GB/T 38520-2020 English PDF

US$409.00 · In stock
Delivery: <= 4 days. True-PDF full-copy in English will be manually translated and delivered via email.
GB/T 38520-2020: Marine cryogenic breakaway coupling
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 38520-2020	409	Add to Cart	4 days	Marine cryogenic breakaway coupling	Valid

Similar standards

GB/T 589   GB/T 586   GB/T 592   GB/T 44678   GB/T 19699

Basic data

Standard ID: GB/T 38520-2020 (GB/T38520-2020)
Description (Translated English): Marine cryogenic breakaway coupling
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: U52
Classification of International Standard: 47.020.99
Word Count Estimation: 22,291
Date of Issue: 2020-03-06
Date of Implementation: 2020-10-01
Quoted Standard: GB/T 191; GB/T 1184-1996; GB/T 1220-2007; GB/T 1804-2000; GB/T 1958; GB/T 9124.1; GB/T 13306; GB/T 13384; GB/T 24925; GB/T 30832-2014; ISO 10497
Issuing agency(ies): State Administration for Market Regulation, China National Standardization Administration
Summary: This standard specifies the classification, technical requirements, test methods, inspection rules, marking, packaging, transportation and storage of marine ultra-low temperature breakaway valves (hereinafter referred to as "breakaway valves"). This standard applies to the design, manufacture and acceptance of break-away valves for hose transmission systems used in operations such as liquefied natural gas (LNG) bunkering, transfer, and loading and unloading of ships.

GB/T 38520-2020: Marine cryogenic breakaway coupling

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Marine cryogenic breakaway coupling ICS 47.020.99 U52 National Standards of People's Republic of China Marine cryogenic pull-off valve 2020-03-06 release 2020-10-01 implementation State Administration of Market Supervision Published by the National Standardization Administration

Contents

Foreword III 1 Scope 1 2 Normative references 1 3 Terms and definitions 1 4 Classification 2 4.1 Structural Type 2 4.2 Basic parameters 2 4.3 Product Marking 3 5 Technical requirements 3 5.1 Design and Structure 3 5.2 Size 3 5.3 Appearance quality 4 5.4 Material 4 5.5 Performance 4 6 Test method 5 6.1 Size 5 6.2 Appearance quality 5 6.3 Electrical conductivity 5 6.4 Performance 6 7 Inspection rules 11 7.1 Inspection classification 11 7.2 Type inspection 11 7.3 Factory inspection 12 8 Marking, packaging, transport and storage 12 8.1 Logo 12 8.2 Packaging 13 8.3 Transport 13 8.4 Storage 13 Appendix A (informative) Typical structure of a pull-off valve 14 Reference 16

Foreword

This standard was drafted in accordance with the rules given in GB/T 1.1-2009. This standard was proposed and managed by the National Marine Machinery Standardization Technical Committee (SAC/TC137). This standard was drafted. China Institute of Shipbuilding Industry Comprehensive Technology and Economy, China Classification Society Wuhan Specification Institute, Chengdu Andy Biosensor Co., Ltd., Zhangjiagang Furui Valve Co., Ltd., Wuhan Sanjiang Aerospace Yuanfang Technology Co., Ltd., Hangzhou Xinya Low Temperature Technology Co., Ltd. Yantai Taiyue Fluid Technology Co., Ltd. and Guangdong CSSC Military-civilian Integration Research Institute Co., Ltd. The main drafters of this standard. Wei Huaxing, Wu Shunping, Liu Tieying, Wu Yongfeng, Tu Huan, Zeng Xuebing, Wang Jianrong, Wang Jun, Yu Feng, Sun Lilong, Xu Jincheng, Li Run, Wang Ruidong, Shengwei, An Lili, Yang Peng, Zhou Jie, Shi Liping, Ma Jun, Cheng Jun, Jiang Bin. Marine cryogenic pull-off valve

1 Scope

This standard specifies the classification, technical requirements, test methods, inspection rules, and standards for marine ultra-low temperature pull-off valves (hereinafter referred to as "pull-off valves"). Storage, packaging, transportation, storage. This standard applies to the breaking of hose transmission systems used in the process of bunkering, transfer and loading and unloading of ships' liquefied natural gas (LNG). Design, manufacture and acceptance of valves.

2 Normative references

The following documents are essential for the application of this document. For dated references, only the dated version applies to this article Pieces. For undated references, the latest version (including all amendments) applies to this document. GB/T 191 Packaging, storage and transportation icon GB/T 1184-1996 shape and position tolerances without tolerance values GB/T 1220-2007 stainless steel rod GB/T 1804-2000 Tolerances for linear and angular dimensions without general tolerances GB/T 1958 Product Geometric Technical Specification (GPS) Geometric Tolerance Detection and Verification GB/T 9124.1 Steel pipe flanges Part 1. PN series GB/T 13306 signs GB/T 13384 General technical requirements for packaging of electromechanical products GB/T 24925 low temperature valve technical conditions GB/T 30832-2014 Valve flow coefficient and flow resistance coefficient test method ISO 10497 Valve Test Fire Testing Requirements (Testing ofvalves-Firetype-testing requirements)

3 terms and definitions

The following terms and definitions apply to this document. 3.1 Breakawaycoupling When a certain external force is applied, the safety device can be safely disconnected, and the two ends are automatically closed. 3.2 Full close time When the pull-off valve is subjected to external force, the time from the safe disconnection to automatic closing at both ends. Note. The unit of full shutdown time is seconds (s). 3.3 Breaking force The force to which the two ends of the pull-off valve are safely disconnected. Note. The unit of breaking force is kilonewtons (kN). ......
