US$854.00 · In stock
Delivery: <= 5 days. True-PDF full-copy in English will be manually translated and delivered via email.
GB/T 24744-2009: Geometrical product specifications (GPS) -- Drawing indications for moulded parts in technical product documentation (TPD)
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 24744-2009	854	Add to Cart	5 days	Geometrical product specifications (GPS) -- Drawing indications for moulded parts in technical product documentation (TPD)	Valid

Similar standards

GB/T 23901.5 GB/T 23901.4 GB/T 23907 GB/T 24734.11 GB/T 24734.1 GB/T 24734.10

Basic data

Standard ID: GB/T 24744-2009 (GB/T24744-2009)
Description (Translated English): Geometrical product specifications (GPS) -- Drawing indications for moulded parts in technical product documentation (TPD)
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: J04
Classification of International Standard: 01.100.01
Word Count Estimation: 43,432
Date of Issue: 2009-11-30
Date of Implementation: 2010-09-01
Quoted Standard: GB/T 131; GB/T 1804; GB/T 1182; GB/T 4457.2; GB/T 4457.4; GB/T 15757; GB/T 16671; GB/T 17851; GB/T 18780.1; GB/T 18780.2; GB/T 19096; ISO 129-1; ISO 7083; ISO 8062-1-2007; ISO 14405; ISO 81714-1
Adopted Standard: ISO 10135-2007, IDT
Regulation (derived from): National Standard Approval Announcement 2009 No.14 (Total No.154)
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China
Summary: This standard specifies the technical product documentation moldings rules and graphical symbols represent the proportion and size. This standard applies to cast, draw forging process of pattern.

GB/T 24744-2009: Geometrical product specifications (GPS) -- Drawing indications for moulded parts in technical product documentation (TPD)

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Geometrical product specifications (GPS) .Drawing indications for moulded parts in technical product documentation (TPD) ICS 01.100.01 J04 National Standards of People's Republic of China GB/T 24744-2009/ISO 10135.2007 Geometrical product specifications (GPS) Technical product documentation (TPD) in molding notation (ISO 10135.2007, IDT) Posted 2009-11-30 2010-09-01 implementation Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China Standardization Administration of China released

Preface Ⅰ 1 Scope 1 2 Normative references 1 3 Terms and definitions 2 4 letter code 2 5 linear provisions 2 6 molding notation 3 6.1 parting surface 3 6.2 Process Identifier 4 6.3 jack special identifier 6 6.4 6 wrong move 6.5 flash 9 6.6 range specified label 11 6.7 draft angle 16 The direction of movement of the tool 26 6.8 Local motion direction 27 6.9 6.10 Surface Strengthening 28 6.11 dent 29 6.12 porosity 30 6.13 identification and marking 30 6.14 Additional information required 31 6.15 without interference surface 31 special labeling 7 linear dimensions, geometric dimensioning and tolerancing annotation rule 32 Appendix A (normative) ratio and size of the graphic symbols 36 Annex B (informative) conical feature 39 GB/T 24744-2009/ISO 10135.2007

Foreword

This standard is identical with ISO 10135.2007 "Geometrical Product Specifications (GPS) technology product documentation (TPD) in the molding of representation." Appendix A of this standard is a normative appendix, Appendix B is an informative annex. This standard by the National Technical product documentation Standardization Technical Committee (SAC/TC146) and focal points. This standard was drafted. the machine Productivity Promotion Center, Jiangsu Teachers University, Jilin University. The main drafters of this standard. thanks to Yang, Wang Huai Germany, Wang Xiuying, Pang Wei. GB/T 24744-2009/ISO 10135.2007 Geometrical product specifications (GPS) Technical product documentation (TPD) in molding notation

1 Scope

This standard specifies the technical product documentation molding representation rules and graphic symbols proportions and dimensions. This standard applies to casting, forging process of drawing pattern.

2 Normative references

The following documents contain provisions which, through reference in this standard and become the standard terms. For dated references, subsequent Amendments (not including errata content) or revisions do not apply to this standard, however, encourage the parties to the agreement are based on research Whether the latest versions of these documents. For undated reference documents, the latest versions apply to this standard. GB/T 131 Geometrical product specifications (GPS) technology products in the surface structure of the file notation (GB/T 131-2006, ISO 1302.2002, IDT) GB/T 1804 General tolerances Tolerances for linear and angular dimensions without individual tolerance (GB/T 1804-2000, eqv ISO 2768-1. 1989) GB/T 1182 Geometrical product specifications (GPS) geometric tolerances of form, orientation, location and runout tolerancing (GB/T 1182-2008, ISO 1101.2004, IDT) The basic provisions of GB/T 4457.2 Technical drawings - Leader and baseline (GB/T 4457.2-2003, ISO 128-22.1999, Technicaldrawings-Generalprinciplesofpresentation-Part 22. Basicconventions andapplicationsforleaderlinesandreferencelines, IDT) GB/T 4457.4 Mechanical drawings Fatou line (GB/T 4457.4-2002, ISO 128-24.1999, Technical drawings-Generalprinciplesofpresentation-Part 24. Linesonmechanicalengineeringdrawing, MOD) GB/T 15757 Geometrical product specifications (GPS) Surface imperfections - Terms, definitions and parameters (GB/T 15757-2002, eqv ISO 8785.1998) GB/T 16671 Geometrical product specifications (GPS) Geometrical tolerancing - Maximum material requirement, the minimum physical demand and reversible demand (GB/T 16671-2009, ISO 2692.2006, MOD) GB/T 17851 shape and position tolerances and datum reference system (GB/T 17851-1999, eqv ISO 5459. 1981) GB/T 18780.1 Geometrical product specifications (GPS) - Geometrical features - Part 1. Basic terms and definitions (GB/T 18780.1-2002, idt ISO 14660-1.1999) GB/T 18780.2 Geometrical product specifications (GPS) - Geometrical features - Part 2. Extract the center cylindrical and conical face Lines parallel to the plane of the central surface extraction, feature extraction local dimension (GB/T 18780.2-2003, ISO 14660-2.1999, IDT) GB/T 19096 Technical drawings edges of undefined shape terminology and injection method (GB/T 19096-2003, ISO 13715.2000, Technicaldrawings-Edgesofundefinedshape-Vocabularyandindications, IDT) ISO 129-1 Technical drawings showing dimensions and tolerances - Part 1. General principles ISO 7083 Technical drawings - Symbols for geometrical tolerancing of dimensions and proportions ISO 8062-1.2007 Geometrical product specifications (GPS) molding dimensions and geometric tolerances - Part 1. Vocabulary ISO 14405 Geometrical product specifications (GPS) dimensional tolerances GB/T 24744-2009/ISO 10135.2007 ......
