US$2079.00 · In stock
Delivery: <= 13 days. True-PDF full-copy in English will be manually translated and delivered via email.
GB/T 3167-2015: Metal-cutting machine tools -- Graphical symbols for operation indications
Status: Valid

GB/T 3167: Historical versions

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 3167-2015	2079	Add to Cart	13 days	Metal-cutting machine tools -- Graphical symbols for operation indications	Valid
GB/T 3167-1993	RFQ	ASK	11 days	Symbols for indications appearing on machine tools	Obsolete

Similar standards

GB/T 5900.1 GB/T 9061 GB 15760 GB/T 5900.3 GB/T 5900.2

Basic data

Standard ID: GB/T 3167-2015 (GB/T3167-2015)
Description (Translated English): Metal-cutting machine tools -- Graphical symbols for operation indications
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: J50
Classification of International Standard: 25.080.01
Word Count Estimation: 99,953
Date of Issue: 2015-05-15
Date of Implementation: 2015-09-01
Older Standard (superseded by this standard): GB/T 3167-1993
Quoted Standard: ISO 7000
Regulation (derived from): National Standard Announcement 2015 No. 15
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China
Summary: This Standard specifies the graphical symbol for metal cutting machine tools of various operating instructions. This Standard applies to metal cutting machine tools and their accessories operating panel, operating instructions signs and logos (logo), etc., can also refer to other similar mechanical use.

GB/T 3167-2015: Metal-cutting machine tools -- Graphical symbols for operation indications

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
(Metal cutting machines - Graphical symbols) ICS 25.080.01 J50 National Standards of People's Republic of China Replacing GB/T 3167-1993 Metal Cutting Machine Graphical symbols for instructions Issued on. 2015-05-15 2015-09-01 implementation Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China Standardization Administration of China released

Preface Ⅰ Introduction Ⅱ 1 Scope 1 2 Normative references 1 3 Operating instructions and other graphical symbols 1 3.1 operation, measurement, motion, motion graphics primitives symbol 1 3.2 Operation of the workpiece, the discharge of waste and graphic symbol means 24 Graphics 3.3 lubrication, hydraulic equipment and symbols 28 Graphics 3.4 workpiece and cooling apparatus 35 symbols 3.5 metal cutting tools and a common graphical symbols 37 3.6 Graphics turning lathe and symbols 42 3.7 drilling, boring, reaming and boring machine graphic symbols 47 Graphics 3.8 milling and milling symbols 48 Graphics 3.9 grinding and grinding machines, the symbol 49 Graphic 3.10 gear processing machine tools and gear symbol 53 3.11 planing, slotting and machining planer, slotting graphic symbols 55 3.12 broaching broaching processing and graphic symbols 55 3.13 sawing sawing graphics processing and symbols 56 Graphic 3.14 belt grinding, honing, grinding and machining machine symbol 57 3.15 Safety and warning graphical symbol 58 62 3.16 Other graphical symbols 4 requirements 65 Appendix A (informative) Example 66 graphical symbols used in combination Annex B (informative) This standard and GB/T 3167-1993 major changes Addendum 72 References 79 Pinyin index 80

Foreword

This standard was drafted in accordance with GB/T 1.1-2009 given rules. This standard replaces GB/T 3167-1993 "metal-cutting machine tools - Symbols." This standard compared with GB/T 3167-1993, the main technical changes are as follows. --- Standard name changed to "metal cutting machine instructions graphic symbols"; --- Added "Preface" and "Introduction"; --- "Subject matter and scope" to "program", and expanded the scope of application of the criteria (see Chapter 1, Section 1 of the 1993 edition chapter); --- "Reference standard" to "Normative references" (see Chapter 2, Section 2 of the 1993 edition); --- Press the symbol attributes were rearranged; --- An increase of some new graphical symbols (see Appendix B, Table B.1); --- Adjust some graphic symbols (see Appendix B, Table B.2); --- Cancellation of some graphic symbols (see Appendix B, Table B.3); --- Increased references; --- Increase the index. The standard proposed by China Machinery Industry Federation. The standard metal cutting machine tools by the National Standardization Technical Committee (SAC/TC22) centralized. This standard is drafted by. GSK CNC Equipment Co., Ltd., Beijing Machine Tool Research Institute. Participated in the drafting of this standard. Wuhan Heavy Duty Machine Tool Group Co., Hanchuan Machine Tool Group Co., Ltd., Beijing North has a CNC machine tools Limited liability company, Chongqing Machine Tool Group Co., Ltd., Dalian Machine Tool Group Co., Ltd., Shaanxi Qinchuan Machinery Development Company Limited Secretary of Sichuan Changzheng Machine Tool Group Co., Ltd., LK Group in Shenzhen Granville Technology Co., Ltd. The main drafters. Zhang Yujie, Lixiang Wen, Zhang Wei, Shao Guoan, Liu Hao, Wu Jing Ping, Wang Lei, Hu, Hu Ruilin, Yu Bin can, Fucheng Yun, Huwan Liang, Wang Xiaohui, Chi Heng Cai. This standard replaces the standards previously issued as follows. --- GB/T 3167-1982, GB/T 3167-1993.

Introduction

ISO 7000 "Graphical symbols for indexing and equipment list" a total of nearly 3000 graphic symbols, this reference standard ISO 7000 Select In which the metal-cutting machine tools and other instructions related to a number of graphic symbols, while retaining part of the original GB graphics/T 3167-1993 of symbol. With the development of scientific and technological progress, further to the CNC metal cutting machine tools, high-speed, high-precision, flexibility and other direction, knot CNC machine tools combined use requires, in this standard adds a number of useful graphical symbols. Metal Cutting Machine Graphical symbols for instructions

1 Scope

This standard specifies graphical symbols for a variety of metal-cutting machine operating instructions. This standard applies to metal cutting machine tools and their accessories operating panel, operating instructions signs and logos (logo), etc., but also other similar machinery Reference may be used.

2 Normative references

The following documents for the application of this document is essential. For dated references, only the dated version suitable for use herein Member. For undated references, the latest edition (including any amendments) applies to this document. ISO 7000 Graphical symbols for equipment - Index and synopsis (Graphicalsymbolsforuseonequipment-Indexand synopsis)

3 Operating instructions and other graphical symbols

3.1 operation, measurement, action, sports basic graphical symbols Operation, measurement, movements to the basic graphical symbols shown in Table 1. Table 1 operation, measurement, action, sports basic graphical symbols No Graphic Symbol Name Description 3.1.1 Start IEC 60417 5007 Preferably white (available in green) 3.1.2 Stop IEC 60417 5008 Black (or other colors, No red) 3.1.3 Jog IEC 60417 5011 Hold down the move, loosen stop ......
