GB/T 29618.301-2015: Field device tool (FDT) interface specification -- Part 301: Communication profile integration -- FF fieldbus specification
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 29618.301-2015	2614	Add to Cart	10 days	Field device tool (FDT) interface specification -- Part 301: Communication profile integration -- FF fieldbus specification	Valid

Similar standards

GB/T 33008.1 GB/T 33009.1 GB/T 33009.2 GB/T 29618.306 GB/T 29618.309 GB/T 29618.315

Basic data

Standard ID: GB/T 29618.301-2015 (GB/T29618.301-2015)
Description (Translated English): Field device tool (FDT) interface specification -- Part 301: Communication profile integration -- FF fieldbus specification
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: N10
Classification of International Standard: 25.040
Word Count Estimation: 131,135
Date of Issue: 2015-12-10
Date of Implementation: 2016-07-01
Quoted Standard: GB/T 29618.1-2013; GB/T 29618.2-2013; ISO 646; IEC 61158-2; IEC 61158-3-1; IEC 61158-4-1-2007; IEC 61158-5-5; IEC 61158-5- 9; IEC 61158-6-5; IEC 61158-6-9; IEC 61784-1
Adopted Standard: IEC 62453-301-2009, IDT
Regulation (derived from): National Standard Announcement 2015 No.38
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China
Summary: This standard specifies the definition of the communication protocol-specific extensions, and a block (eg, transmission block, resource block or function block) representation. The new protocol-specific definition is based on FF H1 and HSE protocol specification above. In addition, the definition includes information systems FF device configuration required. This standard applies to a specific definition of FF devices and systems.

GB/T 29618.301-2015: Field device tool (FDT) interface specification -- Part 301: Communication profile integration -- FF fieldbus specification

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Field device tool (FDT) interface specification - Part 301. Communication profile integration - FF fieldbus specification ICS 25.040 N10 National Standards of People's Republic of China Field device tool (FDT) interface specification Part 301. Integrated communication profile Fieldbus Specification FF Fielddevicetool (FDT) interfacespecification-Part 301. (IEC 62453-301.2009, Fielddevicetool (FDT) interfacespecification- Part 301. Communicationprofileintegration-IEC 61784CPF1, IDT) Issued on. 2015-12-10 2016-07-01 implementation Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China Standardization Administration of China released

Introduction Ⅲ Introduction Ⅳ 1 Scope 1 2 Normative references 1 3 Terms, definitions, symbols, abbreviations and conventions 2 3.1 Terms and definitions 2 3.2 Symbols and abbreviations 2 3.3 Conventions 2 The basic structure of 2 4 4.1 system topology and FDT 2 4.2 H1 FDT topology device 3 FDT topology 4.3 HSE devices 4 4.4 nested distribution 6 Bus 5 Category 6 Examples of devices and data access 6 of 7 6.1 DTM 7 6.2 BTM 7 7 7 protocol-specific behavior 7 7.1 Connection Management 7.2 Abort abort 9 Relations FMS 7.3 FMS requests and responses 9 7.4 subscribe mechanism 11 8 General protocol-specific data types use 12 12 8.1 Address 8.2 protocolID 13 8.3 applicationDomain 13 8.4 semanticId 13 9 protocol-specific data types 14 9.1 DTM 14 9.2 BTM 22 10 Network Management Data Types 38 10.1 Overview 38 10.2 H1 network management defined 38 10.3 HSE management network defined 39 11 communication data type 83 11.1 General Data Type 83 11.2 FFFMS data type 88 11.3 H1 communication data type 95 11.4 HSE communication data type 102 11.5 FDTFF standard block communication data type 110 12-Channel Data Type 112 13 device identification 114 13.1 Data type STRING protocol specific processing 114 13.2 common type of device identification data type 114 13.3 scanning identification data type 118 13.4 Equipment type identification data type -DTM provide 119 Appendix A (informative) to achieve prompt 121 A.1 About Trend subscription, the configuration of 121 A.2 on subscription parameter configuration tips 121 A.3 about the event subscription configuration tips 122 Appendix B (normative) level of support 123 B.1 Common 123 References 125

Foreword

GB/T 29618 "Field device tool (FDT) interface specification" is divided into the following sections. --- Part 1. Overview and guidance; --- Part 2. Concepts and detailed description; --- Part 301. Integrated communication profile Fieldbus Specification FF; --- Part 302. Integrated communication profile Common Industrial Protocol; Part --- Article 303-1. communication profile integrated PROFIBUS Fieldbus specifications; --- Article 303-2. Communication profiles integrated PROFINET input and output interface specification; --- Part 306. Integrated communication profile INTERBUS Fieldbus specifications; --- Part 309. Integrated communication profile Addressable Remote Transducer Highway; --- Part 315. Integrated MODBUS communication profile Fieldbus specifications; --- Part 41. Integrated generic object model profiles Object Model; --- Part 501. Communication Common Object Model for the FF Fieldbus specifications; --- Part 502. Communication implementation of Common Object Model CIP; Part --- Article 503-1. Communication Common Object Model for the PROFIBUS Fieldbus specifications; --- Article 503-2. Communication Common Object Model for the PROFINET input and output interface specification; --- Part 506. Communication Common Object Model for the INTERBUS Fieldbus specifications; --- Part 509. Communication Common Object Model for the HART Fieldbus specifications; --- Part 515. Communication Common Object Model for the MODBUS Fieldbus specifications; --- Part 61. Device Type Manager Style Guide Common Object Model. This section GB/T 29618 Part 301. This section drafted in accordance with GB/T 1.1-2009 given rules. This section uses the translation method identical with IEC 62453-301.2009 "Field device tool (FDT) interface specification - Part 301. Through Nobuyuki Compliance Integration Fieldbus Specification FF "(in English). This part of IEC 62453-301.2009 made the following editorial changes. --- Remove the IEC 62453-301.2009 Introduction, re-write the foreword to this section; --- Where "IEC 62453" where to "GB/T 29618". --- Remove the body no abbreviations FDA cited. This part is proposed by China Machinery Industry Federation. This part of the measurement and control of Standardization Technical Committee (SAC/TC124) is administered by the National industrial processes. This section is drafted. Southwest University, Shenzhen City superscript Li Technology Development Co., Xi'an University of Posts and Telecommunications, Mechanical Instrumentation Technical and Economic Research Institute, China Silian Instrument Group. The main drafters of this section. Liu Feng, YT, Liu Yuan, Ouyang Jinsong, Wang Chunxi, Liu Jin, Zhang Yu, Huang Renjie, Qi Qian.

Introduction

This section FDT (Field Device Tool) components developers interface specification, FDT components for client/server architecture Control functions and data access. This section is the result of the development of standard interfaces in the process of analysis and design. These multiple standard interfaces easy Manufacturers develop seamless server and client interoperability. Field devices integrated into the control system, you need to perform some other tasks. In addition to the specific fieldbus-specific tools and equipment Tools, the need to integrate these tools into a higher level of system-wide planning or engineering tool. In particular, for the large-scale heterogeneous Control systems (Process Industry) using well-defined and easy to use interface to the relevant project is very important. Device-specific software components created in accordance with this section called Device Type Manager (DTM). FDT it through this part of the definition of Service, all device-specific data, functions and business rules are integrated into the system. FDT/DTM scene for all types of methods Bus are open, allowing all kinds of devices into heterogeneous systems. Figure 1 shows the GB/T 29618.301 position in GB/T 29618 series of standards structure. FIG. 1 GB/T 29618 series Part 301 Field device tool (FDT) interface specification Part 301. Integrated communication profile Fieldbus Specification FF

1 Scope

Communication profiles cluster 1 (FF1) in accordance with IEC 61158-2 Type 1, IEC 61158-3-1, IEC 61158-4-1, IEC 61158-5-5, IEC 61158-5-9, IEC 61158-6-5 and IEC 61158-6-9 defines the communication profile. Defines the basic protocol IEC 61784-1 CP1/1 (FFH1) and CP1/2 (FFHSE). This section FF protocol integrated into the FDT standard (GB/T 29618.2) to provide information. These standards describe the definition of the communication protocol-specific extensions, and a block (eg, transmission block, resource block or function block) representation. The new protocol-specific definition is based on the protocol specification FFH1 and HSE. In addition, the definition includes system FF device configuration The required information. This section applies to a specific definition of FF devices and systems.
