GB/T 28697-2012 English PDF

US$254.00 · In stock
Delivery: <= 3 days. True-PDF full-copy in English will be manually translated and delivered via email.
GB/T 28697-2012: Rolling bearings -- Aligning thrust ball bearings and aligning seat washers -- Boundary dimensions
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 28697-2012	254	Add to Cart	3 days	Rolling bearings -- Aligning thrust ball bearings and aligning seat washers -- Boundary dimensions	Valid

Similar standards

GB/T 25764   GB/T 25763   GB/T 25770   GB/T 28698

Basic data

Standard ID: GB/T 28697-2012 (GB/T28697-2012)
Description (Translated English): Rolling bearings -- Aligning thrust ball bearings and aligning seat washers -- Boundary dimensions
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: J11
Classification of International Standard: 21.100.20
Word Count Estimation: 13,120
Older Standard (superseded by this standard): GB/T 301-1995
Quoted Standard: ISO 582; ISO 5593; ISO 15241
Adopted Standard: ISO 20516-2007, IDT
Regulation (derived from): National Standards Bulletin No. 24 of 2012
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China
Summary: This standard specifies the with and without aligning seat washers unidirectional and bidirectional self-aligning thrust ball bearing dimensions.

GB/T 28697-2012: Rolling bearings -- Aligning thrust ball bearings and aligning seat washers -- Boundary dimensions

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
ICS21.100.20 J11 National Standards of People's Republic of China GB/T 28697-2012/ISO 20516.2007 Partial replacement of GB/T 301-1995 Rolling Aligning thrust ball bearings and aligning seat washers Dimensions Rolingbearings- (ISO 20516.2007, IDT) Issued on. 2013-03-01 2012-09-03 implementation Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China Standardization Administration of China released

Foreword

This standard rule according to GB/T 1.1-2009 given draft. This standard replaces GB/T 301-1995 "Rolling Thrust ball bearings Dimensions" in the unidirectional and bidirectional external heart Thrust Ball Bearing portion. This standard uses the translation method identical with ISO 20516.2007 "Rolling aligning thrust ball bearings and aligning seat washer shape size". Correspondence between the consistency of the standards of international documents and normative references of the following documents. --- GB/T 274-2000 Rolling chamfer dimensions Max (ISO 582.1995, IDT) --- GB/T 6930-2002 Rolling vocabulary (ISO 5593.1997, IDT) --- GB/T 7811-2007 Rolling Parameter Symbol (ISO 15241.2001, IDT) This standard also made the following editorial changes. --- With a decimal symbol instead of ",". ","; --- Remove the international standards outlined in the informative elements. The standard proposed by China Machinery Industry Federation. This standard by the National Standardization Technical Committee of Rolling (SAC/TC98) centralized. This standard was drafted. Shengzhou Meiya Special Bearing Factory, Luoyang Bearing Research Institute Co., Ltd. The main drafters of this standard. Zhou Youhua, Li snow, Zhouyou Feng, Zhao Wenxiang. GB/T 28697-2012/ISO 20516.2007 Rolling Aligning thrust ball bearings and aligning seat washers Dimensions

1 Scope

This standard specifies with and without aligning seat washers unidirectional and bidirectional thrust-aligning ball bearing dimensions.

2 Normative references

The following documents for the application of this document is essential. For dated references, only the dated edition applies to this article Member. For undated references, the latest edition (including any amendments) applies to this document. ISO 582 Rolling maximum chamfer dimensions (Rolingbearings-Chamferdimensions-Maximum values) ISO 5593 Rolling vocabulary (Rolingbearings-Vocabulary) ISO 15241 Rolling Parameter Symbol (Rolingbearings-Symbolsforquantities)

3 Terms and Definitions

ISO 5593 define the following terms and definitions apply to this document. 3.1 Aligning thrust ball bearings < one-way bearing> aligningthrustbalbearing Through a self-aligning bearing seat can accommodate between axis and bearing axis of the amount of skew angle thrust ball bearings. NOTE. The spherical aligning the back seat with a self-aligning bearing seat gasket or corresponding concave spherical match. 3.2 Aligning thrust ball bearings < way bearing> aligningthrustbalbearing By aligning seat ring and the bearing can be adapted to a certain amount of angle between the axis of the bearing axis oblique thrust ball bearings. NOTE. spherical and the back aligning seat washer or bearing race aligning corresponding concave spherical match. 3.3 Unidirectional aligning thrust ball bearings single-directionaligningthrustbalbearing Only to withstand a direction of axial load spherical thrust ball bearings. 3.4 Aligning two-way thrust ball bearings double-directionaligningthrustbalbearing To withstand axial load in both directions of aligning thrust ball bearings. 3.5 Axis circle centralshaftwasher Mounted on the shaft of the circle.

4 Symbol

ISO 15241 is given and the following symbols are applicable to this document. GB/T 28697-2012/ISO 20516.2007 ......
