| Standard ID | GB/T 25026-2017 (GB/T25026-2017) | | Description (Translated English) | Structure, main size and basic parameters of one-piece glass-lined steel vessels with agitator | | Sector / Industry | National Standard (Recommended) | | Classification of Chinese Standard | G94 | | Classification of International Standard | 71.120; 25.220.50 | | Word Count Estimation | 22,212 | | Date of Issue | 2017-09-29 | | Date of Implementation | 2018-02-01 | | Older Standard (superseded by this standard) | GB/T 25026-2010 | | Quoted Standard | GB 25025; HG/T 2048.1; HG/T 2050; HG/T 2051.3; HG/T 2051.4; HG/T 2052; HG/T 2054; HG/T 2055.1; HG/T 2055.2; HG/T 2057; HG/T 2058.1; HG/T 2058.2; HG/T 2143; HG/T 3217; HG/T 3218; HG/T 20592; JB/T 4712.3; JB/T 4712.4 | | Regulation (derived from) | National Standard Notice 2017 No. 23 | | Issuing agency(ies) | People's Republic of China General Administration of Quality Supervision, Inspection and Quarantine, China National Standardization Administration | | Summary | This standard specifies the definition, type, main dimensions and basic parameters of glass-lined closed vessel, marking. This standard applies to the design pressure of the inner container is less than or equal to 1.0 MPa, nominal volume of 1000 L ~ 40 000 L, U-type jacket design pressure is less than or equal to 0.6 MPa, inner container and jacket design temperature higher than -20 �� ~ 200 �� glass-lined closed mixing vessel. |
GB/T 25026-2017
Structure, main size and basic parameters ofone piece glass-lined steel vessels with agitator
ICS 71.120; 25.220.50
G94
National Standards of People's Republic of China
Replacing GB/T 25026-2010
Glass-lined closed container type,
The main dimensions and basic parameters
Structure, mainsizeandbasicparametersof
2017-09-29 Posted
2018-02-01 implementation
General Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China
China National Standardization Administration released
Foreword
This standard was drafted in accordance with the rules given in GB/T 1.1-2009.
This standard replaces GB/T 25026-2010 "glass-lined closed mixing vessel", compared with GB/T 25026-2010, in addition to editorial repair
Change the main technical changes are as follows.
--- Increase 1000L ~ 40000L fully enclosed structure of glass-lined mixing vessel type, main dimensions and basic parameters;
--- Nominal diameter DN1200 ~ DN2000 mixing vessel, adjust the interchangeable nozzle N1 and nozzle T position;
--- Nominal diameter DN2200 ~ DN3600 mixing vessel, nozzle N1 orientation from 40 ° to 45 °;
--- Remove the original standard 6.1 "glass-lined closed vessel design, manufacture, inspection and acceptance according to GB 25025 and the relevant standards
Norms, "6.2" glass-lined closed container mixing all accessories, such as manhole, high-neck flange, manhole flange, nozzle, clip, looper
Flanges, transmissions, agitators, seals, gaskets, thermometer covers (including bezels), sight glasses and flange covers must comply with phase
Should be glass-lined equipment parts standards, "6.3" glass-lined closed mixing vessel should be carried out with water to bring the pressure
Mixing operation test, the test results should be consistent with the requirements of the design drawings ";
--- Delete the original standard chapter 7 "factory documents, packaging, transportation and storage."
This standard proposed by the China Petroleum and Chemical Industry Federation.
This standard by the National Glass-lined Equipment Standardization Technical Committee (SAC/TC72) centralized.
The main drafting units of this standard. Zibo Taiji Industrial Enamel Co., Ltd., Suzhou City, Chemical Equipment Co., Ltd., Jiangsu Yang Yang Chemical
Equipment Manufacturing Co., Ltd., Zibo Bao Te Chemical Technology Co., Ltd., Jiangyin Chemical Equipment Factory, Gansu Province Boiler and Pressure Vessel Inspection Institute,
Tianhua Chemical Machinery and Automation Research and Design Institute Co., Ltd., Chemical Industry Non-metallic Materials and Equipment Quality Supervision and Inspection Center.
The main drafters of this standard. Qian Jianfeng, Sang Linchun, Fu Jun, Zhu Hongzhi, Xu Tao, Eternal Red, Xu Guoping, Li Wei, Ding Jigen, Zhang Zhongli,
Wei hole hill.
This standard replaces the standards previously issued as.
--- GB/T 25026-2010.
Glass-lined closed container type,
The main dimensions and basic parameters
1 Scope
This standard specifies the definition, type, main dimensions and basic parameters of glass-lined closed vessel, marking.
This standard applies to the inner container design pressure is less than or equal to 1.0MPa, nominal volume 1000L ~ 40000L, U-type jacket design
Pressure less than or equal to 0.6MPa, inner container and jacket design temperature higher than -20 ℃ ~.200 ℃ glass-lined closed vessel.
2 Normative references
The following documents for the application of this document is essential. For dated references, only the dated version applies to this article
Pieces. For undated references, the latest edition (including all amendments) applies to this document.
GB 25025 glass-lined equipment technical conditions
HG/T 2048.1 glass-lined packing box
HG/T 2050 glass-lined equipment gasket
HG/T 2051.3 glass-lined blender impeller stirrer
HG/T 2051.4 glass-lined mixer paddle mixer
HG/T 2052 glass-lined equipment transmission
HG/T 2054 glass-lined equipment clip
HG/T 2055.1 glass-lined manhole
HG/T 2055.2 glass-lined with manhole lens
HG/T 2057 Glass-lined mixing vessel with mechanical seal
HG/T 2058.1 glass-lined thermometer sets
HG/T 2058.2 glass-lined baffle thermometer sets
HG/T 2143 glass-lined equipment nozzle
HG/T 3217 glass-lined on the discharge valve
HG/T 3218 enamel under the exhibition-style discharge valve
HG/T 20592 steel pipe flange (PN series)
JB/T 4712.3 container support part 3 ear bearing
JB/T 4712.4 container support part 4 support bearings
3 Terms and definitions
The following terms and definitions apply to this document.
3.1
Calculate the volume capacityforunderagitatorflangedoragitatornozzles
When the head of the container is provided with the equipment flange, it means the volume below the flange. When the head of the container is not provided with the equipment flange, the mixing shaft
Hole below the volume.
......
GB/T 25026-2010
One piece glass-lined steel ships with agitator
ICS 71.120; 25.220.50
G94
National Standards of People's Republic of China
Glass - lined closed mixing container
2010-09-02 release
2011-01-01 implementation
General Administration of Quality Supervision, Inspection and Quarantine of the People 's Republic of China
China National Standardization Management Committee released
Preface
This standard refers to DIN28136.1..2005 "Main dimensions of the mixing vessel" in the glass-lined stirrer part, DIN28136.3..2005
"Glass-lined glass mixing container on the head of the nozzle position and size", DIN28137.3. 1983 "glass-lined mixing tank mixing port deceleration machine seat method
Blue connection dimensions ", DIN 28140.2. 1978" Connection dimensions of discharge valve and glass-lined container PN1.0 ", DIN28145.3. 1982
"Location and size of welding lugs on glass-lined containers" and DIN28151..1999 "Industrial glass-lined agitated containers
And the size of the "HG/T 2372-2003" glass-lined closed mixing container "in the implementation process found problems and shortcomings, combined with me
State glass-making equipment manufacturing process characteristics and manufacturing level to develop.
This standard is proposed by the China Petroleum and Chemical Industry Association.
This standard is nationalized by the National Standardization Technical Committee for Glass Coated Equipment (SAC/TC72).
The main drafting of this standard. Jiangsu Province, Liyang City Yunlong Equipment Manufacturing Co., Ltd., Changshu City, Mao Chemical Equipment Co., Ltd., Suzhou
City Chemical Chemical Equipment Co., Ltd., Ningbo Mingxin Chemical Machinery Co., Ltd., Jiangyin Chemical Equipment Factory, chemical industry non-metallic materials
And equipment quality supervision and inspection center.
This standard participates in the drafting unit. Zibo Industrial Enamel Factory, Jiangsu Huadong Mingmao Machinery Co., Ltd., Tianhua Chemical Machinery and Automation Research
Design Institute.
The main drafters of this standard. Qian Jianfeng, Yong Zhaoming, Sang Linchun, Zhou Zhiqiang, Qiu Weiping, Xu Guoping, Zheng Guidong.
This standard participates in the drafters. Yang Changming, Yu Fei, Zhang Nan.
Glass - lined closed mixing container
1 Scope
This standard specifies the terminology and definition of the glass-lined closed mixing vessel, the basic parameters and the main dimensions, types and technical characteristics.
As well as factory documents, packaging, transportation and storage.
This standard applies to internal design pressure less than or equal to 1.0MPa, nominal volume greater than or equal to 3000L, less than or equal to
40000L, U-type jacket within the design pressure is less than or equal to 0.6MPa, the inner container and jacket design temperature is higher than -20 ℃ ~.200 ℃
Glass - lined closed mixing container.
2 normative reference documents
The terms of the following documents are hereby incorporated by reference into this standard. Whichever is the date of the reference file, which is followed by all
(Excluding corrigenda) or revisions do not apply to this standard, however, encourage the parties to reach an agreement under this standard
Whether you can use the latest version of these files. For undated references, the latest edition applies to this standard.
GB 25025 glass - lined equipment technical conditions
HG/T 2048 enamel packing box
HG/T 2049 glass-lined equipment high-neck flange
HG/T 2050 glass-lined equipment gasket
HG/T 2051 glass-lined stirrer
HG/T 2052 glass - lined equipment transmission
HG/T 2054 glass-lined equipment
HG/T 2055 glass-lined manhole
HG/T 2057 glass-lined container with mechanical seal
HG/T 2058 glass-lined thermometer sets
HG/T 2143 glass - lined equipment
HG/T 3217 glass-lined on the release valve
HG/T 3218 glass curtain under the discharge valve
HG20592 steel pipe flange parameters and type
JB/T 4712.3 ear type bearing
JB/T 4712.4 support bearing
JB/T 4746 Head for steel pressure vessels
3 terms and definitions
The following terms and definitions apply to this standard.
3.1
Glasses closed mixing containers onepieceglass-lindsteelvesselswithagitator
Container head set less than one-half the head diameter of the high-neck flange with a stirrer glass-lined container, code-named F, structural
See Figure 1.
3.2
Calculate the capacity capacityforunderagitatorflange
High neck flange below the volume.
......
|
