GB/T 3294-2018 English PDF

US$359.00 · In stock
Delivery: <= 4 days. True-PDF full-copy in English will be manually translated and delivered via email.
GB/T 3294-2018: Test method of inspection for last sizes
Status: Valid

GB/T 3294: Historical versions

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 3294-2018	359	Add to Cart	4 days	Test method of inspection for last sizes	Valid
GB/T 3294-1998	359	Add to Cart	3 days	Method of inspection for last sizes	Obsolete
GB/T 3294-1982	RFQ	ASK	3 days	Method of measuring last sizes	Obsolete

Similar standards

GB/T 3903.12   GB/T 3903.14   GB/T 3903.13   GB/T 3903.6   GB/T 3293

Basic data

Standard ID: GB/T 3294-2018 (GB/T3294-2018)
Description (Translated English): Test method of inspection for last sizes
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: Y78
Classification of International Standard: 61.060
Word Count Estimation: 18,173
Date of Issue: 2018-06-07
Date of Implementation: 2019-01-01
Issuing agency(ies): State Administration for Market Regulation, China National Standardization Administration

GB/T 3294-2018: Test method of inspection for last sizes

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Test method of inspection for last sizes ICS 61.060 Y78 National Standards of People's Republic of China Replace GB/T 3294-1998 Shoe size detection method Published on.2018-06-07 2019-01-01 implementation State market supervision and administration China National Standardization Administration issued

Foreword

This standard was drafted in accordance with the rules given in GB/T 1.1-2009. This standard replaces GB/T 3294-1998 "Shoe Size Measurement Method". The main technical changes of this standard and GB/T 3294-1998 are as follows. --- Revised scope (see Chapter 1, Chapter 1 of the.1998 edition); ---The inspection equipment has added a square (see 4.2), a rear height measuring instrument (see 4.4), a front point detector (see 4.6); Vernier calipers and wide squares (see 4.2 of.1998); --- Revised the requirements for the sample (see Chapter 5, Chapter 3 of the.1998 edition); --- Revised the method for detecting the length of the last (see 6.2, 6.12, 5.2 of the.1998 edition); --- Removed the detection method of the height of the last of the last (see 5.3 of.1998 edition); ---Modified the detection method of the tolerance of the last (see 6.3, 5.4 of.1998 edition); --- Removed the detection method of the shoe last mouth (see 5.5 of.1998 edition); --- Revised the detection method for the circumference of the shoe last (see 6.4, 6.7, 6.8, 5.6 of the.1998 edition); --- Modified the detection method of the width of the last (see 6.5, 6.6, 6.9, 5.7, 5.8 of the.1998 edition); --- Modified the detection method of shoe lastness (see 6.11, 5.9 of.1998 edition); --- Removed the detection of the bottom end of the ( (see 5.11.1 of the.1998 version); --- Removed the detection of the point after the 楦 口 口 (see 5.11.2.1 of the.1998 edition); --- Revised the detection method of the front point of the 楦 口 mouth (see 6.13, 5.11.2.2 of the.1998 version); --- Increased data processing (see Chapter 7); --- Added test report (see Chapter 8); --- Added other measurement methods (see Appendix A); --- Added additional measurement methods (see Appendix B). Please note that some of the contents of this document may involve patents. The issuing organization of this document is not responsible for identifying these patents. This standard was proposed by the China National Light Industry Council. This standard is under the jurisdiction of the National Technical Committee for the Standardization of Footwear (SAC/TC305). This standard was drafted. China Leather and Footwear Industry Research Institute, Golden Monkey Group Weihai Footwear Co., Ltd., Zhejiang Jimmy Bear Children's Products Ltd., Guangzhou Tianchuang Fashion Footwear Co., Ltd., Shandong Leather Industry Association. The main drafters of this standard. Zhang Weijuan, Gao Ming, Zhao Binfeng, Ni Mingming, Li Xuewu, Qin Xiaobo. The previous versions of the standards replaced by this standard are. ---GB 3294-1982, GB/T 3294-1998. Shoe size detection method

1 Scope

This standard specifies the manual measurement method for the basic size of the shoe last. This standard applies to all types of conventional shoe lasts. Note. The specified size of the last does not have to match the size and size of the foot.

2 Normative references

The following documents are indispensable for the application of this document. For dated references, only dated versions apply to this article. Pieces. For undated references, the latest edition (including all amendments) applies to this document. GB/T 2703-2017 footwear terminology

3 Terms and definitions

The terms and definitions defined in GB/T 2703-2017 apply to this document.

4 Instruments and equipment

4.1 The shoe has a ruler with a width of no more than 8mm, a measurable range of not less than 350mm and an accuracy of 1mm. 4.2 Right angle ruler with an accuracy of at least 1 mm, see Figure 1. The unit is mm L1 l2 l3 Figure 1 Schematic diagram of the square 4.3 Ruler with an accuracy of at least 1mm. 4.4 Rear height measuring instrument, a stepped device for supporting the heel to make the shoe last at the corresponding heel height, each step height 5mm, ......
