GB/T 34363-2017: Non-destructive testing -- Test method for fabricating and checking aluminum alloy ultrasonic standard reference blocks
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 34363-2017	319	Add to Cart	3 days	Non-destructive testing -- Test method for fabricating and checking aluminum alloy ultrasonic standard reference blocks	Valid

Similar standards

GB/T 35839   GB/T 35977   GB/T 34018   GB/T 34361   GB/T 34357

Basic data

Standard ID: GB/T 34363-2017 (GB/T34363-2017)
Description (Translated English): Non-destructive testing -- Test method for fabricating and checking aluminum alloy ultrasonic standard reference blocks
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: J04
Classification of International Standard: 19.100
Word Count Estimation: 16,175
Date of Issue: 2017-09-29
Date of Implementation: 2018-04-01
Quoted Standard: GB/T 12604.1; GB/T 20737; GB/T 28880
Regulation (derived from): National Standard Notice 2017 No. 23
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China
Summary: This standard specifies the aluminum alloy ultrasonic standard test block recommended group, production procedures, physical characteristics of the calibration procedure and ultrasonic response verification procedures. This standard specifies the aluminum alloy standard test block for ultrasonic testing equipment performance verification can also be used for aluminum alloy products ultrasonic (longitudinal wave) pulse reflection (direct contact or immersion) testing calibration and control.

GB/T 34363-2017: Non-destructive testing -- Test method for fabricating and checking aluminum alloy ultrasonic standard reference blocks

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Non-destructive testing - Test method for fabricating and checking aluminum alloy ultrasonic standard reference blocks ICS 19.100 J04 National Standards of People's Republic of China Nondestructive testing aluminum alloy ultrasonic standard test block Production and verification methods 2017-09-29 Posted 2018-04-01 implementation General Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China China National Standardization Administration released Directory Foreword Ⅲ 1 Scope 1 2 Normative references 1 3 Terms and definitions 1 4 Method summary 1 5 meaning and purpose 2 6 standard test block recommended group 2 7 standard test block material 5 8 standard test block material quality 5 9 standard test block production process 6 10 Physical Characteristics Verification Program 7 11 ultrasonic response characteristic verification program 7 12 Report 13

Foreword

This standard was drafted in accordance with the rules given in GB/T 1.1-2009. This standard by the National Standardization Technical Committee nondestructive testing (SAC/TC56) and focal point. This standard was drafted. Shanghai Aerospace Precision Machinery Research Institute, Shanghai Institute of Materials, China Aviation Industry Corporation Beijing Aviation Materials Material Research Institute, Shandong Ruixiang Die Co., Ltd. The main drafters of this standard. Li to Ping, Zhou Jianping, Zhou Chao, Zhou Jun, Shi Wei, Liang Jing, Wei Zhongrui, Meng Fan Bao, Jin Yufei, Ding Jie. Nondestructive testing aluminum alloy ultrasonic standard test block Production and verification methods

1 Scope

This standard specifies the aluminum alloy ultrasonic standard test block recommended group, production procedures, physical characteristics of the calibration procedure and ultrasonic response verification procedures. This standard specifies the aluminum alloy standard test block for ultrasonic testing equipment performance verification can also be used for aluminum products ultrasonic (P wave) pulse Reflective (direct contact or immersion) calibration and control of the test.

2 Normative references

The following documents for the application of this document is essential. For dated references, only the dated version applies to this article Pieces. For undated references, the latest edition (including all amendments) applies to this document. GB/T 12604.1 Non-destructive testing - Ultrasonic testing GB/T 20737 non-destructive testing common terms and definitions GB/T 28880 nondestructive testing without electronic measuring instruments pulse reflection ultrasonic testing system performance characteristics of the assessment

3 Terms and definitions

GB/T 12604.1 and GB/T 20737 and defined by the following terms and definitions apply to this document. 3.1 Angle error angularerror The maximum number of shots received by the probe from the standard test block or the maximum back reflection and the response of the bottom of the flat bottom hole is not the maximum. when Ultrasonic incident surface, hole bottom and back are not parallel when there will be angular error. 3.2 Area-amplitude response curve area-amplituderesponsecurve When the distance from the probe is the same, the response curves of the reflectors with different areas and their ultrasonic responses correspond to each other. 3.3 Metal distance metaldistance Standard test block from the ultrasound incident surface to the bottom of the flat-bottomed hole distance. 3.4 Ultrasound response ultrasonicresponse The display height observed on the screen of the ultrasonic testing instrument reflects the amount of ultrasonic energy initially reflected by the standard test block from the bottom of the hole.

4 Method summary

4.1 The standard test block made of aluminum alloy material after ultrasonic testing should be no significant discontinuity, and then precision machining into a certain height of the circle Column test block, in the center of the back of the test block processing a constant depth, the provisions of the diameter of the flat bottom hole. Standard test block by flat-bottomed hole diameter, the total test block Degree or metal distance grouping. 4.2 Each standard test block using a calibrated ultrasonic testing system under the provisions of the detection frequency ultrasonic testing for each test block to establish phase ......
