GB/T 38206.4-2021 English PDFUS$334.00 · In stock
Delivery: <= 4 days. True-PDF full-copy in English will be manually translated and delivered via email. GB/T 38206.4-2021: Methods to assess the reliability of pneumatic components - Part 4: Pressure regulators Status: Valid
Basic dataStandard ID: GB/T 38206.4-2021 (GB/T38206.4-2021)Description (Translated English): Methods to assess the reliability of pneumatic components - Part 4: Pressure regulators Sector / Industry: National Standard (Recommended) Classification of Chinese Standard: J20 Word Count Estimation: 18,110 Issuing agency(ies): State Administration for Market Regulation, China National Standardization Administration GB/T 38206.4-2021: Methods to assess the reliability of pneumatic components - Part 4: Pressure regulators---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order. Methods to assess the reliability of pneumatic components - Part 4.Pressure regulators ICS 23.100.01 CCSJ20 National Standards of People's Republic of China Reliability Evaluation Method of Pneumatic Components Part 4.Pressure regulator (ISO.19973-4.2014, Pneumaticfluidpower-Assessmentofcomponent Released on 2021-08-20 2022-03-01 implementation State Administration of Market Supervision and Administration Issued by the National Standardization Management Committee Table of contentsForeword Ⅲ Introduction Ⅳ 1 Scope 1 2 Normative references 1 3 Terms and definitions 2 4 Symbols and units 2 5 Test equipment 2 6 Test condition 3 7 Test procedure 4 8 Failure determination and threshold level 5 9 Data Analysis 6 10 Test report 6 11 Marking description 6 Appendix A (informative) The test flow chart specified in this document 7 Appendix B (Informative) Optional extended test circuit 8 Appendix C (Informative) Test Record Form 10 Reference 13ForewordThis document is in accordance with the provisions of GB/T 1.1-2020 "Guidelines for Standardization Work Part 1.Structure and Drafting Rules of Standardization Documents" Drafting. This document is the fourth part of GB/T 38206 "Pneumatic Components Reliability Evaluation Method". GB/T 38206 has released the following part. ---Part 1.General procedures; ---Part 2.Reversing valve; ---Part 3.Cylinder with piston rod; ---Part 4.Pressure regulator; ---Part 5.Check valve, shuttle valve, double pressure valve (and valve), one-way throttle valve and quick discharge valve. This document is equivalent to ISO.19973-4.2014 "Test and Evaluation of Reliability of Pneumatic Components Part 4.Pressure Regulator". This document has made the following minimal editorial changes. --- In order to coordinate with existing standards, the standard name is changed to "Pneumatic Components Reliability Evaluation Method Part 4.Pressure Regulator". Please note that some of the contents of this document may involve patents. The issuing agency of this document is not responsible for identifying patents. This document was proposed by China Machinery Industry Federation. This document is under the jurisdiction of the National Hydraulic and Pneumatic Standardization Technical Committee (SAC/TC3). Drafting organizations of this document. Bailing Pneumatic Technology Co., Ltd., Zhejiang Yiri Pneumatic Technology Co., Ltd., Huaibei Hezhong Machinery Equipment Co., Ltd. Company, Beijing University of Aeronautics and Astronautics, National Pneumatic Product Quality Supervision and Inspection Center, Yueqing Hengyi Pneumatic Co., Ltd., Fujian Heima Valve Co., Ltd. Company, Beijing Machinery Industry Automation Research Institute Co., Ltd. The main drafters of this document. Jiao Zhongliang, Chen Xumin, Ren Cheli, Liu Jichao, Shi Yan, Guo Lili, Zhu Lefei, Wu Hongwei, Cao Qiaohui.IntroductionIn a pneumatic system, power is transmitted and controlled by compressed air in the loop. The pneumatic system consists of a variety of components, which are various An important part of the type of machines and equipment. Efficient and economical production requires highly reliable machines and equipment. GB/T 38206 aims to Establish the reliability assessment method of pneumatic components, which consists of five parts. ---Part 1.General procedures. The purpose is to specify the general procedures, general test conditions, and calculations used to assess the reliability of pneumatic components. Calculation methods, data evaluation methods, and requirements for writing test reports. ---Part 2.Reversing valve. The purpose is to specify the test equipment, test conditions, test procedures, and reliability for evaluating the reliability of the directional valve Threshold value and processing method of test results. ---Part 3.Cylinder with piston rod. The purpose is to provide for the evaluation of the reliability of cylinders with piston rods (including single-acting and double-acting) Test equipment, test conditions, test procedures, reliability thresholds and test results processing methods. ---Part 4.Pressure regulating valve. The purpose is to specify the test procedures, test equipment and reliability thresholds for the reliability evaluation of pneumatic pressure regulators And how to deal with the test results. ---Part 5.Check valve, shuttle valve, double pressure valve (and valve), one-way throttle valve and quick discharge valve. The purpose is to provide for the evaluation of check valves, first Pilot check valve, shuttle valve, double pressure valve (and valve), one-way throttle valve and quick exhaust valve reliability test equipment, test conditions, test procedures Order, reliability thresholds and processing methods of test results. This document is used to provide the necessary equipment and test conditions in order to evaluate the inherent reliability of the pneumatic pressure regulator. It is necessary for producers to understand the reliability of pneumatic system components in their equipment. The reliability of the components can be determined by laboratory tests; mastered With the reliability characteristics of the components, the manufacturer can build a system model and make decisions about service intervals, spare parts inventory, and future improvements. Decide. There are three basic levels to determine the reliability of components. a) Preliminary design analysis. finite element analysis (FEA), failure mode and consequence analysis (FMEA); b) Laboratory tests and establishment of reliability models. physical mechanism of failure, reliability prediction, pre-production evaluation; c) On-site data collection. maintenance report, quality analysis report. Each level has its own application during the life of the component. Preliminary design analysis helps to identify possible failure modes and eliminate the cause of failure Or reduce the impact of failure on reliability. When the component samples are obtained, the reliability test can be carried out in the laboratory and the initial availability can be determined. Reliability. Reliability test, as a continuous evaluation of component reliability, often continues to the initial production and runs through the entire production process. exist When the component continues to work and its failure data is available, field data can be collected. Reliability Evaluation Method of Pneumatic Components Part 4.Pressure regulator1 ScopeThis document specifies the test procedures, test equipment and reliability thresholds for the reliability assessment of pneumatic pressure regulators, as well as the processing methods of test results. This document applies to direct-acting pressure regulators and external pilot-operated pressure regulators, including relief and non-relief pressure regulators. This document applies to the first failure without maintenance, except for some abnormal values. This document does not apply to pressure regulators with regular drain holes. Note. See Appendix A for the test procedures specified in this document.2 Normative referencesThe contents of the following documents constitute the indispensable clauses of this document through normative references in the text. Among them, dated quotations Only the version corresponding to that date is applicable to this document; for undated reference documents, the latest version (including all amendments) is applicable to This document. ISO 1219-1 Graphical symbols and circuit diagrams of fluid power transmission systems and components-Part 1.Used for general purpose and data processing Graphical symbols (Fluidpowersystemsandcomponents-Graphicalsymbolsandcircuitdiagrams-Part 1. Graphicalsymbolsforconventionaluseanddata-processingapplication) Note. GB/T 786.1-2021 Graphical symbols and circuit diagrams of fluid power transmission systems and components Part 1.Graphical symbols (ISO 1219-1.2012, IDT) ISO 5598 Fluid power systems and components-Vocabulary (Fluidpowersystemsandcomponents-Vocabulary) Note. GB/T 17446-2012 Fluid Power System and Components Vocabulary (ISO 5598.2008, IDT) ISO 6953-1 Pneumatic Pressure Reducing Valves and Filter Pressure Reducing Valves Part 1.The main characteristics and product identification requirements that should be included in the business documents Seek (Pneumaticfluidpower-Compressedairpressureregulatorsandfilter-regulators-Part 1.Main characteristicstobeincludedinliteraturefromsuppliersandproduct-markingrequirements) Note. GB/T 20081.1-2021 Pneumatic pressure reducing valve and filter pressure reducing valve Part 1.Main characteristics and product identification requirements to be included in commercial documents Seek (ISO 6953-1.2015, IDT) ISO 6953-3 Pneumatic pressure reducing valves and filter pressure reducing valves Part 3.Alternative methods for testing the flow characteristics of pressure reducing valves (Pneumatic fluid power-Compressed air pressure regulators and filter-regulators-Part 3. Alternativetestmethodsformeasuringtheflow-ratecharacteristicsofpressureregulators) Note. GB/T 20081.3-2021 Pneumatic pressure reducing valves and filter pressure reducing valves Part 3.Alternative methods for testing the flow characteristics of pressure reducing valves (ISO 6953-3. 2012, IDT) ISO.19973-1.2015 Test and Evaluation of Reliability of Pneumatic Components Part 1.General Procedure (Pneumaticfluid power-Assessmentofcomponentreliabilitybytesting-Part 1.Generalprocedures) Note. GB/T 38206.1-2019 Pneumatic component reliability assessment method Part 1.General procedure (ISO.19973-1.2015, MOD) ISO 80000-1 Quantity and Units Part 1.General (Quantities and Units-Part 1.General) IEC 60050-192 International Electrotechnical Terminology Part 192.Reliability [InternationalElectrotechnicalVocabulary (IEV)-Part 192.Dependability] Note. GB/T 2900.99-2016 credibility of electrotechnical terminology (IEC 60050-192.2015, IDT) ......Tips & Frequently Asked Questions:Question 1: How long will the true-PDF of GB/T 38206.4-2021_English be delivered?Answer: Upon your order, we will start to translate GB/T 38206.4-2021_English as soon as possible, and keep you informed of the progress. The lead time is typically 2 ~ 4 working days. The lengthier the document the longer the lead time.Question 2: Can I share the purchased PDF of GB/T 38206.4-2021_English with my colleagues?Answer: Yes. The purchased PDF of GB/T 38206.4-2021_English will be deemed to be sold to your employer/organization who actually pays for it, including your colleagues and your employer's intranet.Question 3: Does the price include tax/VAT?Answer: Yes. Our tax invoice, downloaded/delivered in 9 seconds, includes all tax/VAT and complies with 100+ countries' tax regulations (tax exempted in 100+ countries) -- See Avoidance of Double Taxation Agreements (DTAs): List of DTAs signed between Singapore and 100+ countriesQuestion 4: Do you accept my currency other than USD?Answer: Yes. If you need your currency to be printed on the invoice, please write an email to Sales@ChineseStandard.net. In 2 working-hours, we will create a special link for you to pay in any currencies. Otherwise, follow the normal steps: Add to Cart -- Checkout -- Select your currency to pay. |
