GB/T 40610-2021: Technical specifications for binary description and interchange of power system online power flow data

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Technical specifications for binary description and interchange of power system online power flow data ICS 29.020 CCSF21 National Standards of People's Republic of China Binary description of online power flow data of power system and Exchange specification Released on 2021-10-11 2022-05-01 implementation State Administration for Market Regulation Issued by the National Standardization Management Committee

Table of contents

Foreword Ⅲ 1 Scope 1 2 Normative references 1 3 Terms and definitions 1 4 General requirements 1 5 Binary code 2 6 Model description 2 7 Interactive mode 4 Appendix A (informative) Node branch model 5 Appendix B (informative) Equipment physical model 8 Appendix C (informative) Typical structure of UHV DC system 20 Appendix D (informative) Typical structure of unified power flow controller 21

Foreword

This document is in accordance with the provisions of GB/T 1.1-2020 "Guidelines for Standardization Work Part 1.Structure and Drafting Rules of Standardization Documents" Drafting. Please note that some of the contents of this document may involve patents. The issuing agency of this document is not responsible for identifying patents. This document was proposed by the China Electricity Council. This document is under the jurisdiction of the National Grid Operation and Control Standardization Technical Committee (SAC/TC446). Drafting organizations of this document. State Grid Corporation of China National Electric Power Dispatching Control Center, China Electric Power Research Institute Co., Ltd., China Southern Power Grid Electric Power Dispatching Control Center, State Grid Jiangsu Electric Power Co., Ltd., State Grid Zhejiang Electric Power Co., Ltd., and Shenzhen Power Supply Bureau have Co., Ltd., Beijing Kedong Power Control System Co., Ltd., NARI Group Co., Ltd. The main drafters of this document. Shi Dongyu, Yan Yaqin, Yan Jianfeng, Su Dawei, Zhao Huashi, Jiang Zhengwei, Zhang Zongbao, Wang Yi, Li Junliang, Zhang Wei, Zhou Huafeng, Chen Guoping, Lang Yansheng, Leng Xiwu, Zhang Lulu, Lu Juanjuan, Song Xuri, Yu Jing, Gao Baocheng, Zhou Jieying, Li Gang, Cui Bo, Lu Guangming, Ma Xiaochen, Peng Xiaobo, Shan Xin, Tao Hongzhu, Wan Xiong, Zhao Ruina, Chang Naichao, Yu Zhihong, Lu Ying, Jia Yupei, Dai Hongyang, Xie Chang, Gao Bo, Qiu Jian, Yao Haicheng. Binary description of online power flow data of power system and Exchange specification

1 Scope

This document describes the binary coding and interaction method of power system flow data, and specifies general requirements, binary coding, model description Narrative and interactive mode. This document is applicable to grid power flow models and calculations that do not involve switching information between power control centers at all levels or between internal application modules. Data interaction for calculation results. Other application scenarios related to power flow data of the power grid are implemented by reference.

2 Normative references

The content of the following documents constitutes an indispensable clause of this document through normative references in the text. Among them, dated quotations Only the version corresponding to the date is applicable to this document; for undated reference documents, the latest version (including all amendments) is applicable to This document. GB/T 33603 Power System Model Data Dynamic Message Coding Specification

3 Terms and definitions

The following terms and definitions apply to this document. 3.1 Powerflowdata Describe the operating state data such as voltage and power of various power equipment when the power system is operating in a steady state. 3.2 Powergridmodel A data collection that meets the application requirements of power grid operation monitoring, control, analysis and calculation, and expresses the attributes and connection relationships of electrical equipment. 3.3 Node branch model nodebranchmodel A mathematical model established based on the component parameters and the connection mode or topological relationship of the components in the power system. Note. See Appendix A for details. 3.4 Device physical model devicephysicalmodel Models describing the internal electrical structure and parameters of various types of equipment. Note. Including physical bus, generator, load, parallel compensator, series compensator, AC line, transformer, transformer winding, DC system, unified power flow control Maker and other models. See Appendix B for details.

4 General requirements

The binary description of the power flow data should include the overall description of the model, model index, node branch model, equipment physical model, etc., see the structure Table A.1.The binary exchange of power flow data should meet the requirements of fast exchange between power system analysis applications in different scenarios. ......
