GB/T 37266-2018 English PDF

Q: How long will the true-PDF of English version of GB/T 37266-2018 be delivered?

Upon your order, we will start to translate GB/T 37266-2018_English as soon as possible, and keep you informed of the progress. The lead time is typically in 24 hours. The lengthier the document the longer the lead time.

Q: Can I share the purchased PDF of GB/T 37266-2018_English with my colleagues?

Yes. The purchased PDF of GB/T 37266-2018_English will be deemed to be sold to your employer/organization who actually pays for it, including your colleagues and your employer's intranet.

Q: Does the price include tax/VAT?

Yes. Our tax invoice, downloaded/delivered in 9 seconds, includes all tax/VAT and complies with 100+ countries' tax regulations (tax exempted in 100+ countries). Avoidance of Double Taxation Agreements (DTAs) between Singapore and 100+ Countries: https://www.iras.gov.sg/taxes/international-tax

Q: Do you accept my currency other than USD?

Yes. If you need your currency to be printed on the invoice, please write an email to Sales@ChineseStandard.net. In 2 working-hours, we will create a special link for you to pay in any currencies. Otherwise, follow the normal steps: Add to Cart -- Checkout -- Select your currency to pay.

US$878.00 · In stock
Delivery: <= 1 days. True-PDF full-copy in English will be manually translated and delivered via email.
GB/T 37266-2018: Point supporting device for curtain wall
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 37266-2018	878	Add to Cart	1 days	Point supporting device for curtain wall	Valid

Similar standards

GB/T 13554 JG/T 125 GB/T 14370 GB/T 32223 GB/T 11981

Basic data

Standard ID: GB/T 37266-2018 (GB/T37266-2018)
Description (Translated English): Point supporting device for curtain wall
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: Q73
Classification of International Standard: 91.060
Word Count Estimation: 44,476
Date of Issue: 2018-12-28
Date of Implementation: 2019-11-01
Regulation (derived from): National Standard Announcement No. 17 of 2018
Issuing agency(ies): State Administration for Market Regulation, China National Standardization Administration

GB/T 37266-2018: Point supporting device for curtain wall

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Point supporting device for curtain wall ICS 91.060 Q73 National Standards of People's Republic of China Point support device for building curtain wall Published on.2018-12-28 2019-11-01 implementation State market supervision and administration China National Standardization Administration issued

Content

Foreword III 1 Scope 1 2 Normative references 1 3 Terms and Definitions 1 4 Classification and Marking 5 5 Material 9 6 Requirements 9 7 Test method 12 8 Inspection rules 14 9 Product logo, certificate of conformity, quality assurance and instruction manual 15 10 Packaging, transport and storage 16 Appendix A (informative appendix) Connector and clamping head construction 17 Appendix B (informative) Claw structure 21 Appendix C (informative) Number and shape of claw arms 23 Appendix D (informative) Fixture construction 25 Appendix E (informative) Design method for selection of mechanical properties of point support devices 28 Appendix F (Normative Appendix) Test Method for Mechanical Properties of Joints and Clamping Heads 29 Appendix G (Normative Appendix) Test Method for Mechanical Properties of Claw Parts 32 Appendix H (Normative) Test Methods for Mechanical Properties of Fixtures 36

Foreword

This standard was drafted in accordance with the rules given in GB/T 1.1-2009. This standard was proposed by the Ministry of Housing and Urban-Rural Development of the People's Republic This standard is under the jurisdiction of the National Building Curtain Wall Door and Window Standardization Technical Committee (SAC/TC448). This standard was drafted. Guangdong Jianlang Hardware Products Co., Ltd., China Academy of Building Research Institute, Shanghai Jianke Inspection Co., Ltd., Guangdong Provincial Academy of Building Research Group Co., Ltd., China Building Standard Design and Research Institute Co., Ltd., Shenzhen Xinshan Curtain Wall Technology Consulting Co., Ltd., Shenzhen Jinyue Curtain Wall Decoration Engineering Co., Ltd., Shenyang Yuanda Aluminum Engineering Co., Ltd., Jianghe Creation Group Co., Ltd., Shenzhen Sanxin Technology Development Co., Ltd., Guangdong Century Construction Group Co., Ltd., Guangdong Jianyijia Hardware Products Limited company. The main drafters of this standard. Liu Jianchun, Du Wanming, Wang Hongtao, Xu Qin, Li Wei, Hao Wei, Dou Tibo, Wan Shuchun, Wang Shuangjun, Yu Jun, Hua Dingxing, Chen Guangzhang, Shang Jingyu. Point support device for building curtain wall

1 Scope

This standard specifies the classification and marking, materials, requirements, test methods, inspection rules, product marks, and joints of point support devices for building curtain walls. Qualification, quality assurance and instructions for use, packaging, transportation and storage. This standard is applicable to point support devices for building curtain walls. Point support devices such as lighting roofs, awnings and guardrails can be referred to.

2 Normative references

The following documents are indispensable for the application of this document. For dated references, only dated versions apply to this article. Pieces. For undated references, the latest edition (including all amendments) applies to this document. GB/T 193 Ordinary Thread Diameter and Pitch Series GB/T 196 basic thread basic size GB/T 197-2018 Ordinary thread tolerance GB/T 228.1-2010 tensile testing of metallic materials - Part 1 GB/T 1184-1996 Shape and position tolerances without tolerance values GB/T 1220 stainless steel rod GB/T 1804-2000 General tolerances and tolerances for linear and angular dimensions without tolerances GB/T 2100 general corrosion resistant steel castings GB/T 2828.1-2012. Sampling and sampling procedures - Part 1 . Batch-to-batch sampling plan searched by AQL GB/T 3098.6 Mechanical properties of fasteners Stainless steel bolts, screws and studs GB/T 3098.15 fastener mechanical properties stainless steel nut GB/T 3280 stainless steel cold rolled steel plate and strip GB/T 4226 stainless steel cold-worked steel rod GB/T 4237 stainless steel hot rolled steel sheet and strip GB/T 4238 heat-resistant steel plate and strip GB/T 9969 General guidelines for the use of industrial products GB/T 14436 General Rules for Industrial Product Assurance Documents GB/T 16825.1 Inspection of static single-axis testing machines - Part 1 . Examination and calibration of tensile force and/or pressure testing machines GB/T 20878 Stainless steel and heat resistant steel grades and chemical composition GB/T 22095-2008 cast iron plate GB/T 34327 Building curtain wall terminology

3 Terms and definitions

The following terms and definitions as defined in GB/T 34327 apply to this document. 3.1 Point support device pointsupportingdevice The panel is directly supported and fixed in a point connection, and the components that the panel is subjected to are transmitted. ......
