US$279.00 · In stock
Delivery: <= 3 days. True-PDF full-copy in English will be manually translated and delivered via email.
GB/T 36273-2018: Digital interface technical specification for relaying protection and security automatic equipment in smart substation
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 36273-2018	279	Add to Cart	3 days	Digital interface technical specification for relaying protection and security automatic equipment in smart substation	Valid

Similar standards

GB/T 38953 GB/T 37155.2 GB/T 19826 GB/T 45648.2 GB/T 36283

Basic data

Standard ID: GB/T 36273-2018 (GB/T36273-2018)
Description (Translated English): Digital interface technical specification for relaying protection and security automatic equipment in smart substation
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: K45
Classification of International Standard: 29.240
Word Count Estimation: 14,160
Date of Issue: 2018-06-07
Date of Implementation: 2019-01-01
Issuing agency(ies): State Administration for Market Regulation, China National Standardization Administration

GB/T 36273-2018: Digital interface technical specification for relaying protection and security automatic equipment in smart substation

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Digital interface technical specification for relaying protection and security automatic equipment in smart substation ICS 29.240 K45 National Standards of People's Republic of China Intelligent Substation Relay Protection and Safety Automatic Device Digital Interface Specification Published on.2018-06-07 2019-01-01 Implementation National Market Supervision Administration China National Standardization Administration released Directory Preface I 1 Scope 1 2 Normative references 1 3 Terms and Definitions, Abbreviations 1 4 General 2 5 Virtual Terminal Interface Specification 2 6 Physical Interface Specification 2 7 Platen Configuration 3 8 Process Layer Secondary Loop Modeling 3 9 Requirements for related equipment 3 10 Project Configuration File 4 Appendix A (Informative) Loop Example Configuration File Format Requirements 6

Foreword

This standard was drafted in accordance with the rules given in GB/T 1.1-2009. Please note that some of the contents of this document may involve patents. The issuing agency of this document does not assume responsibility for identifying these patents. This standard is proposed and managed by the China Electricity Council. This standard was drafted by. China Electric Power Engineering Consulting Group Northeast Electric Power Design Institute Co., Ltd., Nanjing Nanrui Jibao Electric Co., Ltd. State Grid Jiangsu Electric Power Company Electric Power Research Institute, State Grid Corporation of China National Electric Power Dispatch Control Center, China Southern Power Grid Co., Ltd. Division, State Grid Chongqing Electric Power Company, State Grid Yubei Electric Power Co., Ltd., Guangdong Power Grid Co., Ltd. Power Dispatching Control Center, Power Planning General Hospital Co., Ltd., State Grid Hunan Electric Power Company Electric Power Research Institute, State Grid Henan Electric Power Company Electric Power Research Institute, Guizhou Power Grid Electric Power Science Research Institute, Beijing Sifang Jibao Automation Co., Ltd., Xuji Group Co., Ltd., Guodian Nanjing Auto Chemical Corporation. The main drafters of this standard. Zhang Zhonghua, Lu Hang, Gao Lei, Li Tiemin, Li Li, Jiang Hang, Shi Zebing, Song Liangliang, Zeng Zhian, Gao Xu, Deng Xuyang, Chen Zhirong, Zhu Weijun, Han Wei, Wang Yu, Sun Xiaoyong, Yan Jun, Wang Zengchao, Yao Liang, Su Liming, Deng Maojun. Intelligent Substation Relay Protection and Safety Automatic Device Digital Interface Specification

1 Scope

This standard specifies the virtual terminal interface specification for smart substation relay protection and safety automation devices, the physical interface specification for the process layer, and the pressure plate Configuration, process layer secondary loop modeling, requirements for related equipment, project configuration files. This standard is applicable to various relay protection and safety automatic devices of 110kV (66kV) and above voltage classes in smart substations. The device is referred to as "device" below and is referenced to a device with a voltage rating of 110 kV (66 kV) or less.

2 Normative references

The following documents are indispensable for the application of this document. For dated references, only dated versions apply to this article Pieces. For undated references, the latest version (including all amendments) applies to this document. GB/T 14285-2006 Technical specifications for relay protection and safety automatic devices GB/T 30155-2013 Technical Guidelines for Smart Substations GB/T 32890-2016 Relay protection IEC 61850 engineering application model GB/T 34132-2017 Smart Substation Intelligent Terminal Device General Specifications GB/T 51071-2014 330kV~750kV intelligent substation design specification GB/T 51072-2014 110(66)kV~220kV Intelligent Substation Design Specification DL/T 282 Merging Unit Technical Conditions DL/T 860 (all parts) Substation Communication Network and System DL/T 1663-2016 Smart Substation Relay Protection Online Monitoring and Intelligent Diagnostic Technical Guidelines 3 Terms and Definitions, Abbreviations 3.1 Terms and Definitions GB/T 14285-2006, GB/T 30155-2013, GB/T 51071-2014, GB/T 51072-2014, DL/T 860, The terms and definitions defined in DL/T 282 apply to this document. 3.2 Abbreviations The following abbreviations apply to this document. CID. IED instance configuration (ConfiguredIEDDescription) CRC. Cyclic Redundancy Check GOOSE. GenericObjectOrientedSubstationEvents for Generic Object Substation Events ICD. IEDCapabilityDescription IED. Intelligent Electronic Device (InteligentElectronicDevice) SCD. Substation Configuration Description SSD. System Specification Description ......
