annex 7 5.6 Installation Information 7 5.7 Standard gauge 8 6 Technical characteristics 8 6.1 Climate category 8 6.2 Electrical characteristics 8 6.3 Mechanical properties 9 6.4 Dynamic stress test 11 6.5 Climate test 11 6.6 Environmental factors 11 7 trials 12 7.1 General 12 7.2 Test list 12 7.3 Test procedure and measurement method 17 7.4 Sample pretreatment before test 17 7.5 Wiring and installation of test samples 17 Reference 18 Fig.1 Axonometric diagram of free end connector Fig.3 Figure 2 Axonometric Figure 3 of the Fixed End Connector Figure 3 Fixed end connector 4 Figure 4 Free end connector 6 Figure 5 Standard Gauge 8 Table 1 Climate Category 2 Table 2 Fixed-end connector size 4 Table 3 Free end connector size 7 Table 4 Standard gauge size 8 Table 5 Conductor connection reliability test 10 Table 6 Number of test samples 12 Table 7 P test group 12 Table 8 AP test group 13 Table 9 BP test group 14 Table 10 CP test group 15 Table 11 DP test group 15 Table 12 EP test group 16 Table 13 JP test group 16 Table 14 KP test group 17forewordThis document is in accordance with the provisions of GB/T 1.1-2020 "Guidelines for Standardization Work Part 1.Structure and Drafting Rules for Standardization Documents" drafting. This document is part 5 of GB/T 42207 "Connector Product Requirements for Electronic Equipment Rectangular Connector". GB/T 42207 The following parts have been published. --- Part 5.Detailed specification for rated voltage DC 250V rated current 30A snap lock rewirable power connector. This document is equivalent to IEC 61076-3-120.2016 "Product Requirements for Connectors for Electronic Equipment Part 3-120.Rectangular Connection Detail specification for snap lock rewirable power connector with rated voltage DC 250V rated current 30A. The following minimal editorial changes have been made to this document. --- In order to coordinate with the existing standard, change the name of the standard to "Connector Product Requirements for Electronic Equipment Rectangular Connector Part 5 Sub. Rated Voltage DC 250V Rated Current 30A Snap Lock Rewirable Power Connector Detailed Specification"; --- The IEC 61076-3.2008 cited in the original international standard is deleted in the normative reference document because it is not cited in the text. Please note that some contents of this document may refer to patents. The issuing agency of this document assumes no responsibility for identifying patents. This document is proposed by the Ministry of Industry and Information Technology of the People's Republic of China. This document is under the jurisdiction of the National Standardization Technical Committee of Electromechanical Components for Electronic Equipment (SAC/TC166). This document is drafted by. Sichuan Huafeng Enterprise Group Co., Ltd., China Electronics Standardization Institute, Huawei Technologies Co., Ltd. The main drafters of this document. Pang Bin, Xiao Miao, Liu Jun, Zhu Ming, Fang Wei, Sun Baoliang.IntroductionGB/T 42207 "Connector Product Requirements for Electronic Equipment Rectangular Connector" is proposed to be composed of the following parts. --- Part 1.Sub-specification (IEC 61076-3). The purpose is to establish a unified detailed specification and technical information for rectangular connectors, as The basis for the development of a consistent product detail specification for rectangular connectors. --- Part 2.Blank detailed specification (IEC 61076-3-001). The purpose is to standardize the content of detailed specifications for rectangular connector products content, for use with Part 1. --- Part 3.8-channel unshielded free and fixed connectors for industrial IEC 60603-7 series interface data transmission in detail Specification (IEC 61076-3-106). The purpose is to specify the industrial IEC 60603-7 series interface data transmission with 8-channel non-screen Outline dimensions, interface dimensions, technical parameters, performance requirements and test methods of shielded free and fixed connectors. --- Part 4.Detailed specification for shielded free and fixed connectors for data transmission up to 1000MHz (IEC 61076-3- 110). The purpose of this standard is to specify the external dimensions, connectors and connectors of shielded free and fixed connectors for data transmission up to 1000MHz. Requirements such as port size, technical parameters, performance requirements and test methods. --- Part 5.Detail specification for rated voltage DC 250V rated current 30A snap lock rewirable power connector (IEC 61076-3-120). The purpose is to specify the rated voltage DC 250V rated current 30A buckle lock can be repeated wiring Outline dimensions, interface dimensions, technical parameters, performance requirements and test methods of power connectors. --- Part 6.Detailed specification for reinforced 8-channel shielded free and fixed connectors (IEC 61076-3-122). The purpose is to provide Outline dimensions, interface dimensions, technical parameters, performance requirements and test methods, etc. of solid 8-channel shielded free and fixed connectors Require. --- Part 7.Detailed specification for 10-channel shielded free and fixed connectors for industrial I/O and gigabit transmission capabilities (IEC 61076-3- 124). The purpose is to specify the outline dimensions of 10-channel shielded free and fixed connectors for industrial I/O and gigabit transmission capabilities Dimensions, interface dimensions, technical parameters, performance requirements and test methods and other requirements. Product requirements for connectors for electronic equipment Rectangular connectors part 5. rated voltage dc 250V rated current 30A buckle lock repeatable Wiring Power Connector Detail Specification1 ScopeThis document specifies the overall dimensions, interface dimensions, technical Technical parameters, performance requirements and test methods, etc. This document applies to non-breaking capacity connectors specified in IEC 61984.2008, mainly used for DC power distribution equipment in the communication field, Including outdoor modules, subrack power supplies, etc.2 Normative referencesThe contents of the following documents constitute the essential provisions of this document through normative references in the text. Among them, dated references For documents, only the version corresponding to the date is applicable to this document; for undated reference documents, the latest version (including all amendments) is applicable to this document. GB/T 3956-2008 Cable Conductors (IEC 60228.2004, IDT) GB/T 4210-2015 Electrotechnical terms Electromechanical components for electronic equipment (IEC 60050-581.2008, IDT) GB/T 17464-2012 The safety requirements for threaded and non-threaded clamps for electrical copper conductors of connecting devices are applicable to General requirements and special requirements for clamping parts of conductors from 0.2 mm2 up to 35 mm2 (inclusive) (IEC 60999-1.1999, IDT) GB/T 20636-2006 The safety requirements for threaded and non-threaded clamps for electrical copper conductors of connecting devices are applicable to Special requirements for wires above 35mm2 to 300mm2 (IEC 60999-2.2003, IDT) plastic products) Note. GB/T 16288-2008 Marking of plastic products (ISO 11469.2000, MOD) guidance) Note. GB/T 2421-2020 Environmental Test Overview and Guidelines (IEC 60068-1.2013, IDT) Note. GB/T 18290 (all parts) Solderless connection [IEC 60352 (all parts)] IEC 60512 (all parts) Basic test procedures and measurement methods for electromechanical components used in electronic equipment (Connectors for Note. GB/T 5095 (all parts) Basic test procedures and measurement methods for electromechanical components used in electronic equipment [IEC 60512 (all parts)] IEC 60512-1-2.2002 Basic test procedures and methods of measurement for electromechanical components used in electronic equipment Part 1-2.General inspection Note. GB/T 18501.1-2001 Quality-assessed connectors for DC and low-frequency analog and digital high-speed data processing equipment Part 1.General regulations Fan (idtIEC 61076-1.1995) ...... |
