GB/T 30104.302-2021: Digital addressable lighting interface - Part 302: Particular requirements - Input devices - Absolute input devices
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 30104.302-2021	344	Add to Cart	4 days	Digital addressable lighting interface - Part 302: Particular requirements - Input devices - Absolute input devices	Valid

Similar standards

GB/T 24825 GB/T 9473 GB/T 32483.2 GB/T 30104.304 GB/T 30104.101 GB/T 30104.303

Basic data

Standard ID: GB/T 30104.302-2021 (GB/T30104.302-2021)
Description (Translated English): Digital addressable lighting interface - Part 302: Particular requirements - Input devices - Absolute input devices
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: K74
Word Count Estimation: 18,147
Issuing agency(ies): State Administration for Market Regulation, China National Standardization Administration

GB/T 30104.302-2021: Digital addressable lighting interface - Part 302: Particular requirements - Input devices - Absolute input devices

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Digital addressable lighting interface -- Part 302: Particular requirements -- Input devices -- Absolute input devices ICS 29:140:50;29:140:99 CCSK74 National Standards of People's Republic of China Digital Addressable Lighting Interface Part 302: Special requirements for input devices absolute input device (IEC 62386-302:2017, IDT) Published on 2021-12-31 2022-07-01 Implementation State Administration for Market Regulation Released by the National Standardization Administration directory Preface III Introduction IV 1 Scope 1 2 Normative references 1 3 Terms and Definitions 1 4 General Requirements 2 5 Electrical Specifications 2 6 Interface Power 3 7 Transmission protocol structure 3 8 Timing 3 9 Operation method 3 10 Variable declaration 7 11 Instruction Definition 8 Appendix A (normative) Example of connecting an external switch or slider 11 Reference 13

foreword

This document is in accordance with the provisions of GB/T 1:1-2020 "Guidelines for Standardization Work Part 1: Structure and Drafting Rules of Standardization Documents" drafted: This document is part 302 of GB/T 30104 "Digital Addressable Lighting Interface": GB/T 30104 has released the following parts: --- Part 101: General requirements for system components; --- Part 102: General requirements for control devices; --- Part 103: General requirements for control equipment; --- Part:201: Particular requirements for control gear fluorescent lamps (equipment type 0); --- Part 202: Particular requirements for control gear Self-contained emergency lighting (equipment type 1); --- Part 203: Particular requirements for control devices for discharge lamps (other than fluorescent lamps) (equipment type 2); --- Part 204: Particular requirements for control gear low-voltage tungsten halogen lamps (equipment type 3); --- Part 205: Particular requirements for control gear incandescent lamp supply voltage controllers (equipment type 4); --- Part 206: Particular requirements for control gear digital signals into DC voltage (equipment type 5); --- Part 207: Particular requirements for control gear LED modules (equipment type 6); --- Part 208: Particular requirements for control gear switch functions (equipment type 7); --- Part 209: Particular requirements for control devices Color control (equipment type 8); --- Part 301: Special requirements for input device buttons; --- Part 302: Special requirements for input devices Absolute input devices; --- Part 303: Special requirements for input device occupancy sensors; --- Part 304: Special requirements for input device light sensors: This document uses the translation method equivalent to IEC 62386-302:2017 "Digital Addressable Lighting Interface Part 302: Special Requirements Input Device Absolute Input Device": The Chinese documents that have a consistent correspondence with the international documents of normative references in this document are as follows: ---GB/T 30104:101-2021 Digital Addressable Lighting Interface Part 101: General Requirements System Components (IEC 62386- 101:2014, IDT) ---GB/T 30104:103-2017 Digital Addressable Lighting Interface Part 103: General Requirements Control Equipment (IEC 62386- 103:2014, IDT) Please note that some content of this document may be patented: The issuing agency of this document assumes no responsibility for identifying patents: This document is proposed by China National Light Industry Federation: This document is under the jurisdiction of the National Technical Committee for Standardization of Lighting Electrical Appliances (SAC/TC224): This document is drafted by: Zhejiang Boshang Optoelectronics Co:, Ltd:, State Electric Light Source Quality Supervision and Inspection Center (Beijing), Signify (China) Investment Investment Co:, Ltd:, Changzhou Tianzheng Industrial Development Co:, Ltd:, Zhejiang Jingri Technology Co:, Ltd: The main drafters of this document: Bi Weicong, Huang Feng, Zhang Chonghao, Shen Qianghua, Yang Qingfeng, Xie Runqing:

Introduction

GB/T 30104 aims to standardize the digital addressable lighting interface and is intended to consist of the following parts: Part 103 specifies the general requirements for control equipment: It is a special requirement to regulate the control device for a specific type of light source: It is a special requirement that regulates various types of input devices: GB/T 30104 is divided into several parts and published as a series of standards, and specific provisions are made for each type of equipment: The purpose is to facilitate the standardization of standards: use and maintenance: This document will be used concurrently with GB/T 30104:101 and GB/T 30104:103: The structure of the series of standards is shown in Figure 1 as follows: Figure 1 Overview of GB/T 30104 Scope of application of this clause: Other sections also include additional requirements when necessary: except: The standardization of the control interface of the control equipment is to realize the compatible coexistence and multi-master operation between the electronic control device and the lighting control equipment, This system is at a lower level than the building management system: This document describes a method of implementing a control device: Unless otherwise stated, numbers used in this document are in decimal: Hexadecimal numbers are in the format 0xVV, where VV is the number "Any value": Use the following typographical expressions: Variable: "variable name" or "variable name[3:0]", only the 3rd to 0th bits of "variable name" are given: Range of values: [min,max]: Directive: "directive-name": Digital Addressable Lighting Interface Part 302: Special requirements for input devices absolute input device

1 Scope

This document specifies a bus system controlled by binary signals for electronic lighting equipment that complies with IEC 61347 (all part), and has a DC power supply: This document only applies to lighting control systems in GB/T 30104:103-2017 and IEC 62386-103:2014/Amd1:2018 Input devices that are sensitive to absolute input devices, such as switches or sliders: Absolute input devices always have deterministic states, such as start and end position between points: Note: Testing requirements for individual products during production are not included:

2 Normative references

The contents of the following documents constitute essential provisions of this document through normative references in the text: Among them, dated citations documents, only the version corresponding to that date applies to this document; for undated references, the latest edition (including all amendments) applies to this document: GB/T 30104:103-2017 Digital Addressable Lighting Interface Part 103: General Requirements Control Equipment (IEC 62386- 103:2014, IDT) IEC 62386-101 Interfaces for digitally addressable lighting - Part 101: General requirements for system components (Digitaladdressable lightinginterface-Part 101:Generalrequirements-Systemcomponents) IEC 62386-103 Interfaces for digitally addressable lighting - Part 103: General requirements for control equipment (Digitaladdressable lightinginterface-Part 103:Generalrequirements-Controldevices) IEC 62386-103:2014/Amd1:2018 Digital addressable lighting interfaces Part 103: General requirements for control equipment (Digitaladdressablelightinginterface-Part 103:Generalrequirements-Controldevices) IEC 62386-333 Digitally addressable lighting interfaces Part 333: Particular requirements for control equipment Manual configuration [Digitalad- dressablelightinginterface-Part 333:Particularrequirementsforcontroldevices-Manualconfigura- tion(featuretype33)]

3 Terms and Definitions

Terms and definitions defined in IEC 62386-101 and IEC 62386-103 and the following terms and definitions apply to this document: 3:1 instance instance Analog or binary signal processing modules for input devices: [Source: GB/T 30104:101-2021, 3:29, with modifications] 3:2 Analog signal input analogueinput A means for the environment to interact with a lighting control system, expressed in terms of specific values relative to known upper and lower bounds: ......
