GB/T 24637.4-2020 English PDF

US$259.00 · In stock
Delivery: <= 3 days. True-PDF full-copy in English will be manually translated and delivered via email.
GB/T 24637.4-2020: Geometrical product specifications (GPS) - General concepts - Part 4: Geometrical characteristics for quantifying GPS deviations
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 24637.4-2020	259	Add to Cart	3 days	Geometrical product specifications (GPS) - General concepts - Part 4: Geometrical characteristics for quantifying GPS deviations	Valid

Similar standards

GB/T 23901.5   GB/T 23901.4   GB/T 23907   GB/T 24630.1   GB/T 24637.3   GB/T 24637.1

Basic data

Standard ID: GB/T 24637.4-2020 (GB/T24637.4-2020)
Description (Translated English): Geometrical product specifications (GPS) - General concepts - Part 4: Geometrical characteristics for quantifying GPS deviations
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: J04
Classification of International Standard: 17.040.30
Word Count Estimation: 14,192
Date of Issue: 2020-04-28
Date of Implementation: 2020-11-01
Issuing agency(ies): State Administration for Market Regulation, China National Standardization Administration

GB/T 24637.4-2020: Geometrical product specifications (GPS) - General concepts - Part 4: Geometrical characteristics for quantifying GPS deviations

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Geometrical product specifications (GPS) - General concepts - Part 4.Geometrical characteristics for quantifying GPS deviations ICS 17.040.30 J04 National Standards of People's Republic of China Product Geometric Technical Specification (GPS) General Concept Part 4.GPS deviation quantification of geometric features 2020-04-29 released 2020-11-01 implementation State Administration for Market Regulation Issued by the National Standardization Management Committee

Foreword

GB/T 24637 "Geometric Technical Specifications for Products (GPS) General Concepts" is divided into 4 parts. ---Part 1.Geometric specifications and inspection models; ---Part 2.Basic principles, specifications, operation set and uncertainty; ---Part 3.Elements to be tested; ---Part 4.GPS deviation quantification of geometric features. This part is Part 4 of GB/T 24637. This section was drafted in accordance with the rules given in GB/T 1.1-2009. This part uses the redrafting method to modify and adopt ISO 17450-4.2017 ``Geometrical Technical Specifications for Products (GPS) General Concepts No. Part 4.GPS deviation quantification of geometric features. Compared with ISO 17450-4.2017, this part has technical differences. The corresponding technical differences and their reasons are as follows. ---Regarding normative reference documents, this section has made adjustments with technical differences to adapt to my country's technical conditions and adjustments. The situation is collectively reflected in Chapter 2 "Normative Reference Documents", and the specific adjustments are as follows. ● Replace ISO 25378 with GB/T 38761 which is modified to adopt international standards. This part is proposed and managed by the National Standardization Technical Committee for Product Geometric Technical Specifications (SAC/TC240). Drafting organizations of this section. Hangzhou Changgeng Measurement Technology Co., Ltd., China Machinery Productivity Promotion Center, Beijing Times Peak Technology Co., Ltd., Shanghai Institute of Metrology and Testing Technology, Zhengzhou University. The main drafters of this section. Zheng Peng, Ming Cuixin, Zhao Jun, Hao Jianguo, Zhu Yue, Zhang Rui, Zhang Bo. Product Geometric Technical Specification (GPS) General Concept Part 4.GPS deviation quantification of geometric features

1 Scope

This part of GB/T 24637 gives the GPS deviation quantification rules for a single GPS feature. This section is suitable for quantifying GPS deviations that represent geometric features. Note. GPS deviation can be local or global. The GPS feature defined by the local GPS deviation is a parameter, which is The number (see Table 1) converts the local deviation set into a global feature.

2 Normative references

The following documents are indispensable for the application of this document. For dated reference documents, only the dated version applies to this article Pieces. For undated references, the latest version (including all amendments) applies to this document. GB/T 38761 Product Geometric Technical Specification (GPS) Features and Condition Definition (GB/T 38761-2020, ISO 25378.2011, MOD)

3 Terms and definitions

The following terms and definitions defined in GB/T 38761 apply to this document. 3.1 Local geometric deviation The local distance value from a point "P" on the input element to the point on the reference element, the local distance value is positive or negative. Note 1.d(P) defines any local geometric deviation of any point (P) of the input element. Note 2.The local geometric deviation d(P)An can be defined in an n-dimensional reference space An belonging to the reference element. Note 3.There are local geometric deviations at any point of the input features (see Figure 1). Each local geometric deviation can be corresponded with reference elements in the reference space An The point and the coordinate corresponding to the local geometric deviation are expressed. Note 4.The local geometric deviation can be expressed in the reference space An by the point coordinates on the change curve. Note 5.When the deviation element intersects the reference element, the local geometric deviation is equal to zero. 3.2 Reference space An A space defined by n curvilinear coordinate axes, which belong to a reference element, and the input is defined based on the reference element The local deviation of each point on the feature. Note. For the reference line n is equal to 1, and for the reference surface n is equal to 2. 3.2.1 Surface reference space A2 The reference space (3.2) when the reference feature is a polygon. Note. The reference space is a two-dimensional size reference element. 3.2.2 Line reference space A1 The reference space (3.2) when the reference element is a straight line. Note. The reference space is a one-dimensional size reference element. 3.2.3 Bidirectional reference space Two line reference spaces that have the same line reference feature and are orthogonal to any point P on the reference feature (3.2.2) The combination. 3.3 Quantization function Quantify a mathematical function of a geometric feature with a complete set of local deviations. Note. The quantization function can be a statistical function (see Table 1). 3.4 Statistical Features Geometric features defined by a set of local geometric deviations mathematically. Note. The statistical characteristics are defined by the quantization function. Table 1 gives formulas for several statistical characteristics. 3.4.1 Max A set of characteristic maximum values of local geometric deviations. Note. See Table 1. 3.4.2 Minimum A set of characteristic minimum values of local geometric deviations. Note. See Table 1. 3.4.3 Mean A set of characteristic average values of local geometric deviations. Note. See Table 1. 3.4.4 Median A set of characteristic median values of local geometric deviations. Note 1.The median value divides the overall local geometric deviation into two equal parts (50% each). Depending on the overall distribution, the median and mean may be the same. It may be different. Note 2.See Table 1. 3.4.5 Median The characteristic average of the maximum value (3.4.1) and the minimum value (3.4.2). Note. See Table 1. 3.4.6 Range The characteristic difference between the maximum value (3.4.1) and the minimum value (3.4.2). Note. See Table 1. 3.4.7 Maximum absolute deviation The characteristic maximum value of the absolute value of the maximum value (3.4.1) and the minimum value (3.4.2). Note. See Table 1.

4 Geometric features

4.1 Overview Several types of geometric features, as defined in GB/T 38761, are as follows. --- Essential characteristics. size, shape or surface structure characteristics; ---Azimuth characteristics. position, direction and beating characteristics. For a geometric feature, the fitting element of the input element is its reference element (see Figure 2). Note 1.The reference element is the fitting element. For more information, please refer to GB/T 17851. Note 2.It is assumed that the points in the required range on the reference element meet the correspondence with the corresponding point in the input element. In some cases, mathematical extensions of reference elements are required, The rules for this extension are not given in this document. For details, please refer to the relevant standards of GPS features. a) Unconstrained (shape deviation) b) Directional constraint (directional deviation) c) There are position constraints (local position deviation) The reference elements for evaluating essential characteristics (size, shape, or surface structure characteristics) are independent of the benchmark system. The reference element for evaluating the azimuth characteristics is related to the benchmark system (defining direction or location constraints). Reference elements can be. ---Fully constrained, that is, all non-redundant degrees of freedom are constrained; --- Partially constrained, that is, not all non-redundant degrees of freedom are constrained. For geometric features such as shape, direction, position or runout, the shape of the reference element defaults to the nominal shape of the measured element. When tested The nominal shape of the element belongs to the prism or complex constant class, so its definition is related to the nominal length. In order to define arbitrary bias based on reference elements Poor, it is necessary to give an unconstrained definition of reference elements. Compared with the nominal shape, the extension of the reference element is defined as the curvature of the nominal shape by default. continue. 4.2 Types of geometric features Local geometric deviation is the basic element to establish geometric features. The direction away from the material is usually regarded as the positive direction. The default is defined as the minimum distance from a point on the measured element to the reference element (see Figure 3). Note. The local geometric deviation is defined by any point in the input elements, but for reference elements, this is not necessary. Set of minimum distance and normal distance The collections need not be the same. The input feature can be an extracted feature, a filtered feature, or a constrained fitting feature. If the input feature is a complete line, then the geometric feature is a line geometric feature. If the input feature is a complete surface, then This geometric feature is a face geometric feature. If the input element is. ---A derived surface, then the reference space is the surface reference space; ---A line on a complete surface, then the reference space is a line reference space; ---An export line in the space, then the reference space is a two-way reference space; ---An export point, then the reference space is the line reference space; ---A component point, then the reference space is a line or area reference space. Example. When the input feature is a cylindrical lead-out line (center line), the surface reference space is a cylindrical space. Any geometric feature is established by the quantization function of the local geometric deviation set (see the example in Table 1). Each quantization function is built on. a) Variation curve of local geometric deviation; b) Change curve of support rate; c) Amplitude distribution variation curve. A local coordinate system is defined in the reference space An, and the variation curve of the local geometric deviation is in the reference space (line or surface) The local geometric deviation set (local coordinate value) in. The curve can be drawn in a reference space that directly displays local coordinate values (See Figure 5). Note 1.Since the local geometric deviation is defined by any point of the input feature, there are three possibilities for any coordinate in the reference space. no additional local geometry Deviation, there is an additional local geometric deviation, and there are multiple additional local geometric deviations (when the input feature is more locally smooth than the reference feature). The support rate curve is the conversion of the local geometric deviation variation curve. The definition of support ratio is any number between the minimum and maximum The percentage of entities of any feature. Note 2.The support rate curve can be understood as the cumulative probability function in the reference space. The amplitude distribution variation curve is a kind of deformation of the local geometric deviation variation curve. The amplitude distribution variation curve is one of the support ratio curves A derived definition, which represents the probability in a reference space where the local deviation level is a fixed value. The geometric features are defined by a quantization function, which is a kind of mathematical operator. The quantization functions given in Table 1 are used in the game Part of the geometric deviation change curve (see GB/T 38761). When the geometric characteristics are obtained from the support ratio or the amplitude distribution variation curve, other mathematical operators can also be defined. Note 3.At any position near the extracted (composed or derived) element, mathematical operators can be used for a certain part of the geometric element. Mathematical operators can be used first It is used in one direction of the reference space, and then used in other directions, or directly used in the two directions of the reference space. This process can be repeated Until the geometric feature becomes a global feature. a For details, see GB/T 3358.1. bn extraction points, each with a weight wi. When the extracted points of the measured feature are uniformly distributed, the weight of these extracted points is 1. c When establishing the reference element using the minimum and maximum criterion (Chebyshev criterion without entity constraints), use the "double maximum deviation" formula and The "range" formula gives the same result. d For geometric specifications, the target value τ is considered equal to zero. In the geometric specification, the quantization functions in Table 1 are used to define geometric features. Figure 6 shows the set of local geometric deviations, which are defined by the signed distance value between the extracted combined element and the reference element. Shown The local geometric deviation set is a circle with a certain size in the reference system, and these local distances constitute a variation curve.

Appendix A

(Informative appendix) Relationship with GPS matrix model A.1 Overview For the complete details of the GPS matrix model, see GB/T 20308. The GPS matrix model in GB/T 20308 summarizes the GPS system, and this part is a part of the system. Unless otherwise stated Obviously, the GPS basic rules given in GB/T 4249 are applicable to this part, and the default rules given in GB/T 18779.1 are applicable in accordance with this part. Developed specifications. A.2 Information about standards and their use This section gives general rules for establishing GPS features. A.3 Position in GPS matrix model This part is a general GPS standard. The rules and principles given in this section apply to all marked solid points in the GPS matrix part. A.4 Related standards The standards involved in the standard chain shown in Table A.1 are related standards. references [1] GB/T 3358.1 Statistics vocabulary and symbols Part 1.General statistical terms and terms used in probability [2] GB/T 4249 Geometric Technical Specification for Products (GPS) Basic Principles Concepts, Principles and Rules [3] GB/T 17851 Product Geometric Technical Specification (GPS) Geometric Tolerance Datum and Datum System [4] GB/T 18779.1 Product Geometrical Quantity Technical Specification (GPS) Measurement and Inspection of Workpiece and Measuring Equipment Part 1 Press Standardizing inspection rules for qualified or unqualified [5] GB/T 20308 Product Geometric Technical Specification (GPS) Matrix Model [6] GB/T 24637.1 Product Geometric Technical Specification (GPS) General Concept Part 1.Geometric Specification and Inspection Model [7] GB/T 24637.2 Product Geometric Technical Specification (GPS) General Concept Part 2.Basic Principles, Specifications, Operational Sets and uncertainty [8] GB/T 24637.3 Product Geometric Technical Specification (GPS) General Concept Part 3.Measured Elements ......
