US$569.00 · In stock
Delivery: <= 5 days. True-PDF full-copy in English will be manually translated and delivered via email.
GB/T 41666.3-2022: Plastics piping systems for renovation of underground non-pressure drainage and sewerage networks - Part 3: Lining with close-fit pipes
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 41666.3-2022	569	Add to Cart	5 days	Plastics piping systems for renovation of underground non-pressure drainage and sewerage networks - Part 3: Lining with close-fit pipes	Valid

Similar standards

GB/T 41792 GB/T 41791 GB/T 40933 GB/T 45331 GB/T 45332 GB/T 41666.4

Basic data

Standard ID: GB/T 41666.3-2022 (GB/T41666.3-2022)
Description (Translated English): Plastics piping systems for renovation of underground non-pressure drainage and sewerage networks - Part 3: Lining with close-fit pipes
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: G33
Word Count Estimation: 29,246
Issuing agency(ies): State Administration for Market Regulation, China National Standardization Administration

GB/T 41666.3-2022: Plastics piping systems for renovation of underground non-pressure drainage and sewerage networks - Part 3: Lining with close-fit pipes

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Plastics piping systems for renovation of underground non-pressure drainage and sewerage networks -- Part 3.Lining with close-fit pipes ICS 83.140.30 CCSG33 National Standards of People's Republic of China Plastics for trenchless repair of underground pressureless drainage pipe network Piping systems part 3.close fit lining method (ISO 11296-3.2018, MOD) Published on 2022-04-15 2022-11-01 Implementation State Administration for Market Regulation Released by the National Standardization Administration directory Preface III Introduction IV 1 Scope 1 2 Normative references 1 3 Terms and Definitions 2 4 Symbols and Abbreviations 3 5 Production Stage ("M" Stage) Lined Pipe Requirements 3 5.1 Materials 3 5.2 General requirements 4 5.3 Material properties 4 5.4 Geometry 5 5.5 Mechanical properties 6 5.6 Physical Properties 6 5.7 Splice Compatibility 7 5.8 Test method 7 5.9 Flag 7 6 Production Stage (“M” Stage) Fitting Requirements 8 7 Annex 8 8 Construction Phase (“I” Phase) Requirements 8 8.1 Materials 8 8.2 Appearance 8 8.3 Geometry 8 8.4 Mechanical properties 10 8.5 Physical Properties 11 8.6 Test methods 11 9 Construction 11 9.1 Construction preparation 11 9.2 Storage and transport 12 9.3 Equipment and devices 12 9.4 Liner installation 13 9.5 Process Self-Check and Test 13 9.6 End Treatment 14 9.7 Connection to inspection wells 14 9.8 Internal inspection 14 9.9 Archives 14 10 Acceptance 14 10.1 General provisions 14 10.2 Construction quality inspection of lined pipe 15 10.3 Pipeline functional test 15 Appendix A (informative) Changes in the structure of this document compared with ISO 11296-3.201816 Appendix B (informative) Technical differences between this document and ISO 11296-3.2018 and their reasons17 Appendix C (normative) Factory Folded Heat-Reduced Polyethylene (PE) Pipe --- Determination of Memory Ability 18 Appendix D (normative) test method 20 Reference 23

foreword

This document is in accordance with the provisions of GB/T 1.1-2020 "Guidelines for Standardization Work Part 1.Structure and Drafting Rules of Standardization Documents" drafted. This document is part 3 of GB/T 41666 "Plastic piping system for trenchless repair of underground pressureless drainage network". GB/T 41666 The following sections have been published. --- Part 3.Closely fit lining method. This document is modified and adopted ISO 11296-3.2018 "Plastic piping system for trenchless repair of underground pressureless drainage pipe network - Part 3.Tight Close fit lining method. Compared with ISO 11296-3.2018, this document has more structural adjustments. Appendix A lists this document and ISO 11296-3. 2018 chapter number comparison list. There are technical differences between this document and ISO 11296-3.2018, and the clauses involved in these differences have been The vertical single line (1) of the position is marked, and a list of the corresponding technical differences and their reasons is given in Appendix B. Please note that some content of this document may be patented. The issuing agency of this document assumes no responsibility for identifying patents. This document is proposed by China National Light Industry Federation. This document is under the jurisdiction of the National Standardization Technical Committee of Plastic Products (SAC/TC48). This document was drafted by. Beijing Beipai Construction Co., Ltd., Taiyuan Changda Huamei New Material Technology Co., Ltd., China Building Research Institute Co., Ltd., Beijing Huanfa Pipeline Repair Co., Ltd., Xiamen Anyue Trenchless Engineering Technology Co., Ltd., Shanghai Letong Pipeline Engineering Co., Ltd., Fuguang Environmental Engineering (Shanghai) Co., Ltd., Yada Plastic Products Co., Ltd., Wenzhou Fucheng Construction Engineering Co., Ltd., Shanxi Provincial Water Conservancy Construction Engineering Bureau Co., Ltd., Tianjin Yizhihui Technology Development Co., Ltd. The main drafters of this document. Lu Xuexing, Huang Jiawen, Song Xiaodong, Zhao Jicheng, Wang Qingshun, He Bin, Cui Ying, Yang Peng, Yang Jianjun, Li Yan, Chen Jiandong, Fu Jiansheng, Gu Yanan.

Introduction

GB/T 37862 specifies the technical classification, terms and definitions of plastic piping systems for trenchless repair. This document specifies that underground Requirements for plastic piping systems for trenchless repair of pressurized drainage networks. According to the application field of the repaired pipeline system, the trenchless repair technology is also Divided into the following technical series, corresponding to different series of standards. ---Plastic pipe system for trenchless repair of underground pressureless drainage pipe network (this series of standards); ---Plastic pipe system for trenchless repair of underground pressurized drainage pipe network (not yet prepared); --- Plastic pipe system for trenchless repair of underground water supply network (not yet prepared); --- Plastic piping system for trenchless repair of underground gas pipe network (not yet prepared). GB/T 41666 "Plastic Pipeline System for Trenchless Repair of Underground Unpressurized Drainage Pipe Network" is proposed to consist of the following parts. --- Part 1.General; --- Part 2.Coiled tube lining method; --- Part 3.Closely fit lining method; --- Part 4.In-situ curing lining method; --- Part 5.Short tube insertion method; --- Part 7.Spiral winding lining method; --- Part 8.Segment lining method; --- Part 9.Padding method; --- Part 10.Spray polymer lining method. Part 1 (General) of each technology series specifies the general requirements for trenchless repair technology in this field, and the other parts are specific engineering. Engineering method (construction method). Each part (Construction Method) and Part 1 (General) shall be used in combination. This document specifies the phases of the close fit lining method off requirements. See GB/T 37862 for further information. Since not all technical (construction method) standards are applicable to all application fields, The components contained in this different technical series of standards will vary. The standard system table in Figure 1 shows the general parts of the trenchless repair technology system, the interrelationship of each technology series and its basic constitute. Figure 1 Framework of Repair System Standards Plastics for trenchless repair of underground pressureless drainage pipe network Piping systems part 3.close fit lining method

1 Scope

This document specifies the terminology for plastic piping systems used in the trenchless repair of underground pressureless drainage networks with close fit lining and Definitions, Symbols and Abbreviations, Production Stage ("M" Stage) Lined Pipe Requirements, Production Stage ("M" Stage) Fitting Requirements, Accessories, Construction Stages Section ("I" Phase) Requirements, Construction and Acceptance. This document is applicable to the use of the close-fitting lining method in the plastic pipe system for the trenchless repair of the underground pressureless drainage pipe network. Pipes made of polyethylene (PE) or unplasticized polyvinyl chloride (PVC-U), as well as installed lining systems, joints and construction.

2 Normative references

The contents of the following documents constitute essential provisions of this document through normative references in the text. Among them, dated citations documents, only the version corresponding to that date applies to this document; for undated references, the latest edition (including all amendments) applies to this document. GB/T 1033.1-2008 Determination of the density of non-foamed plastics - Part 1.Impregnation method, pycnometer method and titration method (GB/T 1033.1-2008, ISO 1183-1.2004, IDT) GB/T 1040.2 Determination of Tensile Properties of Plastics Part 2.Test Conditions for Molded and Extruded Plastics (GB/T 1040.2- 2006, ISO 527-2.1993, IDT) GB/T 3682.1-2018 Plastics Thermoplastics Melt Mass Flow Rate (MFR) and Melt Volume Flow Rate (MVR) Determination of Part 1.Standard Methods (GB/T 3682.1-2018, ISO 1133.1.2011, MOD) GB/T 6111 Determination of internal pressure resistance of thermoplastic piping systems for fluid transportation (GB/T 6111-2018, ISO 1167-1.2006,ISO 1167-2.2006,ISO 1167-3.2007,ISO 1167-4.2007,NEQ) GB/T 6671-2001 Determination of longitudinal shrinkage of thermoplastic pipes (eqvISO 2505.1994) GB/T 8802 Determination of Vicat softening temperature of thermoplastic pipes and fittings (GB/T 8802-2001, eqvISO 2507.1995) GB/T 8804.1 Determination of Tensile Properties of Thermoplastic Pipes Part 1.General Principles of Test Methods (GB/T 8804.1-2003, ISO 6259-1.1997, IDT) GB/T 8804.2 Determination of Tensile Properties of Thermoplastic Pipes Part 2.Rigid Polyvinyl Chloride (PVC-U), Chlorinated Polyvinyl Chloride (PVC-C) and high impact polyvinyl chloride (PVC-HI) pipes (GB/T 8804.2-2003, ISO 6259.2.1997, IDT) GB/T 8804.3 Determination of Tensile Properties of Thermoplastic Pipes Part 3.Polyolefin Pipes (GB/T 8804.3-2003, ISO 6259-3.1997, IDT) GB/T 8806 Determination of the dimensions of plastic parts of plastic piping systems (GB/T 8806-2008, ISO 3126.2005, IDT) GB/T 9345.1-2008 Determination of ash content of plastics - Part 1.General method (ISO 3451-1.1997, IDT) GB/T 9647 Determination of Ring Rigidity of Thermoplastic Pipes (GB/T 9647-2015, ISO 9969.2007, IDT) GB/T 13526-2007 Rigid Polyvinyl Chloride (PVC-U) Pipe Dichloromethane Impregnation Test Method GB/T 14152 Thermoplastic Pipes Test Method for External Impact Resistance Clock Rotation Method (GB/T 14152-2001, eqv ISO 3127.1994) GB/T 18042-2000 Test method for creep ratio of thermoplastic pipes (eqvISO 9967.1994) GB/T 19278 General terms and definitions for thermoplastic pipes, fittings and valves ......
