GB/T 38276-2019: Lubrication system - Terminology and graphical symbols
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 38276-2019	599	Add to Cart	5 days	Lubrication system - Terminology and graphical symbols	Valid

Similar standards

GB/T 40565.3   GB/T 40565.2   JB/T 8872   GB/T 38275   GB/T 38274

Basic data

Standard ID: GB/T 38276-2019 (GB/T38276-2019)
Description (Translated English): Lubrication system - Terminology and graphical symbols
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: J21
Classification of International Standard: 21.260
Word Count Estimation: 30,366
Date of Issue: 2019-12-10
Date of Implementation: 2020-07-01
Issuing agency(ies): State Administration for Market Regulation, China National Standardization Administration

GB/T 38276-2019: Lubrication system - Terminology and graphical symbols

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
(Lubrication systems Terms and graphic symbols) ICS 21.260 J21 National Standards of People's Republic of China Lubrication system terms and graphic symbols 2019-12-10 release 2020-07-01 implementation State Administration of Market Supervision Published by the National Standardization Management Committee

Contents

Foreword III 1 Scope 1 2 Normative references 1 3 Lubrication system terminology 1 3.1 Basic Terminology 1 3.2 Lubrication System Type 3 3.3 Fuel tank 4 3.4 Pump 4 3.5 Heater 5 3.6 Cooler 5 3.7 Filter 5 3.8 Valve 6 3.9 Control and detection 8 3.10 Pipeline 9 4 Graphic symbols 10 4.1 Graphical symbols for lubrication system 10 4.2 Graphic Symbols Instructions 17 Appendix A (Normative Appendix) Graphic Symbols Instructions 18 Index 19

Foreword

This standard was drafted in accordance with the rules given in GB/T 1.1-2009. This standard was proposed and managed by the National Metallurgical Equipment Standardization Technical Committee (SAC/TC409). This standard was drafted. Sichuan Chuanrun Hydraulic Lubrication Equipment Co., Ltd., Qidong Lubrication Equipment Co., Ltd., Anhui Ningguo Zhongtian Environmental Protection Equipment Equipment Co., Ltd., Taiyuan Tongze Heavy Industry Co., Ltd., China National Heavy Machinery Research Institute Co., Ltd. The main drafters of this standard. Zhu Qiang, Wang Xinyu, Liu Weilin, Liu Fulan, Wu Guobin, Gong Xiangrong, Wang Pengfei, Su Jing, Xia Juan. Lubrication system terms and graphic symbols

1 Scope

This standard defines terms and graphical symbols for lubrication systems. This standard applies to scientific research, engineering and technical documents, publications, terminology and graphical symbols of lubrication systems.

2 Normative references

The following documents are essential for the application of this document. For dated references, only the dated version applies to this article Pieces. For undated references, the latest version (including all amendments) applies to this document. GB/T 786.1-2009 Graphic symbols and circuit diagrams for fluid power systems and components. Part 1. For general use and data processing Graphic symbols GB/T 6567.2-2008 Graphic symbols for technical drawing piping systems GB/T 6567.3-2008 Graphical symbols for technical drawing pipeline systems GB/T 6567.4-2008 Graphical symbols for technical drawing of piping systems Valves and control elements

3 Lubrication system terminology

3.1 Basic Terminology 3.1.1 Lubrication system A system for supplying lubricant (3.1.4) to friction pairs (3.1.10) of machinery and equipment. 3.1.2 Thin oil lubrication system Lubrication system (3.1.1) using lubricant (3.1.5) as lubricant (3.1.4). 3.1.3 Dry oil lubrication system greaseslubricationsystem Lubrication system (3.1.1) using grease (3.1.6) as lubricant (3.1.4). 3.1.4 Lubricant Lubricating medium used to reduce the friction resistance of friction pair (3.1.10) and slow its wear. 3.1.5 Lube oil Liquid lubricants such as mineral oil and synthetic oil (3.1.4). 3.1.6 Grease greases Greasy semi-solid plastic lubricant (3.1.4). ......
