GB/T 41114-2021: Non-destructive testing - Ultrasonic testing - Specification for a calibration block for phased array testing(PAUT)
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 41114-2021	414	Add to Cart	4 days	Non-destructive testing - Ultrasonic testing - Specification for a calibration block for phased array testing(PAUT)	Valid

Similar standards

GB/T 41105.2 GB/T 41105.1 GB/T 41120

Basic data

Standard ID: GB/T 41114-2021 (GB/T41114-2021)
Description (Translated English): Non-destructive testing - Ultrasonic testing - Specification for a calibration block for phased array testing(PAUT)
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: J04
Word Count Estimation: 22,241
Issuing agency(ies): State Administration for Market Regulation, China National Standardization Administration

GB/T 41114-2021: Non-destructive testing - Ultrasonic testing - Specification for a calibration block for phased array testing(PAUT)

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Non-destructive testing -- Ultrasonic testing -- Specification for a calibration block for phased array testing(PAUT) ICS 19:100 CCSJ04 National Standards of People's Republic of China NDT Ultrasonic Testing Specification for Phased Array Ultrasonic Testing Standard Test Blocks (ISO 19675:2017, IDT) Published on 2021-12-31 2022-07-01 Implementation State Administration for Market Regulation Released by the National Standardization Administration directory Preface III 1 Scope 1 2 Normative references 1 3 Terms and Definitions 1 4 Abbreviations 1 5 make 1 6 Mark 3 7 Declaration of Conformity 5 8 Modifications permissible for Phased Array Standard Test Blocks 6 Appendix A (normative) Determination of material anisotropy 8 Appendix B (informative) Description of possible usage of PAUT standard test block 12 Reference 17

foreword

This document is in accordance with the provisions of GB/T 1:1-2020 "Guidelines for Standardization Work Part 1: Structure and Drafting Rules of Standardization Documents" drafted: This document is equivalent to ISO 19675:2017 "Non-Destructive Testing Ultrasonic Testing Phased Array Ultrasonic Testing Standard Test Block Specifications": The following minimal editorial changes have been made to this document: --- The technical content of EN16018 and ISO 23243 is consistent: In order to be consistent with the existing technical documents, EN16018 is changed to ISO 23243 (chapter 2); ---In order to adapt to domestic technology application, add the note of 5:1; --- In order to adapt to domestic technical applications, increase the national standard mark [see 6a)]; --- In order to adapt to domestic technical applications, the dimension marking form and view direction of Figure 2b) and Figure 2c) have been adjusted; --- Add a reference to Appendix B (Chapter 8); --- Add the description of formula (A:1) symbols; --- Added reference GB/T 1591-2018 for ease of use: Please note that some content of this document may be patented: The issuing agency of this document assumes no responsibility for identifying patents: This document is proposed and managed by the National Technical Committee for Standardization of Nondestructive Testing (SAC/TC56): This document is drafted by: Shanghai Institute of Materials, Zhejiang Electric Power Boiler and Pressure Vessel Inspection Co:, Ltd:, Shanghai Special Equipment Supervisor Supervision and Inspection Technology Research Institute, Shandong Ruixiang Mould Co:, Ltd:, Zhejiang Uerte Testing Technology Co:, Ltd:, Shanghai Baoye Engineering Technology Co:, Ltd: company: The main drafters of this document: Jiang Jiansheng, Huang Yin, Zhang Jie, Zhao Zhoufeng, Yang Yuqing, Zhang Pinghui, Li Qing, Lv Junmin, Wang Lili, Ding Jie, Zhang Yifeng, Ma Jun, Xue Feng, Song Fei: NDT Ultrasonic Testing Specification for Phased Array Ultrasonic Testing Standard Test Blocks

1 Scope

This document specifies the dimensions, materials and fabrication requirements for steel test blocks used to test the performance of phased array ultrasonic testing equipment:

2 Normative references

The contents of the following documents constitute essential provisions of this document through normative references in the text: Among them, dated citations documents, only the version corresponding to that date applies to this document; for undated references, the latest edition (including all amendments) applies to this document: ISO 5577 Non-destructive testing ultrasonic testing terminology (Non-destructive testing-Ultrasonic testing-Vocabula- ry) Note: GB/T 12604:1-2020 Nondestructive testing term ultrasonic testing (ISO 5577:2017, MOD) ISO 23243 Non-destructive testing terminology for phased array ultrasonic testing (Non-destructive testing-Ultrasonic testing with arrays-Vocabulary) EN 10025-2 Structural steel hot-rolled products - Part 2: Technical delivery conditions for non-alloy structural steel (Hotroled products of structuralsteels-Part 2:Technicaldeliveryconditionsfornon-aloystructuralsteels)

3 Terms and Definitions

Terms and definitions defined in ISO 5577 and ISO 23243 apply to this document: The web addresses of terminology databases used in standardization work maintained by ISO and IEC are as follows: ---IEC Electrotechnical Encyclopedia: http://www:electropedia:org/; ---ISO online browsing platform: https://www:iso:org/obp:

4 Abbreviations

The following abbreviations apply to this document: ACG: Angle Gain Correction FSH: full screen height RF: radio frequency SDH: horizontal hole SNR: Signal to Noise Ratio TCG: Time Gain Correction

5 Make

5:1 Steel The test block shall be made of steel with a steel grade of S355J0 in accordance with EN10025-2 or a steel equivalent to this grade: ......
