GB/T 28170.2-2021: Information technology - Computer graphics and image processing - Extensible 3D (X3D) - Part 2: Scene access interface(SAI)
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 28170.2-2021	1484	Add to Cart	6 days	Information technology - Computer graphics and image processing - Extensible 3D (X3D) - Part 2: Scene access interface(SAI)	Valid

Similar standards

GM/T 0132 GB/T 28454 GB/T 28448 GB/T 44247 GB/T 44020 GB/T 28170.1

Basic data

Standard ID: GB/T 28170.2-2021 (GB/T28170.2-2021)
Description (Translated English): Information technology - Computer graphics and image processing - Extensible 3D (X3D) - Part 2: Scene access interface(SAI)
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: L81
Word Count Estimation: 78,771
Issuing agency(ies): State Administration for Market Regulation, China National Standardization Administration

GB/T 28170.2-2021: Information technology - Computer graphics and image processing - Extensible 3D (X3D) - Part 2: Scene access interface(SAI)

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Information technology - Computer graphics and image processing - Extensible 3D (X3D) - Part 2.Scene access interface(SAI) ICS 35.140 L81 National Standards of People's Republic of China Information Technology Computer Graphics and Image Processing Scalable three-dimensional components (X3D) Part 2.Scene Access Interface (SAI) (ISO /IEC 19775-2.2015, IDT) Released on 2021-03-09 2021-10-01 implementation State Administration of Market Supervision and Administration Issued by the National Standardization Management Committee

Foreword Ⅰ Introduction Ⅱ 1 Scope 1 2 Normative references 1 3 Terms and definitions 2 4 Concept 3 4.1 Introduction 3 4.2 Summary 4 4.3 Binding and protocol dependencies 5 4.4 Interface construction 5 4.5 Event 8 4.6 Identifier 9 4.7 Related URLs 9 4.8 Execution Model 10 5 Data type reference 16 5.1 Introduction and topics 16 5.2 Data type definition 18 5.3 Error types 21 5.4 Event types 23 6 Service Reference 24 6.1 Introduction and topics 24 6.2 Create connection 28 6.3 Browser Service 29 6.4 Execution Context Service 40 6.5 Scene Service 47 6.6 Node Service 49 6.7 Domain Services 50 6.8 Routing Service 53 6.9 Proto Type Service 54 6.10 Configuration Service 56 6.11 Services provided by script content 58 6.12 Matrix Service 61 7 Consistency and minimum support requirements 62 7.1 Introduction and topics 62 7.2 Consistency 64 7.3 Minimum requirements 64 Appendix A (normative appendix) VRML script backward compatibility 71 Information Technology Computer Graphics and Image Processing Scalable three-dimensional components (X3D) Part 2.Scene Access Interface (SAI)

1 Scope

This part of GB/T 28170 specifies a set of standard services that can be obtained through a browser, so that users can run the scene graph Access, related access is designed to support interaction and modification with the scene graph.

2 Normative references

The following documents are indispensable for the application of this document. For dated reference documents, only the dated version applies to this article Pieces. For undated reference documents, the latest version (including all amendments) is applicable to this document. GB/T 28170.1-2011 Information Technology Computer Graphics and Image Processing Scalable Three-dimensional Components (X3D) Part 1. Architecture and basic components (ISO /IEC 19775-1.2004, IDT) ISO /IEC 10646 Information Technology Universal Multi-octet Coded Character Set (UCS) [Informationtechnology-Universal multiple-Octetcodedcharacterset(UCS)] ISO /IEC 14496-1.2010 Information Technology Audio and Video Object Coding Part 1.System (Informationtechnology- Codingofaudio-visualobjects-Part 1.Systems) ISO /IEC 14772-1.1997 Information Technology Computer Graphics and Image Processing Virtual Reality Modeling Language Part 1.Function Can standardize and UTF-8 encoding (Informationtechnology-Computergraphicsandimageprocessing-The virtualrealitymodelinglanguage-Part 1.FunctionalspecificationandUTF-8encoding) ISO /IEC 14772-2.2004 Information Technology Computer Graphics and Image Processing Virtual Reality Modeling Language Part 2.Foreign Book Interface [Informationtechnology-Computergraphicsandimageprocessing-Thevirtualreality modelinglanguage(VRML)-Part 2.Externalauthoringinterface(EAI)] ISO /IEC 19776-1.2015 Information Technology Computer Graphics, Image Processing and Environmental Data Representation Extended 3D (X3D) Coding Part 1.Extended Markup Language (XML) coding [Informationtechnology-Computergraphics, image processing and environmentaldata representation-Extensible 3D (X3D) encodings-Part 1. Extensiblemarkuplanguage(XML)encoding] ISO /IEC 19776-2.2015 Information Technology Computer Graphics, Image Processing and Environmental Data Representation Extended 3D (X3D) Coding Part 2.Typical VRML (Virtual Reality Modeling Language) coding [Informationtechnology-Computergraphics, imageprocessingandenvironmentaldatarepresentation-Extensible3D(X3D) encodings-Part 2. ClassicVRMLencoding] ISO /IEC 19776-3.2015 Information Technology Computer Graphics, Image Processing and Environmental Data Representation Extended 3D (X3D) Coding Part 3.Compressed binary coding [Informationtechnology-Computergraphics, imageprocessinganden- vironmentaldatarepresentation-Extensible3D(X3D) encodings-Part 3.Compressedbinaryenco- ding] ISO /IEC 19777-1 Information Technology Computer Graphics, Image Processing and Environmental Data Representation Extended 3D (X3D) Language Coding Part 1.ECMAScript[Informationtechnology-Computergraphicsandimageprocessing-Exten- ---Access the functions of the browser; ---Receive notifications of browser operations, such as unreachable URLs, startup and shutdown; ---Send the event to the node field that can be entered in the scene; ---Read the last value sent by the output node field in the scene; ---You can get a notification when the event changes the value of the node field in the scene. 4.2.2 Compatibility with ISO /IEC 14772 If the X3D browser wants to meet the requirements of ISO /IEC 14772-1.1997, the browser should support the "VRML The event model and semantics defined in "Script Backward Compatibility", and support the functions defined in GB/T 28170.1-2011.This support only It should be used when processing documents conforming to ISO /IEC 14772-1.1997. If the X3D browser wants to meet the requirements of ISO /IEC 14772-2.2004, the browser should use the following rules to determine the content Effectiveness. a) If the user code accesses the browser through EAI, only the VRML file defined in ISO /IEC 14772-2.2004 should be loaded Pieces. If the user code is accessing the browser through EAI, then loading a file that meets the requirements of this section should be a error; b) If the user code accesses the browser through the capabilities provided by the external interaction defined in this section, it should only be loaded X3D file defined in GB/T 28170.1-2011.If the user code is accessing the browser through SAI, add It should be an error to load documents that comply with ISO /IEC 14772-1.1997. 4.3 Binding and protocol dependencies Implementation dependency is defined in terms of language binding or the protocol encoding of the service defined in this section. If a service is defined as real If it is currently dependent, then if it is to be implemented, each binding and coding needs to specify how to implement the service. The binding and coding of these services can define their own implementation-dependent parts in the specification. 4.4 Interface construction 4.4.1 Overview In the X3D browser, there are four main data sets that can be accessed using the SAI service. browser, information about the currently loaded scene Metadata, nodes in the scene graph, and fields in nodes. Definitions and specifications are constructed in the form of services. X3D browser is open A set of services that allow external applications to interact with it. In order to describe these concepts, some terms are defined. 4.4.2 User code Any code that uses the services defined in this section is considered user code. User code can exist in the scene graph or browser outer. You should only use the services provided in this section, not the browser to achieve specific services. In addition, these services are neither written for the browser The ground node is designed for expansion, but not for its use. The browser can provide its own special program interface to realize that does not belong to this part Local extension. If the code uses a dedicated extension, it should not be regarded as user code for the purposes of this section. 4.4.3 Include nodes Containing nodes are nodes in the scene graph that are responsible for representing user codes that want to participate in internal interactions (see 4.8.3 Internal Interactions). User Generation The life cycle of the code should be completely controlled by the containing node. When the containing node is active, the user code is also active. Dang Bao When the containing node is deleted and is no longer regarded as the activation state as defined in 4.4.2.5 object life cycle in GB/T 28170.1-2011, this section The user code contained in the point should be terminated. User code cannot extend the life cycle of the containing node by keeping a reference to its containing node period. The browser is the final arbiter that contains when the node is no longer active. There is no requirement for a one-to-one correspondence between the containing node and its user code. Language binding allows an instance of user code to be included in the node Shared between multiple instances. 4.4.4 Application The application is an external process, not an implicit part of the X3D browser. The application connects in some form at the request of the browser Connect to the X3D browser. The application is neither part of the X3D browser defined in Figure 1 of GB/T 28170.1-2011, It is not part of the execution model defined in 4.4.8.3 of GB/T 28170.1-2011.Application can be in another On a machine from the X3D browser. The application can be responsible for creating an embedded in the application, or attaching to an already running A new browser instance on the browser instance (for example, a small program on a web page). 4.4.5 Session The session defines the life cycle of a single connection between the user code and the X3D browser. A browser can serve multiple sessions at the same time (e.g. For example, multiple script nodes in a scene). An application can contain multiple separate sessions with multiple browsers, but a script node should not. External application Multiple sessions with multiple X3D browsers at the same time are allowed. However, independent implementations may set up such multiple simultaneous sessions Some restrictions. The session is not an achievable part of this section. It is purely a conceptual mechanism through which users can request services. It may be browsing The browser and the external application exist before any connection is established, or it is established at the same time as the browser connection request. 4.4.6 Browser The browser is a basic encapsulation mechanism for effective X3D scene graphs (this is a time advance rather than a file format stored on disk of). Since it contains the entire scene graph, it also provides a minimal set of core capabilities for dynamic manipulation at a coarse level Scene graph. This scene graph may contain at most one active LayerSet node, which should be the root node of this scene graph (see 4.3.2 root node in GB/T 28170.1-2011). Any other items included in the scene that are imported using inline nodes (or through other means) All other LayerSet nodes should be ignored. Users may run many X3D browsers on their machines at the same time. Therefore, each browser should be uniquely identified in the session Symbol to indicate. For multiple requests to a single browser instance, the identifier should be exactly the same. This is to ensure access to a browser instance The two apps can share information in a clear way. Any operation that requires the use of browser functions should use the browser identifier to identify the service request. 4.4.7 Scene The scene represents a single X3D scene graph and all the information about the scene graph. This scene is the programmatic equivalent of an X3D file Things. It can contain nodes, routes, prototype declarations, imports and exports, and all the information that a valid X3D file might contain. In office At any given time, the browser can contain one or more scenes. For example, one scene uses the Inline node to contain another scene. In the browser, the scene does not have to be active or running. The user can construct a new And then programmatically fill in information such as nodes and routes. This scene can then be passed directly to a general program, For example, it is used to publish the printing program of the source file, or used to replace the current scene in the browser. 4.4.8 Nodes and node life cycle A node is the smallest unit of interaction with elements in the scene graph. The node corresponds to the X3D node defined in GB/T 28170.1-2011 with. A node can be deleted from the scene graph as a unit, stored, and then reinserted into the same session at a later time. Another location without adverse effects. Each node is defined by a unique identifier, which is unique to the session. In other words, a single browser may Used by user code to uniquely identify this event when it is not implicitly unique. The mark does not need to be delivered with the service request, and And can be saved as part of the internal implementation of the application program interface. All outputable fields of the node referenced by the application can be read. The read value is the last value sent in the field, or If no event is sent, it is the default value of the field type. The data read is specific to the field type of the field and is Formalized to suit the language or agreement used. 4.4.10 execution context The execution context is runtime semantics, which is equivalent to the name described in 4.4.7 runtime naming scope in GB/T 28170.1-2011 range. It provides a way to include internal interaction code and add a firewall to it. This way is related to the namespace in the file format. The restrictions on supply are similar. For example, when a script in a Proto instance adds a ROUTE, the route is added to the proto, Instead of adding to the general scene. Scenario is a derived type of execution context. When internal interaction requests the current execution context, a scene object is returned. Then, use The user code can check whether the execution context is an instance of the complete scene, and convert it to the corresponding derived type (if available time cost). 4.5 Event 4.5.1 Concept Any short-lived data usage around the X3D scene graph is done through events. Application can be registered from X3D scene graph Receive events and initiate new events. The event is considered to be short-lived and only occurs when a specific behavior occurs. Event should not be saved The reserve should not be delivered to those parties who did not express interest in the event at the time of the event. Example. An application that connects to the browser after loading should not deliver the Initialize event. 4.5.2 Inside the browser The application can write values to or read values from the field. Before the time stamp is represented and marked internally in the X3D browser, this value is not Will become an event. The boundary between the browser and the application is where the event stops. The event cannot exist from outside the X3D browser; that is Say, the application cannot be inserted into the event cascade. The application can be notified of events and initiate new events, but when the event is notified, the browser When the current timestamp event is blocked within the cascade processing, the event cannot be processed and delivered. Allows logging of events for analysis purposes. No event will be generated until the cascade is created. If the internal interaction is directly written into the outputable field of another node, no task will be generated. Any event, so it will not form part of the event cascade. If the internal interaction is written into an inputable field containing a node, then if the field is The theme of ROUTE from other places forms an event with a written value. 4.5.3 Browser to external application 4.5.3.1 Overview The browser can directly communicate with external applications through its own series of events. These events are used to indicate the status of the browser or a Some asynchronous issues. The number and types of events available will depend on the implementation. At a minimum, all implementations that follow this section should provide the following event. The event delivery from the browser to the external application should be guaranteed. 4.5.3.2 Initialization The initialization event is used to indicate that the browser has run a scene during the initialization process (the browser has loaded the world, just in it Just before the release of its first time-related event). At this point, the node identifier will be obtained from the scene's getNode service (see 6.4.7getNode). The initialization event should be immediately generated in the browser and delivered to the application. The event is considered asynchronous. That is, the event The delivery (and any implementation-dependent confirmation scheme) should not delay the time the browser starts to perform model evaluation. 4.5.3.3 Close The close event is used to indicate that the browser will stop running the current scene. This can happen under many different conditions. a) The scene is being replaced (see 6.3.12replaceWorld and 6.3.14loadURL); b) The browser itself is exiting; c) The client application has processed its connection with the browser (see 6.3.25 dispose). The close event should be immediately generated in the browser and delivered to the application. The event is considered asynchronous. In other words, the event's Delivery (and any implementation-dependent confirmation scheme) will not delay the browser from stopping performing model evaluation and closing browser resources unless required Make sure that the event is delivered to the application. 4.5.3.4 No URL available The SAI_BROWSER_URL_ERROR event is used to notify the application that the browser cannot Load any URL/URNs in the asynchronous call (see 6.3.14 loadURL). This means that any URL specified in this call cannot be Load or call payload. Other calls may involve other asynchronous load calls, such as replaceWorld (see 6.3.12 replaceWorld) and createX3DFromString and createX3DFromStream (see 6.3.16 createX3DFromString, 6.3.17createX3DFromStream) can also use this event to indicate the 9.3.2X3DUrlObject in GB/T 28170.1-2011 Any X3DUrlNode loading issues specified, such as inlining, textures and EXTERNPROTO, although not required. 4.5.3.5 Connection interrupted The connection loss error is used to notify the application that the underlying implementation has lost the connection between the browser and the application, thus leading to The service request cannot be granted. For example, a TCP network connection timed out or other similar problems. If the implementation performs some automatic reconnection attempts, the implementation may delay sending the connection loss event. It will only be Sent when it is considered impossible to connect to the browser. After this event is generated, there is no need to forcibly re-establish the connection, nor do you need to try any What kind of automatic reconnection function. 4.6 Identifier The composition of the identifier depends on the implementation. In some cases, representing the node identifier as the entire node (including all field information) can be Can be more effective. Then make a request for field information on the local node. In other implementations, the identifier may be just a simple integer. It is the important responsibility of the browser to ensure that the identifier is unique, so that applications can share data under reasonable environmental constraints. About the environment Bundles can be specified as part of the independent implementation def......
