GB/T 34134-2017 English PDF

US$199.00 · In stock
Delivery: <= 3 days. True-PDF full-copy in English will be manually translated and delivered via email.
GB/T 34134-2017: SELV plugs and socket-outlets for household and similar purposes 16 A 6 V, 12 V, 24 V, 48 V a.c. and d.c. - Types, basic parameters and dimensions
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 34134-2017	199	Add to Cart	3 days	SELV plugs and socket-outlets for household and similar purposes 16 A 6 V, 12 V, 24 V, 48 V a.c. and d.c. - Types, basic parameters and dimensions	Valid

Similar standards

GB/T 36277   GB/T 34130.1   GB/T 34130.21

Basic data

Standard ID: GB/T 34134-2017 (GB/T34134-2017)
Description (Translated English): SELV plugs and socket-outlets for household and similar purposes 16 A 6 V, 12 V, 24 V, 48 V a.c. and d.c. - Types, basic parameters and dimensions
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: K30
Classification of International Standard: 29.120.30
Word Count Estimation: 10,136
Date of Issue: 2017-07-31
Date of Implementation: 2018-02-01
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China

GB/T 34134-2017: SELV plugs and socket-outlets for household and similar purposes 16 A 6 V, 12 V, 24 V, 48 V a.c. and d.c. - Types, basic parameters and dimensions

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
SELV plugs and socket-outlets for household and similar purposes 16 A 6 V, 12 V, 24 V, 48 V acand dc - Types, basic parameters and dimensions ICS 29.120.30 K30 National Standards of People's Republic of China Household and Similar Safety Extra Low Voltage (SELV) AC and DC plug socket 16A6V, 12V, 24V, 48V type, the basic parameters and dimensions 12V, 24V, 48Va.c.andd.c.-Types, basicparametersanddimensions (IEC 60906-3.1994, IEC Systemofplugsandsocket-outletsforhouseholdand similarpurposes-Part 3.SELVplugsandsocket-outlets, 16A6V, 12V, 24V, 48V, acandd.c., MOD) 2017-07-31Published.2018-02-01 implementation General Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China China National Standardization Administration released Directory Preface Ⅰ 1 Scope 1 2 Normative references 1 3 technical requirements and test methods 1 Standard loose-leaf 1 24V, 50/60 Hz SELV socket and removable socket 2 Standard loose-leaf 2 24V, 50/60 Hz SELV connector 3 Standard loose-leaf 3 50/60 Hz SELV socket Position of coded groove under different voltages 4 Standard Loads 4 50/60 Hz SELV Plug Position of rib 5 at different voltages Standard loose-leaf 5 DC SELV socket Position of coded groove under different voltages 6 Standard loose leaf 6 Position of DC SELV plug at different voltage coding ribs 7

Foreword

This standard was drafted in accordance with the rules given in GB/T 1.1-2009. This standard uses redrafted law to amend the use of IEC 60906-3.1994 "IEC for household and similar purposes plug and socket Part 3. Safety Extra Low Voltage (SELV) Plug & Socket 16A6V, 12V, 24V, 48V AC and DC ". This standard and IEC 60906-3.1994 technical differences and the reasons are as follows. --- According to the relevant provisions of GB/T 1.1 and the standard reference documents, an increase of Chapter 2, "Normative references", tied Out of GB/T 2099.8. This standard made the following editorial changes. --- The standard name was changed to "Household and Similar Safety extra low voltage (SELV) AC and DC plug and socket 16A6V, 12V, 24V, 48V type, the basic parameters and dimensions "; --- According to the relevant provisions of GB/T 1.1, in Chapter 1 "Scope" in paragraph 1 added "This standard specifies the household and similar security All special low voltage (SELV) plug socket type, basic parameters and dimensions "; --- Because this standard adds Chapter 2 "normative references", so Chapter 2 of IEC 60906-3.1994 "technical requirements and Test Method "in this standard as Chapter 3. This standard proposed by the China Electrical Equipment Industry Association. This standard by the National Electrical Accessories Standardization Technical Committee (SAC/TC67) centralized. This standard was drafted unit. China Electric Apparatus Research Institute Co., Ltd., Hangzhou Hongyan Electric Co., Ltd., Zhejiang Chint Building Electric Co., Ltd. Company, Bulls Group Co., Ltd., Guangdong Red Wo Long Technology Industry Co., Ltd., Wei Kai Detection Technology Co., Ltd. The main drafters of this standard. Liqinqin, Wu Ming, Wang Fengqin, Zhang She Yu, Ruan Liping, Ho even, high hope, Cai Jun, Cai Yingfeng, Ye Xinsheng. Household and Similar Safety Extra Low Voltage (SELV) AC and DC plug socket 16A6V, 12V, 24V, 48V type, the basic parameters and dimensions

1 Scope

This standard specifies the type and basic parameters and dimensions of SELV plugs and sockets for household and similar purposes. This standard applies to indoor or outdoor use, household and similar purposes 6V, 12V, 24V, 48V DC or AC (50 / 60Hz) Safety Extra Low Voltage (SELV), 16A rated current, fixed or mobile sockets and appliance sockets.

2 Normative references

The following documents for the application of this document is essential. For dated references, only the dated version applies to this article Pieces. For undated references, the latest edition (including all amendments) applies to this document. GB/T 2099.8 plugs and socket outlets for household and similar use - Part 2-4 - Special plugs and sockets for safety extra low voltage (SELV) Seeking (GB/T 2099.8-2017, IEC 60884-2-4.2007, MOD)

3 technical requirements and test methods

Safety Extra Low Voltage (SELV) plugs and sockets shall comply with the relevant standard loose-leaf pages of this standard. In addition, the plug and socket should be consistent with GB/T 2099.8 all the relevant requirements. ......
