GB/T 34374-2017 English PDF

US$119.00 · In stock
Delivery: <= 3 days. True-PDF full-copy in English will be manually translated and delivered via email.
GB/T 34374-2017: Stamping dies -- L-shaped guide plates
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 34374-2017	119	Add to Cart	3 days	Stamping dies -- L-shaped guide plates	Valid

Similar standards

GB/T 45677   GB/T 6110   JB/T 3943   GB/T 45382   GB/T 45361

Basic data

Standard ID: GB/T 34374-2017 (GB/T34374-2017)
Description (Translated English): Stamping dies -- L-shaped guide plates
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: J46
Classification of International Standard: 25.120.10
Word Count Estimation: 6,663
Date of Issue: 2017-09-29
Date of Implementation: 2018-04-01
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China

GB/T 34374-2017: Stamping dies -- L-shaped guide plates

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Stamping dies - L-shaped guide plates ICS 25.120.10 J46 National Standards of People's Republic of China Die L-shaped guide plate (ISO 16366.2008, Toolsforpressing-L-shapedguides, MOD) 2017-09-29 Posted 2018-04-01 implementation General Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China China National Standardization Administration released

Foreword

This standard was drafted in accordance with the rules given in GB/T 1.1-2009. This standard uses redrafted law revision using ISO 16366.2008 "die L-shaped guide plate." This standard and ISO 16366.2008 technical differences and the reasons are as follows. --- In the "range" added "This standard applies to die L-shaped guide plate" to meet the national standards; --- On normative references, this standard made a technical difference with the adjustment to adapt to China's technical conditions, adjust the situation Concentration reactions in the second chapter "Normative references", the specific adjustments are as follows. ● Replaced ISO 4762 with GB/T 70.1 modified to international standards (see Table 1); ● Replace ISO 8733 with GB/T 120.1 equivalent to international standards (see Table 1); ● Replace ISO 2768-1 with GB/T 1804 equivalent to international standards (see Chapter 3); ● Replace ISO 13715 with GB/T 19096 equivalent to international standards (see Chapter 3); --- Modify the cross-section of the parts in Figure 1, a clear relationship between the various components; --- Modify the part 2 in Figure 2, the screw hole and counterbore painting method, in line with the national standard mechanical drawing; --- Increased in the main view of Figure 2 hole d2 1 projection line, clear and accurate and in line with the national standard mechanical drawing; --- In Fig. 2, all the symbols representing the diameter of the circle are marked with φ, which is in accordance with the national standard of mechanical drawing; --- Figure 2 on the left side of the main view of the size of the box l1 removed, and the other two l1 consistent with the label; --- Remove the excess φ after table d2 to meet the national standard; --- Modify the markings to meet the national standards; --- Removed the "reference", its content is an optional element, no actual reference. This standard by the National Mold Standardization Technical Committee (SAC/TC33) and focal point. The main drafting units of this standard. Guilin Electric Institute of Science and Technology Co., Ltd., Youde Precision Industry (Kunshan) Co., Ltd., Jiangsu Province Precision Mold Product Quality Supervision and Inspection Center, Dongguan is the standard detection Technology Co., Ltd., Chuzhou City, exquisite appliances limited liability company. The main drafters of this standard. Feng Shuang, Tao Yu, Zhang Jun, Hu Sai Lin, Zhang Lei, Wang Chong, Yang Jiahua, Wang Haoshen. Die L-shaped guide plate

1 Scope

This standard specifies the die L-shaped guide with the main dimensions and tolerances (application examples shown in Figure 1). This standard also specifies the L-shaped guide mark. This standard applies to die L-shaped guide plate. Description. 1 --- L-shaped guide plate; 2 --- guide slide; 3 --- Die parts. Figure 1 L-shaped guide plate application examples

2 Normative references

The following documents for the application of this document is essential. For dated references, only the dated version applies to this article Pieces. For undated references, the latest edition (including all amendments) applies to this document. GB/T 70.1 Hexagon socket head cap screws (GB/T 70.1-2008, ISO 4762.2004, MOD) GB/T 120.1 internally threaded cylindrical pins not hardened steel and austenitic stainless steel (GB/T 120.1-2000, eqvISO 8733.) 1997) GB/T 1804-2000 General tolerances Tolerances for linear and angular dimensions without tolerance (eqvISO 2768-1.1989) GB/T 19096 technical drawings and drawings is not defined by the definition of the shape of the terms and Notes (GB/T 19096-2003, ISO 13715.2000, IDT)

3 size

L-shaped guide plate size shown in Figure 2 and Table 1. Undefined shape edge should be consistent with the provisions of GB/T 19096. General tolerances should be consistent with GB/T 1804-2000 Chapter 5 m-level provisions. ......
