GB/T 27504-2011: Pressure gauge error table
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 27504-2011	299	Add to Cart	3 days	Pressure gauge error table	Valid

Similar standards

GB/T 20730.2   GB/T 19146   GB/T 22065   GB/T 45358   GB/T 19665   GB/T 27505

Basic data

Standard ID: GB/T 27504-2011 (GB/T27504-2011)
Description (Translated English): Pressure gauge error table
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: N11
Classification of International Standard: 17.100
Word Count Estimation: 13,187
Date of Issue: 2011-10-31
Date of Implementation: 2012-01-01
Quoted Standard: GB/T 8170
Regulation (derived from): Announcement of Newly Approved National Standards No. 15 of 2011
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China
Summary: This standard specifies the basic error limit gauge and hysteresis, tapping displacement, ambient temperature, etc. indication error allowable value. This standard applies to sensitive components of the elastic element is different accuracy levels, measuring range of pressure gauges (referred to as instrumentation). This standard specifies the instrument working environment when the temperature deviates from reference temperature indication error limits, this standard applies only to the elastic modulus temperature coefficient "K" of 0. 04%/��C of the instrument.

GB/T 27504-2011: Pressure gauge error table

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Pressure gauge error table ICS 17.100 N11 National Standards of People's Republic of China Gauge error table Issued on. 2011-10-31 2012-01-01 implementation Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China Standardization Administration of China released

Foreword

The standard proposed by China Machinery Industry Federation. This standard by the national industrial process measurement and control Standardization Technical Committee (SAC/TC124) centralized. This standard is drafted by. Xi'an Institute of Industrial Automation Instrumentation. Participated in the drafting of this standard. West Instrument Group Co., Ltd. instrument factory, Hongqi Instrument Co., Ltd., Ningbo Long Welding Science and Technology Ltd., Leier Da Instrument Co., Ltd., Beijing Const Instrument Technology Co., Ltd. The main drafters of this standard. Luo Juan, Li Zhenghua. Gauge error table

1 Scope

This standard specifies the basic error limit gauges and hysteresis, tapping displacement allowable value, ambient temperature, etc. indication errors. This standard applies to the elastic element is different sensor accuracy class, measuring range of the gauge (the meter). This standard specifies the instrument operating ambient temperature deviates from the reference temperature indication of the margin of error, this standard applies only to the elastic modulus of the material The temperature coefficient "K" of the instrument 0.04%/℃ of.

2 Normative references

The following documents contain provisions which, through reference in this standard and become the standard terms. For dated references, subsequent Amendments (not including errata content) or revisions do not apply to this standard, however, encourage the parties to the agreement are based on research Whether the latest versions of these documents. For undated reference documents, the latest versions apply to this standard. GB/T 8170 numerical rounding rules

3 Technical requirements

3.1 Accuracy class Meter accuracy level is divided into. 0.1, 0.16, 0.25, 0.4, 1.0, 1.6, 2.5, 4.0. 3.2 units of measurement The standard unit of measurement used are. Pa, kPa, MPa. 3.3 numerical rounding rules The value of this standard into homes by rounding rules GB/T 8170 implementation of the provisions. 3.4 Basic error limit 3.4.1 Basic error limits and accuracy of the correspondence between the grades as defined in Table 1. Table 1 Basic error limit Accuracy class 0.1 0.16 0.25 0.4 1.0 1.6 2.5 4.0 Basic error limit (Percentage range) /% ± 0.10 ± 0.16 ± 0.25 ± 0.4 ± 1 ± 1.6 ± 2.5 ± 4 3.4.2 Different accuracy class, measuring range of the instrument, the basic error allowable value specified in Table 2 and Table 3. 3.5 Backlash Correspondence between the provisions of 3.5.1 hysteresis and accuracy class in Table 4. ......
