GB/T 28782.1-2023 English PDF

Q: How long will the true-PDF of English version of GB/T 28782.1-2023 be delivered?

Upon your order, we will start to translate GB/T 28782.1-2023_English as soon as possible, and keep you informed of the progress. The lead time is typically 2 ~ 4 working days. The lengthier the document the longer the lead time.

Q: Can I share the purchased PDF of GB/T 28782.1-2023_English with my colleagues?

Yes. The purchased PDF of GB/T 28782.1-2023_English will be deemed to be sold to your employer/organization who actually pays for it, including your colleagues and your employer's intranet.

Q: Does the price include tax/VAT?

Yes. Our tax invoice, downloaded/delivered in 9 seconds, includes all tax/VAT and complies with 100+ countries' tax regulations (tax exempted in 100+ countries). Avoidance of Double Taxation Agreements (DTAs) between Singapore and 100+ Countries: https://www.iras.gov.sg/taxes/international-tax

Q: Do you accept my currency other than USD?

Yes. If you need your currency to be printed on the invoice, please write an email to Sales@ChineseStandard.net. In 2 working-hours, we will create a special link for you to pay in any currencies. Otherwise, follow the normal steps: Add to Cart -- Checkout -- Select your currency to pay.

US$419.00 · In stock
Delivery: <= 4 days. True-PDF full-copy in English will be manually translated and delivered via email.
GB/T 28782.1-2023: Hydraulic fluid power - Measurement techniques - Part 1: General principles
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 28782.1-2023	419	Add to Cart	4 days	Hydraulic fluid power - Measurement techniques - Part 1: General principles	Valid

Similar standards

GB/T 20080 GB/T 25133 GB/T 20079 GB/T 28782.2 GB/T 28783 GB/T 28781

Basic data

Standard ID: GB/T 28782.1-2023 (GB/T28782.1-2023)
Description (Translated English): Hydraulic fluid power - Measurement techniques - Part 1: General principles
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: J20
Classification of International Standard: 23.100.01
Word Count Estimation: 22,223
Date of Issue: 2023-08-06
Date of Implementation: 2023-08-06
Issuing agency(ies): State Administration for Market Regulation, China National Standardization Administration

GB/T 28782.1-2023: Hydraulic fluid power - Measurement techniques - Part 1: General principles

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
ICS 23.100.01 CCSJ20 National Standards of People's Republic of China Hydraulic transmission measurement technology Part 1.General principles Part 1.Generalprinciples Published on 2023-08-06 2023-08-06 Implementation State Administration for Market Regulation Released by the National Standardization Administration Committee

Preface III Introduction IV 1 Scope 1 2 Normative reference documents 1 3 Terms and Definitions 1 4 Target uncertainty2 5 Measurement requirements 2 6 Calibration Procedure 4 7 Instrument calibration uncertainty model 5 8 Evaluation of uncertainty introduced by reading capability7 9 Safeguards 8 10 Combined standard measurement uncertainty 9 Appendix A (Informative) Guidelines for Best Measurement Capabilities10 Appendix B (Informative) Uncertainty Propagation Law 13 Appendix C (informative) Measurement system acceptance information table 14 Reference 15

Foreword

This document complies with the provisions of GB/T 1.1-2020 "Standardization Work Guidelines Part 1.Structure and Drafting Rules of Standardization Documents" Drafting. This document is Part 1 of GB/T 28782 "Hydraulic Transmission Measurement Technology". GB/T 28782 has released the following parts. ---Part 1.General principles; ---Part 2.Measurement of average steady-state pressure in closed circuits. This document is modified to adopt ISO 9110-1.2020 "Hydraulic Transmission Measurement Technology Part 1.General Measurement Criteria". Compared with ISO 9110-1.2020, this document has made the following structural adjustments. ---5.2~5.8 corresponds to 5.1.1~5.1.7 in ISO 9110-1.2020; ---7.7.1 and 7.7.2 correspond to the suspended section and 7.7.1 of 7.7 in ISO 9110-1.2020; ---8.2.2~8.2.4, 8.2.5, and 8.3 correspond to 8.2.1.1~8.2.1.3, 8.2.2, and 8.3.1 in ISO 9110-1.2020; ---10.2 and 10.3 correspond to 10.1.1 and 10.1.2 in ISO 9110-1.2020; ---Appendix A corresponds to Appendix C in ISO 9110-1.2020, among which A.2.1~A.2.14 corresponds to ISO 9110-1.2020 C.2.1~C.2.14; Appendix C corresponds to Appendix A in ISO 9110-1.2020. The technical differences between this document and ISO 9110-1.2020 and their reasons are as follows. ---Replaced ISO 5598 (see Chapter 3) with normatively cited GB/T 17446 to adapt to my country's technical conditions and improve reliability operability; ---Replaced ISO 7870-1 (see Chapter 9) with normatively quoted GB/T 17989.1 to adapt to my country's technical conditions and improve High operability; ---Replaced ISO 7870-2 (see Chapter 9) with normatively quoted GB/T 17989.2 to adapt to my country's technical conditions and improve High operability; ---Replaced ISO /IEC Guide98-3 (see 10.1, Appendix B) with normatively quoted GB/T 27418 to adapt to my country's technical conditions to improve operability. The following editorial changes have been made to this document. ---Deleted the terminology database address maintained by ISO and IEC for standardization; ---Change formula (2a) to formula (2), formula (2b) to formula (3), and the subsequent formula numbers will be postponed. Please note that some content in this document may be subject to patents. The publisher of this document assumes no responsibility for identifying patents. This document is proposed by China Machinery Industry Federation. This document is under the jurisdiction of the National Hydraulic and Pneumatic Standardization Technical Committee (SAC/TC3). This document was drafted by. Guangdong Shaoguan City Quality Measurement Supervision and Inspection Institute, Anhui Jiale Mining Equipment Co., Ltd., Zhejiang University, Youwei Li Hydraulic Technology Co., Ltd., Xiamen Qinghua Intelligent Transmission Co., Ltd., Zhejiang Haihong Hydraulic Technology Co., Ltd., Ningbo City Products Food Quality Inspection Institute (Ningbo Fiber Inspection Institute), Xiamen University, Qingdao Liwo Hydraulic Machinery Co., Ltd., Yiwu Yuantai Intelligent Technology Co., Ltd., Xi'an Libeian Intelligent Technology Co., Ltd., Henan Aerospace Hydraulic and Pneumatic Technology Co., Ltd., Ningbo Hengtong Nuoda Hydraulic Co., Ltd. Co., Ltd., Guangdong Hengxinya Technology Co., Ltd., and Beijing Machinery Industry Automation Research Institute Co., Ltd. The main drafters of this document. Zhao Shangyu, Xu Bing, Sun Shengxi, Lin Guang, He Xianjian, Zheng Zhijian, Qian Zhan, Ye Shaoqian, Xiang Daxin, Wang Huawei, Deng Weihong, Liu Songlin, Liu Baolin, Wang Dongsheng, Huang Qiongfang, Cao Qiaohui.

Introduction

As a key technology in the development and production of hydraulic components and hydraulic systems, hydraulic transmission measurement technology is an important tool for verifying product performance indicators and reliability. important means of sex, lifespan, etc. Only through quantification can the performance characteristics of hydraulic components and systems provide a basis for action or decision-making. GB/T 28782 "Hydraulic Transmission Measurement Technology" aims to unify the measurement technology in hydraulic transmission and consists of two parts. constitute. ---Part 1.General principles. The purpose is to identify general guidelines for measuring hydraulic component performance parameters under static or steady-state operating conditions. ---Part 2.Measurement of average steady-state pressure in closed circuits. The purpose is to determine the average steady-state pressure in the hydraulic transmission circuit program of. Hydraulic transmission measurement technology Part 1.General principles

1 Scope

This document specifies general guidelines for measuring performance parameters of hydraulic components under static or steady-state operating conditions. This document gives the sources and principles for the assessment of uncertainties in the calibration and measurement of systems containing hydraulic components. This document is suitable for assessing actual requirements and uncertainties of measurement system capabilities, or for establishing a system that meets target uncertainties.

2 Normative reference documents

The contents of the following documents constitute essential provisions of this document through normative references in the text. Among them, the dated quotations For undated referenced documents, only the version corresponding to that date applies to this document; for undated referenced documents, the latest version (including all amendments) applies to this document. GB/T 17446 Fluid transmission system and component vocabulary (GB/T 17446-2012, ISO 5598.2008, IDT) GB/T 17989.1 Control Charts Part 1.General Guidelines (GB/T 17989.1-2020, ISO 7870-1.2014, MOD) GB/T 17989.2 Control Charts Part 2.General Control Charts (GB/T 17989.2-2020, ISO 7870-2.2013, MOD) GB/T 27418 Evaluation and expression of measurement uncertainty (GB/T 27418-2017, ISO /IEC Guide98-3.2008, MOD)

3 Terms and definitions

The terms and definitions defined in GB/T 17446 and the following apply to this document. 3.1 datareductionerrors Errors arising from the processing of test data to final results (such as computer resolution, numerical rounding, and model curve fitting and interpolation) value uncertainty). 3.2 indicatedvalue indicatedvalue A quantity value given by a measuring instrument or measuring system. 3.3 parallaxparalax When the tip of the pointer is not on the same plane as the meter scale, the observer's line of sight is not perpendicular to the meter surface and not directly aligned with the pointer. resulting in reading errors. 3.4 reading abilityreadability The ability of an observer to identify the value displayed by an instrument. 3.5 uncertainty model uncertaintymodel A chart, graph or equation showing the relationship between an indication value (3.2) and the measured value of a measured parameter. ......
