GB/T 40502-2021: Technical requirements for active drag head
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 40502-2021	359	Add to Cart	4 days	Technical requirements for active drag head	Valid

Similar standards

GB/T 18572 GB/T 42341 GB/T 40709

Basic data

Standard ID: GB/T 40502-2021 (GB/T40502-2021)
Description (Translated English): Technical requirements for active drag head
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: U34
Word Count Estimation: 18,179
Issuing agency(ies): State Administration for Market Regulation, China National Standardization Administration

GB/T 40502-2021: Technical requirements for active drag head

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Technical requirements for active draghead ICS 47.020.50 U34 National Standards of People's Republic of China Active drag head technical requirements Released on 2021-08-20 2022-03-01 implementation State Administration of Market Supervision and Administration Issued by the National Standardization Management Committee

Foreword Ⅲ 1 Scope 1 2 Normative references 1 3 Terms and definitions 1 4 Structure 2 5 Technical requirements 6 6 Test method 8 Appendix A (Normative Appendix) Water Tank and Water Chamber Hydraulic Test 9 Appendix B (Normative Appendix) Active drag head hoisting test 10 Appendix C (Normative Appendix) Movable Cover Rotation Test 11 Reference 12

Foreword

This standard was drafted in accordance with the rules given in GB/T 1.1-2009. This standard was proposed by the Ministry of Transport of the People's Republic of China. This standard is under the jurisdiction of the National Port Standardization Technical Committee (SAC/TC530). Drafting organizations of this standard. China Communications Construction Co., Ltd., CCCC Shanghai Waterway Bureau Co., Ltd., CCCC Dredging Technology and Equipment National Engineering Research Center Co., Ltd., CCCC Shanghai Waterway Survey and Design Institute Co., Ltd., CCCC Dredging (Group) Co., Ltd., CCCC Xingyu Technology Co., Ltd., CCCC Tianjin Waterway Bureau Co., Ltd., CCCC Guangzhou Waterway Bureau Co., Ltd., CCCC Shanghai Waterway Equipment Industry Co., Ltd. company. The main drafters of this standard. Hong Guojun, Tian Junfeng, Jiang Ji'an, Lin Feng, Lou Qiming, Li Ning, Chen Yongmei, Yin Liming, Zhou Zhuang, Yang Shu, Yang Xigang, Sun Shousheng, Gu Qing, Zhong Zhisheng. Active drag head technical requirements

1 Scope

This standard specifies the structure, technical requirements and verification methods of the active drag head of a trailing suction dredger. This standard applies to the design, manufacture, inspection and use of active drag heads of trailing suction dredgers, and the design, manufacture, inspection and use of non-active drag heads. Use can refer to use.

2 Normative references

The following documents are indispensable for the application of this document. For dated reference documents, only the dated version applies to this article Pieces. For undated reference documents, the latest version (including all amendments) is applicable to this document. GB/T 1800.1-2020 Product Geometric Technical Specification (GPS) Linear Dimension Tolerance ISO Code System Part 1.Tolerance, Basis for deviation and fit GB/T 1800.2-2020 Product Geometric Technical Specification (GPS) Linear Dimension Tolerance ISO Code System Part 2.Standard Tolerance zone code and limit deviation table of hole and shaft GB/T 8923.1-2011 Visual assessment of surface cleanliness of steel surface treatment before coating-Part 1.Uncoated The corrosion level and treatment level of the steel surface and the steel surface after the original coating has been completely removed GB/T 11345-2013 Ultrasonic testing technology, testing level and assessment for non-destructive testing of welds GB/T 13342 General technical conditions for marine reciprocating hydraulic cylinders GB/T 19418-2003 Guide for the quality classification of arc welded joint defects of steel GB/T 19804 General dimensional tolerances and geometric tolerances of welded structures GB/T 34677 Anticorrosive coating for underwater production system CB/T 4231 Technical requirements for ship coating

3 Terms and definitions

The following terms and definitions apply to this document. 3.1 Draghead It is a digging device installed on the front end of the rake arm of a trailing suction dredger, which is composed of a fixed part, a movable part, a suction cavity and a rake tooth. 3.2 Fixed body helmet The drag head component connected with the rake arm flange of the trailing suction dredger. 3.3 Visor The drag head component is hinged to the fixed body and can rotate within a certain angle range relative to the fixed body. 3.4 Activedraghead The relative angle of the movable cover of the drag head and the fixed body can be adjusted in real time. ......
