GB/T 28187-2011: Textile machinery -- Dyeing and finishing machines -- Square bars for winding devices -- Dimensions
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 28187-2011	114	Add to Cart	3 days	Textile machinery -- Dyeing and finishing machines -- Square bars for winding devices -- Dimensions	Valid

Similar standards

FZ/T 93048.1   FZ/T 93019   GB/T 39944   GB/T 18737.7   GB/T 28186

Basic data

Standard ID: GB/T 28187-2011 (GB/T28187-2011)
Description (Translated English): Textile machinery -- Dyeing and finishing machines -- Square bars for winding devices -- Dimensions
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: W95
Classification of International Standard: 59.120.50
Word Count Estimation: 6,613
Date of Issue: 2011-12-30
Date of Implementation: 2012-09-01
Quoted Standard: ISO 1505
Adopted Standard: ISO 10458-1993, IDT
Regulation (derived from): Announcement of Newly Approved National Standards No. 23 of 2011
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China
Summary: This standard specifies the dyeing and finishing machines with square shaft winding device classification and size. This standard applies to dyeing machine winding device with square shaft.

GB/T 28187-2011: Textile machinery -- Dyeing and finishing machines -- Square bars for winding devices -- Dimensions

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Textile machinery. Dyeing and finishing machines. Square bars for winding devices. Dimensions ICS 59.120.50 W95 National Standards of People's Republic of China Dyeing and finishing machinery textile machinery Winding device with a square shaft size (ISO 10458.1993, IDT) Issued on. 2011-12-30 2012-09-01 implementation Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China Standardization Administration of China released

Foreword

This standard was drafted in accordance with GB/T 1.1-2009, rules GB/T 2000.2-2009 given. This standard uses the translation method identical with ISO 10458.1993 "dyeing and finishing machines textile machinery square shaft winding installations dimension" (in English). And this standard Normative international document correspondence between consistency of the following documents. --- GB/T 20038-2005 textile machinery dyeing machine and nominal width defined series [ISO 1505.1993 (98), MOD]. The standard proposed by China Textile Industry Association. This standard by the National Standardization Technical Committee Textile machinery and accessories (SAC/TC215) centralized. This standard was drafted. Shaoxing Dongsheng Digital Technology Co., Ltd., Jiangsu red Dyeing Machinery Co., Ltd. Zhangjiagang City Jianye Dyeing Machine Armed Ltd., Shaoyang Textile Machinery Company Limited, Pacific Mechatronic (Group) Co., Ltd., Wuxi Textile Machinery Research Institute. The main drafters. Zhang Bohong, Dai sound, CSC Zhang, Zhou Jun Yan, Lin Jian, Zhao Jiping, Zhang Xiuli. Dyeing and finishing machinery textile machinery Winding device with a square shaft size

1 Scope

This standard specifies the classification and size of the dyeing machine winding device associated with the square shaft. This standard applies to dyeing machine winding device with square shaft.

2 Normative references

The following documents for the application of this document is essential. For dated references, only the dated version suitable for use herein Member. For undated references, the latest edition (including any amendments) applies to this document. ISO 1505 Textile machinery dyeing machine and nominal width definition series (Textilemachinery-Widthsrelating todyeingandfinishingmachines-Definitionsandrangeofnominalwidths) Category 3 Square shaft type is divided into A, B type, shown in Figure 1. a) A Type b) B type d --- both ends of the shaft diameter circle; b --- square shaft section side; l1 --- square shaft full length; l2, l3 --- both ends of the circular shaft length. Note 1. The value of l1, l2 and l3, said width according to the structure of the machine and the public, agreed to by both parties. Note 2. The recommended values \u200b\u200bl1 public may be in the ISO 1505 series of predetermined width, said the selection. Figure 1 square shaft ......
