GB/T 3852-2017 English PDF

US$339.00 · In stock
Delivery: <= 4 days. True-PDF full-copy in English will be manually translated and delivered via email.
GB/T 3852-2017: Types and dimensions for coupling bores and their connection
Status: Valid

GB/T 3852: Historical versions

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 3852-2017	339	Add to Cart	4 days	Types and dimensions for coupling bores and their connection	Valid
GB/T 3852-2008	599	Add to Cart	3 days	Types and dimensions for coupling bores and their connection	Obsolete
GB/T 3852-1997	799	Add to Cart	5 days	Types and dimension for coupling bores and their connection	Obsolete
GB 3852-1983	399	Add to Cart	3 days	Types and dimensions for the bore and keyways of coupling	Obsolete

Similar standards

GB/T 5014   GB/T 5015   GB/T 4323   GB/T 5844   GB/T 5843

Basic data

Standard ID: GB/T 3852-2017 (GB/T3852-2017)
Description (Translated English): Types and dimensions for coupling bores and their connection
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: J19
Classification of International Standard: 21.120.20
Word Count Estimation: 17,126
Date of Issue: 2017-05-12
Date of Implementation: 2017-12-01
Older Standard (superseded by this standard): GB/T 3852-2008
Quoted Standard: GB/T 1095; GB/T 1144; GB/T 1184; GB/T 1570; GB/T 3478.1; GB/T 11334
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China
Summary: This standard specifies the type and code of the coupling shaft hole, size and markings and examples. This standard applies to key-connected cylindrical shaft holes, 1: 10 conical shaft holes and spline-coupled spline hole couplings.

GB/T 3852-2017: Types and dimensions for coupling bores and their connection

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Types and dimensions for coupling bores and their connection ICS 21.120.20 J19 National Standards of People's Republic of China Replacing GB/T 3852-2008 Coupling shaft hole and coupling type and size 2017-05-12 released 2017-12-01 implementation General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China China National Standardization Management Committee released Directory Preface I 1 Scope 1 2 normative reference document 1 3 type and code 1 4 size 3 5 Coupling Marking and Example 11 Reference 14

Foreword

This standard is drafted in accordance with the rules given in GB/T 1.1-2009. This standard replaces GB/T 3852-2008 "Coupling shaft hole and coupling type and size". The main technical changes compared with GB/T 3852-2008 are as follows. --- the table 1 in the Y-type, Z-type and Z1-type shaft hole column content to do the appropriate changes; --- "Table 1 in the" hole with long hole conical shaft hole "modified to" have a hole of the cone-shaped shaft hole "; --- Table 3 in the shaft hole length 18,22 were changed to 16,20, an increase of 900,1000 two lengths; --- The length L1 of Table 4 is divided into "long series" and "short series"; --- Table 4 in the diameter dz limit deviation H10 to H8, and the corresponding deviation of the value of the corresponding adjustments; In Table 4, the diameter 6,7 increases the L1 value "18" and the d1 value "16", the diameter 8, 9 increases the L1 value "22" and the d1 value "24" Diameter 10,11 increases the L1 value "25" and the d1 value "28"; --- Change the limit of the "hole dz" in Table 6 to "axis, hole with code" and change all values to H8/k8 code; --- rectangular spline shaft hole and involute spline shaft hole coupling mark unified with Figure 2 said; --- the contents of the standard editorial changes, some of the contents of the value of the amendment. This standard is proposed and assigned by the National Committee on Standardization of Machine Shaft and Accessories (SAC/TC109). This standard drafting unit. in the machine productivity promotion center, Taiyuan Heavy Industry Co., Ltd., Yueqing City coupling plant, Zhejiang Huatai coupling Limited company. The main drafters of this standard. Ming Cuixin, Wang Xiaoling, Huang Xiaojing, Zheng Xiangping, Li Haibin. This standard replaced the previous version of the standard release. GB 3852-1983, GB/T 3852-1997, GB/T 3852-2008. Coupling shaft hole and coupling type and size

1 Scope

This standard specifies the type and code of the coupling shaft hole, size and markings and examples. This standard applies to key-connected cylindrical shaft holes, 1. 10 conical shaft holes and spline-coupled spline hole couplings.

2 normative reference documents

The following documents are indispensable for the application of this document. For dated references, only the dated edition applies to this article Pieces. For undated references, the latest edition (including all modifications) applies to this document. Dimensions of GB/T 1095 flat keyway GB/T 1144 Rectangular spline dimensions, tolerances and tests GB/T 1184 Shapes and position tolerances Not specified Tolerance values GB/T 1570 Conical Shaft Extension GB/T 3478.1 Cylindrical straight teeth involute splines (metric series of teeth) Part 1. General GB/T 11334 Geometrical product specifications (GPS) Cone tolerance

3 type and code

3.1 Shaft hole type and code in Table 1. Table 1 Shaft hole type and code Name Type and Code Icon Remark Cylindrical Shaft hole Y Applicable to long, short series, Recommended short series There is a hole in the hole Short cylindrical Shaft hole Type J recommended ......
