GB/T 33521.1-2017 English PDF

US$834.00 · In stock
Delivery: <= 4 days. True-PDF full-copy in English will be manually translated and delivered via email.
GB/T 33521.1-2017: Mechanical vibration -- Ground-borne noise and vibration arising from rail systems -- Part 1: General guidance
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 33521.1-2017	834	Add to Cart	4 days	Mechanical vibration -- Ground-borne noise and vibration arising from rail systems -- Part 1: General guidance	Valid

Similar standards

GB/T 34018   GB/T 33877   GB/T 32073   GB/T 33523.600   GB/T 33523.700   GB/T 33521.31

Basic data

Standard ID: GB/T 33521.1-2017 (GB/T33521.1-2017)
Description (Translated English): Mechanical vibration -- Ground-borne noise and vibration arising from rail systems -- Part 1: General guidance
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: J04
Classification of International Standard: 17.160
Word Count Estimation: 44,430
Date of Issue: 2017-02-28
Date of Implementation: 2017-09-01
Quoted Standard: ISO 2041
Adopted Standard: ISO 14837-1-2005, IDT
Regulation (derived from): National Standard Announcement No. 4 of 2017
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China
Summary: This standard specifies the general requirements for ground-induced vibrations arising from the operation of the orbital system and the resulting floor-induced structural noise. This standard lists the factors and parameters that need to be considered and gives guidelines for forecasting methods applicable to different environmental conditions (for example, in addition to the assessment of the impact of indoor personnel and sensitive equipment in buildings, Risk assessment of structural damage). (Such as trains, wheels, rails, rails, rails under the support structure); - propagation path: propagation (such as earth conditions, distance); - vibration by the building: the vibration of the building: Incoming (eg foundation, architectural form). This standard covers all wheel and rail systems from light rail trains to high-speed trains and cargo trains. this

GB/T 33521.1-2017: Mechanical vibration -- Ground-borne noise and vibration arising from rail systems -- Part 1: General guidance

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Mechanical vibration - Ground-borne noise and vibration from from rail systems - Part 1. General guidance ICS 17.160 J04 National Standards of People's Republic of China Mechanical vibration of the orbital system caused by ground induction Structural noise and ground vibration Part 1. General systems-Part 1. Generalguidance (ISO 14837-1..2005, IDT) 2017-02-28 released 2017-09-01 implementation General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China China National Standardization Management Committee released

Foreword

This part is part 1 of GB/T 33521 "Ground induced structural noise and ground vibration generated by mechanical vibration track systems". This part is drafted in accordance with the rules given in GB/T 1.1-2009. This part uses the translation method equivalent to the ISO 14837-1..2005 "mechanical vibration orbital system to produce ground induced structural noise and Part 1. General Regulations "(English version). In this part of the normative reference to the international documents have a consistent correspondence between the following documents. GB/T 2298-2010 Mechanical vibration, shock and condition monitoring vocabulary (ISO 2041..2009, IDT) This part of the National Mechanical Vibration, Impact and Condition Monitoring Standardization Technical Committee (SAC/TC53) proposed and centralized. This part of the drafting unit. China Railway Research Institute of energy conservation and environmental protection labor Institute, China Railway Research Institute of standard measurement research Beijing Institute of Labor Protection Science, Southwest Jiaotong University, Tsinghua University. This part of the main drafters. Sun Chenglong, Li Yanliang, Cao Yu, Fan Ronghua, Shao Bin, Lin Jianhui, Wang Zonggang, Wu Xiangyang, Lv Dongmei, Ma Yun.

Introduction

Not all ground traffic systems can cause ground-induced vibration and/or ground-induced structural noise. The rail traffic system vibration is by It is the most common and most important vibration source in the operation of the steel wheel on the rail. All types of rail transit systems produce geostrophic and/or ground induced structural noise (especially in urban areas) The environment has a negative impact. It is therefore necessary to evaluate the geostrophic vibration and building response at different distances from the vibration source. When there is the following demand, This section can be used to guide the relevant planning. Build or rebuild the railway, build or rebuild the building; The dynamic performance of the track changes or the dynamic characteristics of the train change; Train operating conditions change (such as the total length of the train, train speed or operating mode changes); Evaluation of vibration mitigation measures. The correct prediction of ground-induced vibration and/or ground-induced structural noise is an important part of the assessment, including the identification of new or converted rail systems The impact of vibration on existing buildings, or the impact assessment of new buildings adjacent to existing rail transit systems. building The standard [and/or limit] of the ground-induced vibration and/or ground-induced structural noise is the second part of the assessment. But the standard and limit Generally by the national standards and other international standards. The prediction of ground-induced vibration and/or ground-induced structural noise caused by rail transit systems is a complex and evolving technical field. this Some of the basic ideas of the forecasting model are defined to ensure their applicability to the objectives and the consistency of their methods. The guide is used to correct and confirm the model and verify its feasibility, which is an important step in quantifying and improving the accuracy of the model. Table 1 shows the framework for each stage for the construction or reconstruction of the rail transit system, or the rail transit system along the alteration of the building. Headquarters We give general referral and guide. A more detailed section will be given in the subsequent criteria, whose title names are listed in the preface. Table 1 The framework of each stage and the corresponding standard

1 method depends on

New, renovated (refurbished) or proximity development (Part 1) Design phase (conceptual design, preliminary design, detailed design) (Part 1)

2 evaluation criteria

Using national national standards and/or part 4 Provide for the assessment of places and measures

3 affect the parameters

Identify the relevant impact parameters (checklist for Part 1) Collect parameter data

4 measurements

Use field-defined metrics to obtain site-specific information (Part 3 and Part 4) Evaluation of model parameters Create and/or confirm the forecast model Assess the effect of mitigation Table 1 (continued)

5 Forecast

Using standard-defined measures (Part 4) Appropriate models are used in the design phase (Part 1 and Part 2) To ensure effective and well-defined (Part 1)

6 assessment

The predicted value is compared with the standard value Find out more than the standard

7 mitigation measures

Confirmation of mitigation measures (sections 1, 5 and 6) Evaluate whether the selected measures are feasible Conduct cost/benefit analysis

8 solution

Detailed design development Solve the implementation Asset Management By initiating a status monitoring and maintenance program to see if the criteria are met Mechanical vibration of the orbital system caused by ground induction Structural noise and ground vibration Part 1. General

1 Scope

This part of GB/T 33521 specifies the ground vibration generated by the operation of the orbital system and the resulting ground induced structure in the building General requirements for noise. This section lists the factors and parameters that need to be considered and gives guidelines for forecasting methods applicable to different environmental conditions (eg, In addition to the assessment of the impact of indoor personnel and sensitive equipment in buildings, can also be used for risk assessment of structural damage to buildings). This section requires attention to the following. --- vibration source characteristics. launch (such as trains, wheels, rails, rails, rail support structure); - propagation path. propagation (such as earth conditions, distance); --- vibration by the building. incoming (such as basic, architectural form). This section covers all wheel and rail systems from light rail trains to high-speed trains and cargo trains. This section gives the ground lines, elevated Structures and tunnels. This part does not involve vibration caused by the construction and maintenance of the track system, does not involve air noise, nor does it involve an important impact on the environment Structural noise caused by overhead structures.

2 normative reference documents

The following documents are indispensable for the application of this document. For dated references, only the dated edition applies to this article Pieces. For undated references, the latest edition (including all modifications) applies to this document. ISO 2041 Mechanical vibration, shock and condition monitoring vocabulary (Mechanical vibration, shockandconditionmonito- ring-Vocabulary

3 terms and definitions

ISO 2041 and the following terms and definitions apply to this document. 3.1 Ground vibration ground-bornevibration The vibration generated by the vehicle running on the orbit is propagated through the earth or building structure into the vibrating building. 3.2 Ground induced structural noise ground - bornenoise The noise generated in the building caused by the vibration generated by the vehicle on the track. Note 1. Ground induced structural noise is sometimes referred to as secondary radiation noise, structural radiation noise and solid noise. Note 2. Ground induced structural noise does not include direct air noise. 3.3 Model parameter modelparameter A factor or function that describes the physical properties (properties) of a mechanical unit in a mathematical model. ......
