GB/T 30499-2014 English PDF

US$194.00 · In stock
Delivery: <= 3 days. True-PDF full-copy in English will be manually translated and delivered via email.
GB/T 30499-2014: Inland navigation vessels -- Manually cable fightening winch -- Safety requirements and main dimensions
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 30499-2014	194	Add to Cart	3 days	Inland navigation vessels -- Manually cable fightening winch -- Safety requirements and main dimensions	Valid

Similar standards

GB/T 18572

Basic data

Standard ID: GB/T 30499-2014 (GB/T30499-2014)
Description (Translated English): Inland navigation vessels -- Manually cable fightening winch -- Safety requirements and main dimensions
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: U32
Classification of International Standard: 47.060
Word Count Estimation: 10,172
Date of Issue: 2/19/2014
Date of Implementation: 6/1/2014
Quoted Standard: EN ISO 4014; ISO 1035-3; ISO 2768-1
Adopted Standard: ISO 6218-2005, IDT
Regulation (derived from): National Standard Announcement 2014 No. 2
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China
Summary: This Standard specifies the safety requirements of the main dimensions and assembled in inland pushers or manually fixing the cable system through tight river boat winches (hereinafter referred to as the tight rope winch)'s. This Standard applies to inlan

GB/T 30499-2014: Inland navigation vessels -- Manually cable fightening winch -- Safety requirements and main dimensions

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Inland navigation vessels. Manually cable fightening winch. Safety requirements and main dimensions ICS 47.060 U32 National Standards of People's Republic of China River boat manually tight winch Safety requirements and main dimensions (ISO 6218.2005, Inlandnavigationvessels-Manualy Safetyrequirementsandmaindimensions, IDT) Issued on. 2014-02-19 2014-06-01 implementation Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China Standardization Administration of China released

Foreword

This standard was drafted in accordance with GB/T 1.1-2009 given rules. This standard uses the translation method identical with ISO 6218.2005 "river boat pushers manual connection Safety requirements and main ruler Inch "(in English). Correspondence between the consistency of the standards of international documents and normative references of the following documents. --- GB/T 702-2008 Hot-rolled steel bars - Dimensions, shape, weight and tolerances (ISO 1035-3. 1980, MOD) --- GB/T 1804-1992 General tolerances Tolerances for linear and angular dimensions without individual tolerance (eqv ISO 2768-1. 1989) --- GB/T 5782-2000 hex head bolts (eqv ISO 4014.1999) This standard makes the following editorial changes. --- Standard name changed to "riverboats hand tight winch Safety requirements and main dimensions." The standard proposed by the Ministry of Transport of the People's Republic of China. This standard by the National Standardization Technical Committee riverboats (SAC/TC130) centralized. This standard was drafted. China Shipbuilding Industry Corporation seventh THOUSAND AND FORTY Institute, Zhuhai Sunbird Yacht Manufacturing Co., Ltd. The main drafters of this standard. Chenhan Song, Zhengfang Lin, Li Yue first, Pengduan Yang, Wang Xuebin. River boat manually tight winch Safety requirements and main dimensions

1 Scope

This standard specifies the assembly in the river pushers or manually fixing the cable system riverboat by tightening winch (hereinafter referred to as tight winch) The main dimensions and safety requirements. This standard applies to inland marine hand winch tight design and testing.

2 Normative references

The following documents for the application of this document is essential. For dated references, only the dated version suitable for use herein Member. For undated references, the latest edition (including any amendments) applies to this document. ENISO 4014 Hexagon head bolts - Product grade A and B (Hexagonheadbolts-ProductgradesAand B) (ISO 4014.1999) ISO 1035-3 hot rolled steel bars - Part 3. Flat size (Hot-roledsteelbars-Part 3. Dimensionsofflat bars) ISO 2768-1 General tolerances - Part 1. No NOTE tolerances for linear and angular dimensions without individual tolerance (Generaltolerances-Part 1. Tolerancesforlinearandangulardimensionswithoutindividualtoleranceindications)

3 Terms and Definitions

The following terms and definitions apply to this document. 3.1 Manually tight winch manualycablefighteningwinch By rotating the handwheel cables connected fastening means. 3.2 Connected load couplingload Tangential load acting on the handwheel ropes withstand tensile loads.

4 Safety requirements

4.1 General Manufacture and installation of all components tight winch should be able to prevent the hull vibration, tilt, or weather causes reduction of its function. 4.2 Strength Design and fixed tight winch should ensure that all parts can withstand the minimum set out in Table 1 of the rope breaking load.

5 Types

5.1 manipulative left (L) Viewed from the cable release direction, the winch drum and the handwheel is located on the left side of the left gear-operated, shown in Figure 1. ......
