GB/T 28776-2012: Steel gate, globe and check valve for the petroleum and natural gas industries (for sizes DN100 and smaller)
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 28776-2012	579	Add to Cart	5 days	Steel gate, globe and check valve for the petroleum and natural gas industries (for sizes DN100 and smaller)	Valid

Similar standards

GB/T 28778 GB/T 30832 GB/T 29026 GB/T 44519 GB/T 28777

Basic data

Standard ID: GB/T 28776-2012 (GB/T28776-2012)
Description (Translated English): Steel gate, globe and check valve for the petroleum and natural gas industries (for sizes DN100 and smaller)
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: J16
Classification of International Standard: 23.060.99
Word Count Estimation: 25,287
Quoted Standard: GB 150; GB/T 196; GB/T 197; GB/T 228.1; GB/T 898; GB/T 1220; GB/T 1221; GB/T 3077; GB/T 5796.1; GB/T 5796.2; GB/T 5796.3; GB/T 5796.4; GB/T 7306.2; GB/T 9113; GB/T 12220; GB/T 12221; GB/T 12224; GB/T 12228; GB/T 12229; GB/T 12230; GB/T 12716; GB/T 26480;
Adopted Standard: ISO 15761-2002, MOD
Regulation (derived from): National Standards Bulletin 2012 No. 28
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China
Summary: This standard specifies the oil and gas industry with a nominal size not larger than DN100 steel gate valve, globe valve (including throttle) and check valve structure, technical requirements, materials, test methods and inspection rules, marking, packagi

GB/T 28776-2012: Steel gate, globe and check valve for the petroleum and natural gas industries (for sizes DN100 and smaller)

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Steel gate, globe and check valve for the petroleum and natural gas industries (for sizes DN100 and smaller) ICS 23.060.99 J16 National Standards of People's Republic of China Oil and gas industry with a steel gate, globe and Check valve (≤DN100) Steelgate, globeandcheckvalveforthepetroleumandnaturalgasindustries (ISO 15761.2002, Steelgate, globeandcheckvalveforsizesDN100and smalerforthepetroleumandnaturalgasindustries, MOD) Issued on. 2012-11-05 2013-03-01 implementation Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China Standardization Administration of China released

Introduction Ⅲ 1 Scope 1 2 Normative references 1 3 structure 2 4 5 Technical Requirements 4.1 Pressure - Temperature Ratings 5 4.2 Operating temperature limits 5 4.3 Structure of the valve 5 4.4 valve of the flow channel 5 The wall thickness of the valve housing 6 4.5 4.6 Valve connecting terminal 7 4.7 length of the structure 8 4.8 Seat 9 4.9 valve body and bonnet connection 9 4.10 closing member 10 Stem 11 4.11 4.12 stem nut or stem bushing 12 4.13 packing, stuffing and packing gland 12 4.14 compression packing 12 4.15 handwheel 13 5 material 13 6 13 test methods and inspection rules 6.1 Test Method 13 6.2 Inspection Rules 14 7 logo 15 Packaging and storage 8 16 Pressure Appendix A (normative) nominal pressure PN250 valves - temperature rating 17 Appendix B (normative) bellows valve stem seal of claim 18 Annex C (informative) butt welding end dimensions 21

Foreword

This standard was drafted in accordance with GB/T 1.1-2009 given rules. This revised standard adopts ISO 15761.2002 "oil and gas industry with a nominal size of less than or equal to DN100 steel gate, Globe and check valves. " This standard is based on ISO 15761.2002 redrafted. This standard and ISO 15761.2002 as compared to the main changes are as follows. --- With our standards instead of international standards of normative documents referenced; --- Remove the ISO 15761.2002 on the term, because the term has been defined in our standards and have the same meaning; --- The ISO 15761.2002 in the pound to PN level, the unit can also be modified accordingly; --- Not using ISO 15761.2002 5.4.4.3Class1500 valve structure length, according to China's valve provisions of the standard; --- Not using ISO 15761.2002 in 5.4.5, according to China's valve standards, thick-walled tube butt weld end requirements set out in the Appendix; --- Not using ISO 15761.2002, Chapter 8, according to China's existing, applicable to the petroleum and petrochemical valve inspection and test standards; --- Increased static life test frequency bellows valve stem seal requirements; --- Product testing according to the requirements of our country, increase the inspection rules; --- Added Appendix A; --- The ISO 15761.2002 Annex A, Annex D into the body, Appendix B and Appendix C after the merger as Appendix B of this standard; --- The ISO 15761.2002 welding end dimensions in Appendix C of this standard; --- Deleted Appendix E availability information. The standard proposed by China Machinery Industry Federation. The standard valve by the National Standardization Technical Committee (SAC/TCS188) centralized. This standard was drafted. Hefei General Machinery Research Institute, Anhui Tunxi High Pressure Valve Co., Ltd., Henan mountains Valve Co., Ltd., China East Valve Co., Bethel Valve Group Co., Ltd Baoyi group. The main drafters of this standard. Wang Xiaojun, Cao Yaohua, Yangquan Qing, gold AD, metal, rain, Zhang Xiaozhong, Zhang Jiwei. Oil and gas industry with a steel gate, globe and Check valve (≤DN100)

1 Scope

This standard specifies the oil and gas industry with a nominal size no greater than DN100 steel gate, globe (including the throttle) and non-return Form valve structure (hereinafter referred to as "valve"), the technical requirements, materials, test methods and inspection rules, marking, packaging, storage and transportation requirements. This standard applies to nominal pressure PN20, PN50, PN100, PN250, nominal size DN8 ~ DN100 valve flange end of. This standard applies to nominal pressure PN140, PN250, nominal size socket weld or threaded ends DN8 ~ DN65 of valves. This standard applies to nominal pressure PN20 ~ PN250, nominal size butt welding ends DN8 ~ DN100 valve. This standard applies to gate and globe valve bellows stem seal structure. Note. Nominal pressure PN20 equivalent Class150, nominal pressure PN50 equivalent Class300, nominal pressure PN100 equivalent Class600, nominal pressure PN140 equivalent Class800, nominal pressure PN250 equivalent Class1500.
