GB/T 31465.4-2015 English PDFUS$399.00 · In stock
Delivery: <= 4 days. True-PDF full-copy in English will be manually translated and delivered via email. GB/T 31465.4-2015: Road vehicles -- Fuse-link -- Part 4: Fuse-links with female contacts and bolt-in contacts Status: Valid
Basic dataStandard ID: GB/T 31465.4-2015 (GB/T31465.4-2015)Description (Translated English): Road vehicles -- Fuse-link -- Part 4: Fuse-links with female contacts and bolt-in contacts Sector / Industry: National Standard (Recommended) Classification of Chinese Standard: T36 Classification of International Standard: 43.040.10 Word Count Estimation: 19,145 Date of Issue: 2015-05-15 Date of Implementation: 2015-12-01 Quoted Standard: GB/T 97.1; GB/T 1804; GB/T 5783; GB/T 6170; GB/T 25085; GB/T 31465.1-2015 Adopted Standard: ISO 8820-4-2010, MOD Regulation (derived from): National Standard Announcement 2015 No. 15 Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China Summary: This Standard specifies the road vehicles fuse socket and bolt color code, test, and other requirements and size. This section applies to a rated voltage of 32V or 58V, rated current is less than 140A, the fuse capacity 1O00A the socket (A type) and bolt (B type) fuses. GB/T 31465.4-2015: Road vehicles -- Fuse-link -- Part 4: Fuse-links with female contacts and bolt-in contacts---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order. Road vehicles Fuse-link Part 4. Fuse-links with female contacts and bolt-in contacts ICS 43.040.10 T36 National Standards of People's Republic of China Road vehicles - Fuse Part 4. fuse socket and bolt Part 4. Fuse-linkswithfemalecontactsandbolt-incontacts (ISO 8820-4.2010, Roadvehicles-Fuse-link- Part 4. Fuse-linkswithfemalecontacts (typeA) andbolt-in contacts (typeB) andtheirtestfixtures, MOD) Issued on. 2015-05-15 2015-12-01 implementation Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China Standardization Administration of China released ForewordGB/T 31465 "Road vehicles - Fuse" includes seven sections. --- Part 1. Definitions and general test requirements; --- Part 2. User's Guide; --- Part 3. blade fuse; --- Part 4. fuse socket and bolt; --- Part 5. board fuse; --- Part 6. Bolt-voltage fuse; --- Part 7. Short pin fuses. This section GB/T Part of 431,465. This section drafted in accordance with GB/T 1.1-2009 given rules. This section uses redrafted modification method using ISO 8820-4.2010 "Road vehicles - Fuse - Part 4. Box-type fuse socket Breaker (A type) and bolt fuse (B type) and the test fixture "in the development. This part of ISO 8820-4.2010 technical differences and the reasons are as follows. --- Of Chapter 2, this section has been adjusted technical differences, or both will be transformed into our standard international standards change For our standards, see Chapter 2. --- In order to facilitate the use of standards for the text refer to the GB/T 31465.1 terms of numbers are added. --- The 5.1 "test sequence shall be specified in Table 2" Move to 5.2, in line with the requirements of the standard write. --- Complement to A and B-type fuses fuses described in 5.1. --- Original temperature requirements 5.11.2 industry agreed that the limit is too wide, part of the increased "or negotiated by both parties agreed to" increase Operability standards. --- Table 3 to remove the Japanese and American specifications of wire cross-sectional area (AB), retaining only the national standard. --- Reference to Part 3, the fusing time and current gradient two requests increased "after the fuse at rated voltage by fuses The current should not exceed 0.5mA ". --- Original content and climate load 5.12 5.6 repeat, and the lack of specific requirements, belonging to the original error, delete this section 5.12, the same When the contents of the corresponding adjustment table 2, and 5.12 delete references involved in ISO 16750-4. --- Original Chapter 7 bolts, washers and nuts not given requirements, supplemented this part with reference to Section 5, to increase the standard of Operability, and a corresponding increase in the reference standard. And other standards to be consistent, while increasing operability standards, increased "The figure does not specify dimensional tolerances GB T 1804 shall comply with the provisions of the tolerance level /", Chapter 2, the corresponding increase in references standard. --- Original Type B1 and B2 type fuse terminal is not given thickness dimension in this section refer JASOD622.2011 in Figures 6, 7 And Table 10, the t size. --- Original pictures have a lot of obvious errors, some belong mislabeled, and some real car assembly not on this part have been adjusted. The lead position 4 in Fig. 8, 9 made a change, FIG. 9 dimensions 15 ± 0.1 to 15. --- 6.4 Naming example, in accordance with industry practice increases the rated voltage. Editorial changes as follows. "." --- With the decimal point as the decimal comma instead of the original ""; --- Delete foreword international standards; --- According to GB/T 1.1 seek to amend the scope of the definition or description and other text format. This part is proposed by the National Development and Reform Commission. This part of the National Automotive Standardization Technical Committee (SAC/TC114) centralized. This section drafted by. China Automotive Technology and Research Center, Anhui Jianghuai Automobile Co., Aerospace Technology Holdings shares have Ltd., Zhengzhou Yutong Bus Co., Ltd., Henan days the sea Electric Co., Ltd., Changsha Automobile Electric Institute, the Pacific Seiko, United States Special forces office in Shanghai, Zhengzhou Yue Bo Auto Electric Co., Ltd. Chongqing Lifan passenger cars, Kyrgyzstan door Fuse Manufacturing (Xiamen) Co., The company, Baoding Great Wall Automobile Auto Parts Co., Mander. Drafters of this section. Xu Xiang Xiu, Wang Yihai, Weijing Jun, Lu Changjun, Wangrong Xi, Hu Meng Jiao, pool Yongjie, quiet, Zhangyong Ying, Chen Yukang, Chen reng Thailand, Wang Guohui. Road vehicles - Fuse Part 4. fuse socket and bolt1 ScopeThis section provides road vehicles and bolt receptacle fuse color code, test, and size and other requirements. This section applies to a rated voltage of 32V or 58V, rated current is less than 140A, 1000A capacity fuse socket formula (A Type) and bolt (B type) fuses.2 Normative referencesThe following documents for the application of this document is essential. For dated references, only the dated version suitable for use herein Member. For undated references, the latest edition (including any amendments) applies to this document. GB/T 97.1 flat washer A Grade (GB/T 97.1-2002, eqv ISO 7089.2000) GB/T 1804 General tolerances for linear and angular dimensions without individual tolerance tolerance (GB/T 1804-2000, eqv ISO 2768-1. 1989) GB/T 5783 full thread hex head bolts (GB/T 5783-2000, eqv ISO 4017.1999) GB/T 61701 type hexagon nuts (GB/T 6170-2000, eqv ISO 4032.1999) GB/T 25085 Road vehicles 60V and 600V single-core wire (GB/T 25085-2010, ISO 6722.2006, IDT) GB/T 31465.1-2015 road vehicle fuses Part 1. Definitions and general test requirements (ISO 8820-1.2008, MOD)3 Terms and DefinitionsGB/T 31465.1-2015 defined terms and definitions apply to this document. 4 marks, labels and color codes Shall comply with GB/T 31465.1-2015 in Chapter 4 and in Table 1. Table 1 Fuses Color Current Rating Colour 20 light blue 25 White 30 powder 35 dark green ...... |
