GB/T 30164-2013 English PDF

US$254.00 · In stock
Delivery: <= 3 days. True-PDF full-copy in English will be manually translated and delivered via email.
GB/T 30164-2013: Textile machinery and accessories -- Steel pins for spinning preparatory and spinning machinery
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 30164-2013	254	Add to Cart	3 days	Textile machinery and accessories -- Steel pins for spinning preparatory and spinning machinery	Valid

Similar standards

FZ/T 93048.1   FZ/T 93019   GB/T 19382.2   GB/T 19382.1

Basic data

Standard ID: GB/T 30164-2013 (GB/T30164-2013)
Description (Translated English): Textile machinery and accessories -- Steel pins for spinning preparatory and spinning machinery
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: W91
Classification of International Standard: 59.120.10
Word Count Estimation: 13,120
Adopted Standard: ISO 9904-2000, IDT
Regulation (derived from): National Standards Bulletin No. 25 of 2013
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China
Summary: This standard specifies the spinning preparation and spinning machinery needle with basic dimensions, characteristics and marking.

GB/T 30164-2013: Textile machinery and accessories -- Steel pins for spinning preparatory and spinning machinery

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Textile machinery and accessories.Steel pins for spinning preparatory and spinning machinery ICS 59.120.10 W91 National Standards of People's Republic of China Textile machinery and accessories for spinning preparation and Spinning machine with a steel needle (ISO 9904.2000, IDT) Issued on. 2013-12-17 2014-10-15 implementation Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China Standardization Administration of China released

Foreword

This standard was drafted in accordance with GB/T 1.1-2009 given rules. This standard uses the translation method identical with ISO 9904.2000 "Textile machinery and accessories - Spinning preparatory and spinning machinery needle" (English Chinese Version). For ease of use, the standard ISO 9904.2000 made the following editorial changes. a) with the "GB/T 30164" instead of "ISO 9904"; b) Delete the ISO 9904.2000 Foreword; c) In the "References" in with "GB/T 4340.1-2009, GB/T 4340.2-1999" instead of "ISO 6507-1.1997, ISO 6507-2.1997 "; "." D) use the decimal symbol instead of the symbol, ""; e) padded figures significant digits "0"; f) with "φd" instead of the FIG. 2 "d", the size of the line to extend l2 another needle contour; g) the table "×" to 3 "gray" and add "NOTE. currently being used needle marked in gray."; h) in Figure 3 to extend the size of the line l2 needle to another contour. The standard proposed by China Textile Industry Association. This standard by the national textile machinery and accessories Textile Equipment Standardization Technical Committee Technical Committee (SAC/TC215/SC2) Centralized. This standard was drafted. Shanghai Far East fillet limited liability company, Shaanxi Institute of textile equipment. The main drafters of this standard. water conservancy Hou, Zhao Yusheng, Panzeng Rong, Wu Yanping. Textile machinery and accessories for spinning preparation and Spinning machine with a steel needle

1 Scope

This standard specifies the spinning preparation and spinning machine needle with basic dimensions, features and markings.

2 basic dimensions

The basic dimensions of the needle are shown in Table 1. Table 1 Basic dimensions of the needle (see Fig. 1 to 4) Pin No. d, a, or b mm Pin No. d, a, or b mm 1 7.62 18 1.22 2 7.01 1.07 19 3 6.35 20 0.99 4 5.97 21 0.88 5 5.39 22 0.79 6 4.88 23 0.71 7 4.47 24 0.62 8 4.06 25 0.535 9 3.76 26 0.50 10 3.35 27 0.44 11 2.95 28 0.38 12 2.62 29 0.355 13 2.34 30 0.33 14 1.98 31 0.30 15 1.79 32 0.28 16 1.63 33 0.25 17 1.42

3 round pin

3.1 Dimensions Needle bar is divided into three types. A Type. spinning preparation machine needles l2 = 3l1 For 5.56mm≤l1≤17.46mm ......
