US$259.00 · In stock
Delivery: <= 3 days. True-PDF full-copy in English will be manually translated and delivered via email.
GB/T 28424-2012: Graphical symbols and cutline for use in equipment of TV monitoring system for traffic
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 28424-2012	259	Add to Cart	3 days	Graphical symbols and cutline for use in equipment of TV monitoring system for traffic	Valid

Similar standards

GB/T 37471 GB/T 33577 GB/T 26773 GB/T 18277 GB/T 39900 GB/T 38779

Basic data

Standard ID: GB/T 28424-2012 (GB/T28424-2012)
Description (Translated English): Graphical symbols and cutline for use in equipment of TV monitoring system for traffic
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: R87
Classification of International Standard: 03.220.20
Word Count Estimation: 11,120
Quoted Standard: GB/T 5465.2-2008; GB/T 15565.1; GB/T 16902.1-2004; GA/T 74-2000
Regulation (derived from): National Standards Bulletin No. 13 of 2012
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China
Summary: This standard specifies the traffic monitoring system television equipment used primarily graphic symbols and legend. This standard applies to transportation television monitoring system design, construction, and other industries can also refer to the use

GB/T 28424-2012: Graphical symbols and cutline for use in equipment of TV monitoring system for traffic

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
ICS03.220.20 R87 National Standards of People's Republic of China Traffic television monitoring system equipment Graphic symbols and legend Issued on. 2012-10-01 2012-06-29 implementation Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China Standardization Administration of China released

Foreword

This standard rule according to GB/T 1.1-2009 given draft. This standard by the National Intelligent Transportation System Standardization Technical Committee (SAC/TC268) and focal points. This standard was drafted. Research Institute of Highway Ministry of Transport. The main drafters of this standard. Bao Feng, Yan Jingyi, Yang Qi, dawn. Traffic television monitoring system equipment Graphic symbols and legend

1 Scope

This standard specifies the traffic TV monitoring system used in the device's main graphic symbols and legends. This standard applies to traffic TV monitoring system design, construction, and other industries can also refer to use.

2 Normative references

The following documents for the application of this document is essential. For dated references, only the dated edition applies to this article Member. For undated references, the latest edition (including any amendments) applies to this document. GB/T 5465.2-2008 electrical equipment - Graphical symbols - Part 2. Graphical symbols (IEC 60417DB.2007, IDT) GB/T 15565.1 term Graphical symbols - Part 1. General GB/T 16902.1-2004 graphical symbols - Graphical symbols Rule equipment - Part 1. symbol originals GA/T74-2000 security system common graphical symbols

3 Terms and Definitions

Terms and definitions GB/T 15565.1 defined apply to this document.

4 graphical symbols

4.1 cameras and related equipment symbol legend Cameras and related equipment legend symbols in Table 1. Table 1 cameras and related equipment symbol legend No. Name English name SYMBOL DESCRIPTION Black and white TV Video camera Televisioncamera See 5465.2-2008 in GB/T 's 5116 (In this standard sequence number, the same below) Colour TV Camera Colourtelevisioncamera See GB/T 5465.2-2008 In 5117 ......
