GB/T 26099.1-2010: General principles of three-dimensional modeling for mechanical products -- Part 1: General requirements

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
General principles of three-dimensional modeling for mechanical products Part 1. General requirements ICS 01.100.01 J04 National Standards of People's Republic of China General rules for three-dimensional modeling of mechanical products Part 1. General requirements Part 1. Generalrequirements Issued on. 2011-01-10 2011-10-01 implementation Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China Standardization Administration of China released

Foreword

GB/T 26099-2010 "General rules for three-dimensional modeling of mechanical products" is divided into four parts. --- Part 1. General requirements; --- Part 2. part modeling; --- Part 3. assembly modeling; --- Part 4. The model projection drawing. This section GB/T 26099-2010 Part 1 "General rules for three-dimensional modeling of mechanical products," the. This part of the National Technical product documentation Standardization Technical Committee (SAC/TC146) and focal points. This part mainly drafted by. The machine Productivity Promotion Center, Beijing-soft Intentia Information Technology Co., Ltd., China Electronics Technology Group Thirty-eighth Company Institute, Guangxi Yuchai Machinery Co., Ltd., SAIC-GM-Wuling Automobile Co., Ltd., Guangxi Liugong Machinery Unit Limited copies. The main drafters of this section. Zhang Hongqi, sea Yong Jun, Xiao Chengxiang, Wang Lu, Hanlin Lin, Chen Weidong, Liu seized Hua Yan Guangrong, Wenqiu Sheng, He Dandan, Zhang Yan, Lin JR, Lidai Song, Liu Jing. General rules for three-dimensional modeling of mechanical products Part 1. General requirements

1 Scope

This section GB/T 26099 specifies the term three-dimensional modeling of mechanical products, classification and constitute a model, modeling general requirements, the model file Nomenclature, model checking and model management requirements. This section applies to build three-dimensional mechanical product modeling process three-dimensional digital model, application and management.

2 Normative references

The following documents contain provisions which, through reference GB/T 26099 in this section constitute provisions of this section. For dated reference documents Member, all subsequent amendments (not including errata content) or revisions do not apply to this section, however, encouraged to reach under this section Parties to research agreement to use the latest versions of these documents. For undated reference documents, the latest versions apply to this section. GB/T 16722.1 Technical product documentation computer-aided technical information - Security requirements (GB/T 16722.1-2008, ISO 11442.2006, NEQ) GB/T 16722.2 Technical product documentation computer-aided technical information - Original documentation (GB/T 16722.2-2008, ISO 11442.2006, NEQ) GB/T 16722.3 Technical product documentation - computer-aided information processing technology product design process state (GB/T 16722.3-2008, ISO 11442.2006, NEQ) GB/T 16722.4 Technical product documentation computer-aided technical information - Document management and retrieval system (GB/T 16722.4-2008, ISO 11442.2006, NEQ) GB/T 18784 CAD/CAM data quality GB/T 18784.2 CAD/CAM data quality assurance methods GB/T 24734.1 Technical product documentation - Digital product definition data practices - Part 1. Terms and definitions (GB/T 24734.1-2009, ISO 16792.2006, NEQ) GB/T 24734.2-2009 Technical product documentation - Digital product definition data practices - Part 2. Data set identification and control (ISO 16792.2006, NEQ)

3 Terms and Definitions

GB/T 24734.1 and established the following terms and definitions apply to this section. 3.1 Feature feature A collection of geometry or engineering information and the expression of certain features and semantics of a combination of engineering. 3.2 Entity solidbody From the surface or edge forms a closed volume of the three-dimensional geometry. 3.3 Maturity maturedegree The design is completed and the degree of perfection of quantitative description, its value ranges from 0 to 1. ......
