GB/T 26332.2-2015 English PDF

US$374.00 · In stock
Delivery: <= 3 days. True-PDF full-copy in English will be manually translated and delivered via email.
GB/T 26332.2-2015: Optics and photonics -- Optical coatings -- Part 2: Optical properties
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 26332.2-2015	374	Add to Cart	3 days	Optics and photonics -- Optical coatings -- Part 2: Optical properties	Valid

Similar standards

GB/T 22062   GB/T 4315.1   GB/T 4315.2   GB/T 26332.1   GB/T 26332.6   GB/T 26332.7

Basic data

Standard ID: GB/T 26332.2-2015 (GB/T26332.2-2015)
Description (Translated English): Optics and photonics -- Optical coatings -- Part 2: Optical properties
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: N30
Classification of International Standard: 17.180
Word Count Estimation: 19,129
Date of Issue: 2015-12-10
Date of Implementation: 2016-07-01
Quoted Standard: GB/T 26332.1-2010
Adopted Standard: ISO 9211-2-2010, IDT
Regulation (derived from): National Standard Announcement 2015 No.38
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China
Summary: This standard specifies how to express the optical characteristics of the optical film and shown how its spectral characteristics. This standard does not apply to ophthalmic optics (spectacles) optical film.

GB/T 26332.2-2015: Optics and photonics -- Optical coatings -- Part 2: Optical properties

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Optics and photonics - Optical coatings - Part 2. Optical properties ICS 17.180 N30 National Standards of People's Republic of China Optics and photonics optical film Part 2. Optical properties Part 2. Opticalproperties (ISO 9211-2.2010, IDT) Issued on. 2015-12-10 2016-07-01 implementation Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China Standardization Administration of China released

Table of Contents

Introduction Ⅲ 1 Scope 1 2 Normative references 1 3 Terms and definitions 4 express the optical properties of technical indicators 1 Measurement conditions 1 5 6 spectral characteristics and numerical representation of Illustration 1 6.1 Overview 1 6.2 spectral characteristics value expressed in Rule 2 Rule 6.3 illustrating the spectral characteristics of 3 6.4 illustrates the main optical function 3 Additional terms and definitions in Appendix A (normative) filter and separations of 10

Foreword

GB/T 26332 "Optics and Photonics optical film" is divided into four parts. --- Part 1. Definitions; --- Part 2. Optical properties; --- Part 3. environmental adaptability; --- Part 4. Test methods prescribed. This is Part 2 GB/T 26332 of. This section drafted in accordance with GB/T 1.1-2009 given rules. This section uses the translation method identical with ISO 9211-2.2010 "Optics and photonics optical film - Part 2. Optical properties" (In English). Consistency correspondence between this part of international documents and normative references of our files are as follows. --- GB/T 26332.1-2010 optical film and optical instruments - Part 1. Definitions (ISO 9211-1.1994, IDT) This section is proposed and managed by the China Machinery Industry Federation. This section is drafted. Shenyang Academy of Instrumentation Science Co., Ltd., Zhejiang University, Dalian Institute of Chemical Physics, Tongji University, Shenyang Bo Optical Company, Hangzhou Keting Optical Technology Co., Ltd., National Instruments Component Quality Supervision and Inspection Center. The main drafters of this section. Fees book country, Gao Peng, Yin Xiaojun, Gu Peifu, Zhang Yue light, Sun Long, Wang Zhanshan, Zhao Shuai Feng, Li Ye, Song Shu, Cheng Xinbin, Wang Ruisheng, Wang Feng, Deng Wen Song, Xuqiu Ling Yin Bo, Zhang Lingling. Optics and photonics optical film Part 2. Optical properties

1 Scope

GB/T 26332 specifies the application functions in optical components and coating the surface of the substrate made of optical film classification, specification standards Presentation of conventional characteristics and test methods of measurement, but the provisions are not intended to be used plating methods. This section specifies how to express the optical characteristics of the optical film and shown how its spectral characteristics. This section does not apply to ophthalmic optics (spectacles) optical film.

2 Normative references

The following documents for the application of this document is essential. For dated references, only the dated version suitable for use herein Member. For undated references, the latest edition (including any amendments) applies to this document. ISO 9211-1 Optics and photonics optical film - Part 1. Definitions (Opticsandphotonics-opticalcoatings- Part 1. Definitions)

3 Terms and Definitions

Terms and definitions as defined in ISO 9211-1 apply to this document.

4 express the optical properties of technical indicators

When expressed in optical characteristics Technical indicators shall be given the refractive index of the incident medium and the outgoing media. When the incident angle θ is not 0 ° or for a When the range, should indicate the incident light polarization. If not specified, it is considered a non-polarized light. For the full representation of the optical film, optical properties should be expressed in the smallest combination. The optical properties of the optical films. τ (λ), ρ (λ), α (λ), D (λ) and ΔΦ (λ), the requirements of 6.2 shall be described. Other optical characteristics (such as color or scattering parameters, etc.), by the supply and demand sides Negotiated according to demand.

5 measurement conditions

Spectral characteristic measurement conditions shall be subject to supply and demand sides agreed. Measurement conditions (including the incidence angle, polarization, spectral range and measuring light Bandwidth, etc.) should be based on the principles and methods of measurement, the measuring instruments used to determine. Measurement conditions should be documented, in order to verify the test.

6 illustrates the numerical representation of the spectral characteristics

6.1 Overview This section provides rules for presentation spectral characteristics of the optical film. ......
