GB/T 24425.5-2009: Internal thread for wire thread inserts
Status: Valid

Standard ID	USD	BUY PDF	Lead-Days	Standard Title (Description)	Status
GB/T 24425.5-2009	139	Add to Cart	3 days	Internal thread for wire thread inserts	Valid

Similar standards

GB/T 24425.1 GB/T 18230.5 GB/T 18230.3 GB/T 24425.4 GB/T 24425.6 GB/T 24425.3

Basic data

Standard ID: GB/T 24425.5-2009 (GB/T24425.5-2009)
Description (Translated English): Internal thread for wire thread inserts
Sector / Industry: National Standard (Recommended)
Classification of Chinese Standard: J13
Classification of International Standard: 21.060.10
Word Count Estimation: 6,699
Date of Issue: 2009-10-15
Date of Implementation: 2010-03-01
Quoted Standard: GB/T 192; GB/T 197
Regulation (derived from): National Standard Approval Announcement 2009 No.11 (Total No.151)
Issuing agency(ies): General Administration of Quality Supervision, Inspection and Quarantine of the People's Republic of China, Standardization Administration of the People's Republic of China
Summary: This standard specifies the nominal diameter of 2mm ~ 39 mm, pitch O. 4 mm ~ 4 mm mounting wire thread dimensions and tolerances apply basic internal threads.

GB/T 24425.5-2009: Internal thread for wire thread inserts

---This is a DRAFT version for illustration, not a final translation. Full copy of true-PDF in English version (including equations, symbols, images, flow-chart, tables, and figures etc.) will be manually/carefully translated upon your order.
Internal thread for wire thread inserts ICS 21.060.10 J13 National Standards of People's Republic of China Wire thread internal thread Posted 2009-10-15 2010-03-01 implementation Administration of Quality Supervision, Inspection and Quarantine of People's Republic of China Standardization Administration of China released

Foreword

This part is the "wire thread insert" one of series of standards to national standards, the series includes. a) GB/T 24425.1-2009 common type wire thread insert; b) GB/T 24425.2-2009 common type blind hole with a wire nut; c) GB/T 24425.3-2009 locking type wire thread insert; d) GB/T 24425.4-2009 locking type blind hole with a wire nut; e) GB/T 24425.5-2009 wire thread within the thread; f) GB/T 24425.6-2009 wire thread insert technical conditions. This part of GB/T 24425 Part 5. This part is proposed by China Machinery Industry Federation. This part of the National Standardization Technical Committee fasteners (SAC/TC85) centralized. This section is responsible for drafting units. the machine Productivity Promotion Center, Shenyang Liming mechanical components factory. Participated in the drafting of this section. Shanghai Co., Ltd. Ball prescribed standards. This part of the National Standardization Technical Committee Secretariat responsible for the interpretation of fasteners. Wire thread internal thread

1 Scope

This section GB/T 24425 specifies the nominal thread diameter 2mm ~ 39mm, pitch for the installation of the wire 0.4mm ~ 4mm Lo apply the basic dimensions and tolerances internal thread. After the wire thread insert is screwed into the internal thread of the provisions of this section, the formed internal thread diameter tolerance zone is applied to the inner wire thread diameter male thread Difference between the band and wire thread tolerance surface dwelling constitution. This section provides an internal thread for 5H and 6H (GB/T 197), it is recommended common type wire Nut selection 6H, locking wire thread insert type selection 5H. Note. This section uses the "nominal thread diameter" and "wire Lo sets of specifications" refers to the wire thread sets specified in this part of the internal thread, the internal thread is formed Nominal thread diameter and thread size.

2 Normative references

The following documents contain provisions which, through reference GB/T 24425 in this section constitute provisions of this section. For dated reference documents Member, all subsequent amendments (not including errata content) or revisions do not apply to this section, however, we are encouraged to reach agreement under this section All parties that proposed to use the latest versions of these documents. For undated reference documents, the latest versions apply to this section. GB/T 192 ordinary screw threads - Basic model (GB/T 192-2003, ISO 68-1.1998, ISO generalpurposescrew threads-Basicprofile-Part 1. Metricscrewthreads, MOD) GB/T 197 common thread tolerance (GB/T 197-2003, ISO 965-1.1998, ISO generalpurposemetric screwthreads-Tolerances-Part 1. Principlesbasicdata, MOD)

3 the thread type and tolerance

Basic tooth type wire thread internally threaded comply with GB/T 192's. Basic tooth type and location of the threaded tolerance specified in Figure 1. 1 wire thread internal screw threads - Basic type and tolerance position ......
