GB/T 29716.2-2018: Mechanical vibration and shock -- Signal processing -- Part 2: Time domain windows for Fourier Transform analysis

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Mechanical vibration and shock--Signal processing--Part 2. Time domain windows for Fourier Transform analysis ICS 17.160 J04 National Standards of People's Republic of China Mechanical vibration and shock signal processing Part 2. Time domain window of Fourier transform analysis Part 2. TimedomainwindowsforFourierTransformanalysis (ISO 18431-2.2004, IDT) Published on.2018-03-15 2018-10-01 implementation General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China China National Standardization Administration issued

Content

Foreword III Introduction IV 1 Scope 1 2 Normative references 1 3 Terms and Definitions 1 4 symbol 1 5 common time domain window 2 5.1 Overview 2 5.2 Hanning Window 2 5.3 Flat roof window 3 5.4 Rectangular window 4 6 Example 5 6.1 Normal window for truncating sinusoidal signals 5 6.2 Normal window for non-truncated sinusoidal signals 7 Reference 9

Foreword

GB/T 29716 "Mechanical Vibration and Shock Signal Processing" consists of the following parts. --- Part 1. Introduction; --- Part 2. Time domain window of Fourier transform analysis; --- Part 3. Time-frequency analysis method; --- Part 4. Impact response spectrum analysis; --- Part 5. Time scale analysis method. This part is the second part of GB/T 29716. This part is drafted in accordance with the rules given in GB/T 1.1-2009. This section uses the translation method equivalent to ISO 18431-2.2004 "Mechanical Vibration and Shock Signal Analysis Part 2. Fourier Transform Change the time domain window of the analysis (English version) and incorporate the contents of its amendment ISO 18431-2.2004/Cor.1.2008. The documents of our country that have a consistent correspondence with the international documents cited in this part of the norm are as follows. ---GB/T 2298-2010 Mechanical vibration, shock and condition monitoring vocabulary (ISO 2041.2009, IDT) This part is proposed and managed by the National Technical Committee for Standardization of Mechanical Vibration, Shock and Condition Monitoring (SAC/TC53). This section drafted by. Zhengzhou University, Zhengzhou Machinery Research Institute, Guangdong Electric Power Grid Co., Ltd. Electric Power Research Institute, State Grid Henan Electric Power Company Electric Power Research Institute. The main drafters of this section. Miao Tongchen, South Korea Ming, Xu Wentao, Wang Yicui, Liu Shi, Luo Jianbin.

Introduction

Measurement data for vibration and shock can include displacement, velocity, and acceleration, which can be characterized as smooth or non-stationary in time history. base The spectral analysis method of the Fourier transform is one of the tools for analyzing these two types of signals. In the process of digital signal processing, the observed signal is There are N samples with uniform time intervals in the time domain. Using a discrete Fourier transform on these N samples can obtain a series of simple cycles The sine and cosine functions whose amplitude and harmonic balance are determined by the time domain window for these N samples. This section of GB/T 29716 specifies the three most common use of windows. Mechanical vibration and shock signal processing Part 2. Time domain window of Fourier transform analysis

1 Scope

This part of GB/T 29716 specifies a set of algebraic functions that are used to describe the pre-processing of vibration and shock digital sample data. A set of time domain windows is chosen as a precursor to the spectral analysis of discrete Fourier transforms. Selected windows include Hanning windows, flat roof windows and moments Shaped window. This section is one of a series of documents detailing the signal processing tools available for the time domain, frequency domain, and time-frequency combination domain.

2 Normative references

The following documents are indispensable for the application of this document. For dated references, only dated versions apply to this article. Pieces. For undated references, the latest edition (including all amendments) applies to this document. ISO 2041.1990 Vibration and Shock Vocabulary (Vibrationandshock-Vocabulary)

3 Terms and definitions

The following terms and definitions as defined by ISO 2041 apply to this document. 3.1 Discrete Fourier Transform DiscreteFourierTransform DFT Based on the Fourier integral transform, N uniforms observed over a finite continuous time can be obtained by discrete transformations in the time domain and the frequency domain. Sample spectrum estimates for uniform time difference. X(m)= fS∑ N-1 n=0 x(n)e-i2πnm/N The definition of the symbol in the formula is given in Chapter 4. 3.2 Fast Fourier Transform FastFourierTransform FFT A discrete Fourier transform calculation algorithm that optimizes computational efficiency. Note. This algorithm is the classic Cooley-Tukey algorithm (see [1]) or the Sande-Tukey algorithm. 3.3 Time window timewindows In a limited time observation record, the aperiodicity of the acquired signal causes energy to flow into the adjacent frequency domain (spectral leakage), and the time window is A weighting function is used throughout the collected data system to reduce the amount of energy loss, ie, has been truncated to a sinusoidal component.

4 symbol

a(i) flat top window constant Be equivalent noise bandwidth fS sampling frequency i flat top window constant index m frequency sample n time sample N sample data block size; number of transformed sample points w(n) window function in time domain W(m) window function in the frequency domain x(n) sample physical quantity in the time domain Digital Fourier Transform of X(n) x(n, Δt)

5 common time domain windows

5.1 Overview There are three commonly used time domain windows in Fourier analysis. Hanning windows, flat top windows, and rectangular windows. Note. Rectangular windows are not really used for algebraic operations of windows, but are included in this section for completeness. Table 1 window characteristics Window type Highest side lobes dB Sidelobe attenuation dB/10oct Noise bandwidth Number of lines* Maximum error dB Hanning window -31.5 -60 1.50 1.4 Flat top window-93.0 ~0 3.77 < 0.01 Rectangular window -13.3 -20 1.00 3.9 * related to the spacing of the lines The noise bandwidth and maximum amplitude error indicate that when the amplitude is the main factor (for example, during the calibration process), whether it is a flat roof or a Han Ning windows are applicable, and when frequency resolution is the main factor (for example, to determine the boundary bandwidth), rectangular windows and Hanning windows are applicable. The equivalent noise bandwidth is Be= N∑ N-1 n=0 W2(n) N∑ N-1 n=0 w(n)æ ·fS (1) Note. More information on the use of time domain windows can be found in references [2], [3] and [4]. 5.2 Hanning window In this section, the Hanning window is defined as w(n)=1-cos 2πn ÷ (2) In the formula. n=0,1,,N-1. N is the number of samples recorded in time. Figure 1 shows an example of a 1024-point Hanning window obtained with a sampling frequency of 1024 sample points per second (fS). a) Description. X --- sample; Y --- amplitude, w (n). b) Description. X---frequency in Hertz (Hz); Y---amplitude, W(m). Figure 1 1024 sample points Hanning window 5.3 flat roof window In this section, the flat top window is defined as. w(n)=1 a1cos 2πn ÷ a2cos 4πn ÷ a3cos 6πn ÷ a4cos 8πn ÷ (3) In the formula. n=0,1,,N-1; A1=-1.93261719; A2= 1.28613281; A3=-0.38769531; A4= 0.03222656. N is the number of samples recorded in time. Figure 2 shows an example of a 1024-point flat-top window obtained with a sampling frequency of 1024 sample points per second (fS). a) Description. X --- sample; Y --- amplitude, w (n). b) Description. X --- frequency in Hertz (Hz); Y --- amplitude, W (m). Figure 2 1024 sample point flat top window 5.4 Rectangular window In this section, the rectangular window is defined as w(n)=1 (4) In the formula. n=0,1,,N-1. N is the number of samples recorded in time. Figure 3 shows an example of a 1024-point rectangular window obtained with a sampling frequency of 1024 sample points per second (fS). a) Description. X --- sample; Y --- amplitude, w (n). b) Description. X --- frequency in Hertz (Hz); Y --- amplitude, W (m). Figure 3 1024 sample point rectangular window

6 examples

6.1 Normal window for truncating sinusoidal signals Figure 4 and Table 2 show one at 1024 sample points per second (fS) at 4 Example of periodic sine wave sampling, phase shift is not the result influential. It shows the range of noise bandwidth and amplitude error. a) sine wave Description. X---sample; Y---signal, x(n). b) Hanning window c) Flat roof window d) rectangular window Description. X---frequency in Hertz (Hz); Y---X(m). Figure 4 for truncating 4 Example of a normal window with a periodic sine wave Table 2 Normal window for truncating sinusoidal signals Frequency Hanning window flat roof window rectangular window 0 0.0073 0.0033 0.1415 1 0.0101 0.0694 0.1488 2 0.0254 0.3988 0.1763 3 0.1705 0.8507 0.2546 4 0.8483 0.9989 0.6741 5 0.8492 0.9990 0.6031 6 0.1695 0.8506 0.1819 7 0.0240 0.3989 0.0997 8 0.0079 0.0693 0.0655 9 0.0035 0.0017 0.0472 10 0.0019 0.0000 0.0359 6.2 Normal window for non-truncated sinusoidal signals Figure 5 and Table 3 show an example of sampling in a 4-cycle sine wave at 1024 sample points per second (fS). The result is no phase shift. Off. It shows a noise bandwidth range with zero amplitude error. a) sine wave Description. X---sample; Y---signal, x(n). b) Hanning window Figure 5 Example of a normal window for a non-truncated 4-cycle sine wave c) Flat roof window d) rectangular window Description. X --- frequency in Hertz (Hz); Y ---X(m). Figure 5 (continued) Table 3 Normal window for non-truncated sinusoidal signals Frequency Hanning window flat roof window rectangular window 0 0.0000 0.0000 0.0000 1 0.0000 0.1940 0.0000 2 0.0000 0.6430 0.0000 3 0.5000 0.9665 0.0000 4 1.0000 1.0000 1.0000 5 0.5000 0.9665 0.0000 6 0.0000 0.6430 0.0000 7 0.0000 0.1940 0.0000 8 0.0000 0.0160 0.0000 9 0.0000 0.0000 0.0000 10 0.0000 0.0000 0.0000 references [1] COOLEY, JWandTUKEY, JWAnAlgorithmfortheMachineComputationoftheCom- plexFourierSeries.MathematicsofComputation,19,April1965,pp.297-301 [2] HARRIS, FJOntheUseofWindowsforHarmonicAnalysiswiththeDiscreteFourier Transform.ProceedingoftheIEEE,66,January1978,pp.51-83 [3] RANDALL, RBFrequencyAnalysis.3rdED., Bruel BN8787355078) [4] GADE, S. and HERLUFSEN, H. UseofWeightingFunctionsinDFT/FFTAnalysis. PartI. Brueland Kjaer. Technical Review, No. 3, 1987 (ISSN007-2621) [5] GADE, S. and HERLUFSEN, H. UseofWeightingFunctionsinDFT/FFTAnalysis.Part II. Brueland Kjaer. Technical Review, No. 4, 1987 (ISSN 007-2621) ......
